DVD Video Camera
VDR-D50P
Model No.
VDR-D50PC
VDR-D50EG
VDR-D50E
VDR-D50EB
VDR-D50EP
VDR-D50EE
VDR-D50EF
VDR-D50GC
VDR-D50GCS
VDR-D50GN
VDR-D50GT
VDR-D50SG
VDR-D50PL
VDR-D51EE
VDR-D58GK
VOL.1
Colour
(S)....................Silver Type
© 2007 Matsushita Electric Industrial Co., Ltd. All
rights
reserved.
distribution is a violation of law.
ORDER NO.VM0712051CE
B17
Unauthorized
copying
and

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VDR-D50P and is the answer not in the manual?

Questions and answers

Related Manuals for Panasonic VDR-D50P

Summary of Contents for Panasonic VDR-D50P

  • Page 1 ORDER NO.VM0712051CE DVD Video Camera VDR-D50P Model No. VDR-D50PC VDR-D50EG VDR-D50E VDR-D50EB VDR-D50EP VDR-D50EE VDR-D50EF VDR-D50GC VDR-D50GCS VDR-D50GN VDR-D50GT VDR-D50SG VDR-D50PL VDR-D51EE VDR-D58GK VOL.1 Colour (S)....Silver Type © 2007 Matsushita Electric Industrial Co., Ltd. All rights reserved. Unauthorized copying distribution is a violation of law.

  • Page 2: Table Of Contents

    VDR-D50P CONTENTS Page Page 1 Safety Precaution 9.2. Service Positions 1.1. General Guidelines 9.3. Location for Connectors of the Main P.C.B. 2 Warning 9.4. Electrical Adjustment Procedures 2.1. Prevention of Electrostatic Discharge (ESD) to 10 Maintenance Electrostatic Sensitive (ES) Devices 10.1.

  • Page 3: Safety Precaution

    VDR-D50P 1 Safety Precaution 1.1. General Guidelines 1. IMPORTANT SAFETY NOTICE There are special components used in this equipment which are important for safety. These parts are marked by in the Schematic Diagrams, Circuit Board Layout, Exploded Views and Replacement Parts List. It is essential that these critical parts should be replaced with manufacturer’s specified parts to prevent X-RADIATION, shock fire, or other hazards.

  • Page 4: Warning

    VDR-D50P 2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatic Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Electrostatic Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and semiconductor “chip”...

  • Page 5: Service Caution Based On Legal Restrictions

    VDR-D50P 2.2. Service caution based on legal restrictions 2.2.1. General description about Lead Free Solder (PbF) The lead free solder has been used in the mounting process of all electrical components on the printed circuit boards used for this equipment in considering the globally environmental conservation.

  • Page 6: Caution For Ac Cord (For Eb/Gc/Gcs/Sg)

    VDR-D50P 2.3. Caution for AC Cord (For Blue Neutral EB/GC/GCS/SG) Brown Live As the colours of the wires in the mains lead of this appliance 2.3.1. Information for your safety may not correspond with the coloured markings identifying the IMPORTANT...

  • Page 7: How To Replace The Lithium Battery (Procedure)

    2. Unsolder the Lithium Battery “ML-621S/F9D” and then replace the new one. (See Figure B1.) Fig. B1 Note: The lithium battery is a critical component. (Type No.: ML-621S/F9D Manufactured by Panasonic.) It must never be subjected to excessive heat or discharge. It must therefore only be fitted in equipment designed specifically for its use.

  • Page 8: How To Recycle The Lithium Battery (U.s. Only)

    VDR-D50P 2.5. How to Recycle the Lithium Battery (U.S. Only)

  • Page 9: Service Navigation

    1. Schematic Diagram, Block Diagram and P.C.B. layout of Main P.C.B. 2. Parts List for individual parts of Main P.C.B. 2) The following category are recycle module part. Please send them to Central Repair Center. *Main P.C.B. (LSEP8431A1: VDR-D50P/PC/PL) (LSEP8431P1: VDR-D50EG/E/EB/EF/EP) (LSEP8431Q1: VDR-D50GC/GCS/GN/EE/SG, VDR-D58GK)

  • Page 10: Service Caution

    VDR-D50P 3.2. Service Caution 3.2.1. Precaution of Laser Light Please remove the AC adapter/charger or battery at servicing that opens the Disc Cover.

