Securing the TV to the Wall

Caution: Pulling, pushing, or climbing on the TV may cause the TV to fall.
In particular, ensure your children do not hang over or destabilize the TV;
doing so may cause the TV to tip over, causing serious injuries or death.
Follow all safety precautions provided on the included Safety Flyer. For
added stability, install the anti-fall device for safety purposes, as follows.
To avoid the TV from falling:
1
Put the screws into the clamps and firmly fasten them onto the wall. Confirm that the
screws have been firmly installed onto the wall.
■ You may need additional material such as an anchor depending on the type of
wall.
■ Since the necessary clamps, screws, and string are not supplied, please
purchase these additionally.
2
Remove the screws from the centre back of the TV, put the screws into the clamps,
and then fasten the screws onto the TV again.
■ Screws may not be supplied with the product. In this case, please purchase the
screws of the following specifications.
■ Screw Specifications:
•
For a 17 ~ 29 Inch LCD TV: M4 X L15
• For a 32 ~ 40 Inch LCD TV: M6 X L15
3
Connect the clamps fixed onto the TV and the clamps fixed onto the wall with a strong
string and then tie the string tightly.
■ Install the TV near to the wall so that it does not fall backwards.
■ It is safe to connect the string so that the clamps fixed on the wall are equal to or
lower than the clamps fixed on the TV.
■ Untie the string before moving the TV.
4
Verify all connections are properly secured. Periodically check connections for any
sign of fatigue for failure. If you have any doubt about the security of your connections,
contact a professional installer.

Wall
Wall