  • Page 11: Procedure For Removing Disc

    VDR-D50P 3.3. Procedure for Removing Disc 3.3.1. Item to be checked Connect the AC adapter/charger or charged battery (power supply), make sure that the ACCESS indicator turns off, and then press the DISC EJECT button again. Even with normal product, the disc cannot be removed while the ACCESS indicator is lit or blinking.

  • Page 12: Specifications

    VDR-D50P 4 Specifications...

  • Page 13: Location Of Controls And Components

    VDR-D50P 5 Location of Controls and Components Followings are the Location of Controls and Components for VDR-D50P/PC as a sample. For other models, refer to each Operatin Instructions.
  • Page 14 VDR-D50P...

  • Page 15: Service Mode

    VDR-D50P 6 Service Mode 6.1. Error Display “PUSH THE RESET SWITCH” is displayed automatically on the EVF or the LCD Monitor when an undesirable condition has occured.

  • Page 16: Service Menu

    VDR-D50P 6.2. Service Menu When abnormal detection contents are confirmed a When I do the following operation automatic diagnosis code is displayed. 1. Preparation (1) Remove the card and disc from this unit. 2. To enter the Service Menu. (see Fig. S1) (1) Turn on power and set the Mode Dial to [DISC PLAYBACK MODE].
  • Page 17 VDR-D50P <Item 4> Please do the error code backup record the clear after repair completion. CLEAR METHOD If the Card and Disc inserted, take out it before Service Mode operation. Turn on power and set the Mode Dial to [DISC RECORDING MODE].

  • Page 18: Service Fixture & Tools

    VDR-D50P 7 Service Fixture & Tools 7.1. Service Tools and Equipment...

  • Page 19: Disassembly And Assembly Instructions

    VDR-D50P 8 Disassembly and Assembly Instructions 8.1. Disassembly Frow Chart This flow chart indicates the disassembly steps the cabinet parts, P.C.B. and Mecha. Unit in order to access to be serviced. When reinstalling, perform the steps in the reverse order.

  • Page 20: Layout

    VDR-D50P 8.2. P.C.B. Layout Fig. F1...

  • Page 21: Disassembly Procedures

    VDR-D50P 8.3. Disassembly Procedures Flow-Chart for Disassembly Procedure It, / Part Fig. Removal (Screw,Connector,FPC. & Other) Front Unit Fig. D2 2-Screws (A) Front Panel Unit Fig. D3 1-Screw (B) 1-Screw (C) Fig. D4 Open the Disc Cover 1-Screw (D) Fig. D5 1-Screw (E) Fig.
  • Page 22 VDR-D50P Fig. D1 Fig. D3 Fig. D2 Fig. D4...
  • Page 23 VDR-D50P Fig. D7 Fig. D5 Fig. D6 Fig. D8...
  • Page 24 VDR-D50P Fig. D11 Fig. D9 Fig. D10 Fig. D12...
  • Page 25 VDR-D50P Fig. D15 Fig. D13 Fig. D16 Fig. D14...
  • Page 26 VDR-D50P Fig. D19 Fig. D17 Fig. D20 Fig. D18 Fig. D21...

  • Page 27: Disassembly Procedures Of Camera Lens Unit

    VDR-D50P 8.4. Disassembly Procedures of Camera Lens Unit The following flowchart describes order or steps for removing the Camera lens unit and certain printed circuit boards in order to make access to the item needing service. To reassemble the unit follow the steps in reverse order.

  • Page 28: Measurements And Adjustments

    VDR-D50P 9 Measurements and Adjustments 9.1. EEPROM Data for spare parts of the MAIN P.C.B. After replacing the MAIN P.C.B., be sure to achieve adjustment. As for Adjustment condition/procedure, consult the “Adjustment Manual” which is available in Adjustment software. The Adjustment software is available at “TSN Website”, therefore, access to “TSN Website” at “Support Information from NWBG/VDBG-PAVC”.
  • Page 29 VDR-D50P 9.2.2. Checking and repairing individual circuit boards except module parts (Main P.C.B.) How to use extension cables.

  • Page 30: Location For Connectors Of The Main P.c.b

    VDR-D50P 9.3. Location for Connectors of the Main P.C.B.

  • Page 31: Electrical Adjustment Procedures

    VDR-D50P 9.4. Electrical Adjustment Procedures 9.4.1. Initial guideline The table below shows which adjustments are necessary according to the unit parts and individual parts to be replaced. Make sure to perform these adjustments shown below as necessary. 9.4.2. Set-up manual for DVD Video Camera.
  • Page 32 VDR-D50P Fig. E1 Fig. E2 Rough image of set-up connection Part Number of jig · Only a necessary jig mentions it setup electric adjustment Parts Name Parts No. Q’ty Remarks Personal Computer With Tatsuin Software AC Adaptor The AC Adaptor for Video Camera...
  • Page 33 VDR-D50P 9.4.3. Set up of PC-EVR Adjustment Program 1. Turn on the PC and install the TATSUJIN Adjustment Program into the PC. 2. TATSUJIN PC-Adjustment Program start in the following procedure. PC Menu : [Start] ® [Program] ® [win Tatsujin] ® [DV Movie] ®...

  • Page 34: Maintenance

    VDR-D50P 10 Maintenance 10.1. Cleaning Lens, Viewfinder and LCD Panel Do not touch the surface of the lens, Viewfinder and LCD Panel with your hand. When cleaning the lens, use air-Blower to blow off the dust. When cleaning the LCD Panel, dampen the lens cleaning paper with lens cleaner, and the gently wipe the their surface.
  • Page 35 VDR-D50P...
  • Page 36 VDR-D50P...

  • Page 37: Schematic Diagrams

    VDR-D50P 11 Schematic Diagrams 11.1. OVERALL SCHEMATIC DIAGRAM LENS UNIT FRONT P.C.B. AV MULTI JACK SPEAKER FLEX. IC7801, IC7802 IC4801 ZOOM IRIS FOCUS (GYRO) (MIC AMP) IC3301 AVIO (D/A,A/D,AV OUT AMP) AVIO IC303 (V.DRIVER) TERMINAL IC3001 (VIDEO SIGNAL PROCESS, AUDIO SIGNAL...

  • Page 38: Interconnection Schematic Diagram

    VDR-D50P 11.2. INTERCONNECTION SCHEMATIC DIAGRAM LENS UNIT EVF LCD PANEL JOYSTICK ZOOM MENU O.I.S. DELET BATTERY REC START/STOP CATCHER ECM(L) ECM(R) MODE DIAL/ POWER DISC EJECT SIDE CASE (L) UNIT REAR CASE UNIT MIC UNIT EVF BACKLIGHT P.C.B. REMOTE CONTROL...

  • Page 39: Front Schematic Diagram

    VDR-D50P 11.3. FRONT SCHEMATIC DIAGRAM (FRONT P.C.B.) :AUDIO MAIN SIGNAL PATH IN REC MODE (R.FILTER) MAIN CN FP41 (MIC AMP) (VDR-D51) BATTERY AV JACK (AMP) (AMP) NOTE: DO NOT USE ANY PART NUMBER SHOWN ON THIS SCHEMATIC DIAGRAM FOR ORDERING.

  • Page 40: Lcd Backlight Schematic Diagram

    VDR-D50P 11.4. LCD BACKLIGHT SCHEMATIC DIAGRAM (LCD BACKLIGHT P.C.B.) :VIDEO MAIN SIGNAL PATH LCD PANEL FP8102 SHAFT FPC FP8101 (AMP) -5.6 (VREF) NOTE: DO NOT USE ANY PART NUMBER SHOWN ON THIS SCHEMATIC DIAGRAM FOR ORDERING. WHEN YOU ORDER A PART,PLEASE REFER TO PARTS LIST.

  • Page 41: Evf Backlight Schematic Diagram

    VDR-D50P 11.5. EVF BACKLIGHT SCHEMATIC DIAGRAM 11.7. DISC COVER LOCK UNIT SCHEMATIC DIAGRAM (EVF BACKLIGHT P.C.B.) (DISC COVER LOCK UNIT) "FOR REFERENCE ONLY" :VIDEO MAIN SIGNAL PATH NOTE: DO NOT USE ANY PART NUMBER SHOWN ON DOOR OPEN DVD DRIVE UNIT THIS SCHEMATIC DIAGRAM FOR ORDERING.

  • Page 42: Rear Case Unit Schematic Diagram

    VDR-D50P 11.9. REAR CASE UNIT SCHEMATIC DIAGRAM 11.11. LCD SHAFT FPC SCHEMATIC DIAGRAM (LCD SHAFT FPC) (REAR CASE UNIT) :VIDEO MAIN SIGNAL PATH "FOR REFERENCE ONLY" "FOR REFERENCE ONLY" MAIN CN FP1701 LCD REVERS BATTERY MAIN CN CATCHER LCD BLACKLIGHT...

  • Page 43: Printed Circuit Board

    VDR-D50P 12 Printed Circuit Board 12.1. EVF BACKLIGHT P.C.B. (LSEP8365A1) (COMPONENT SIDE) (FOIL SIDE) VDR-D50,D51,D58 EVF BLACKLIGHT P.C.B.

  • Page 44: Front P.c.b

    VDR-D50P 12.2. FRONT P.C.B. (LSEP8432A1:VDR-D50,VDR-D58) (LSEP8432B1:VDR-D51) (VDR-D51) (COMPONENT SIDE) (FOIL SIDE) NOTE:MULTILAYER P.C.B. THIS P.C.B. IS Multi-Layer P.C.B. THIS CIRCUIT BOARD SHOWS COMPONENT LAYOUT-PATTERN VDR-D50,D51,D58 FOR COMPONENT SIDE AND FOIL SIDE. LAYOUT-PATTERNS ARE SINGLE PATTERN FOR EACH SIDE THAT MAKE EASY TO SIGHT THE COMPONENT LAYOUT.

  • Page 45: Lcd Backlight P.c.b

    VDR-D50P 12.3. LCD BACKLIGHT P.C.B. (LSEP8433A1) (COMPONENT SIDE) (FOIL SIDE) VDR-D50,D51,D58 LCD BLACKLIGHT P.C.B.
  • Page 46 VDR-D50P...

  • Page 47: Parts And Exploded Views

    VDR-D50P 13 Parts and Exploded Views 13.1. Exploded Views 13.1.1. Frame & Casing Section...
  • Page 48 VDR-D50P...
  • Page 49 VDR-D50P 13.1.2. LCD Section...
  • Page 50 VDR-D50P 13.1.3. Camera Lens Section...
  • Page 51 VDR-D50P 13.1.4. EVF Section...
  • Page 52 VDR-D50P 13.1.5. Packing Parts & Accessories Section...

  • Page 53: Replacement Parts List

    VDR-D50P 13.2. Replacement Parts List 13.2.1. Frame & Casing Section Parts List Ref. Part No. Part Name & Remarks Description XQN16+BJ5FN SCREW XQN16+BJ5FN SCREW XQN16+BJ5FN SCREW XQN16+BJ5FN SCREW XQN16+BJ5FN SCREW Ref. Part No. Part Name & Remarks Description LSMA1031 EARTH PLATE(SIDE...
  • Page 54 VDR-D50P Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description GN,GN,SG LSMD0849 EVF REFLECT PIECE (PSECI) LSKM1670 LCD CASE A (PSECI)D51EE LSMD0850 EVF SHEET HOLDER (PSECI) LSKM1671 LCD CASE A (PSECI)D58GK L5BDDXH00027 LCD PANEL...
  • Page 55 VDR-D50P Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description LSQT1328-A (PSECI)EP C7802 F1J1A106A023 C.CAPACITOR CH 10V LSQT1329-A (PSECI)EP C7803 F3F0J226A055 E.CAPACITOR CH LSQT1331-A (PSECI)GC,GCS 6.3V 22U C7804 F3F0J226A055 E.CAPACITOR CH LSQT1332-A (PSECI)GC,GCS 6.3V 22U...
  • Page 56 VDR-D50P Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description Q8901 2SC6054J0L TRANSISTOR R8903 ERJ3RBD101 M.RESISTOR CH 1/10W 100 R315 ERJ2GEJ470 M.RESISTOR CH 1/16W 47 SW2501 ESE18L62D SWITCH (PSECI) R601 ERJ3GEYJ562 M.RESISTOR CH...
