- Page 1 2003 ST1300 / ST1300A SET-UP INSTRUCTIONS Set-up and pre-delivery service must be performed by an authorized Honda motorcycle dealer. MPD 9743-9976 (0301) Issued: July 2002 Revised: October 2002 Revised: January 2003 Reorder: S0132 ©2003 American Honda Motor Co., Inc. - All Rights Reserved...
- Page 2 To reduce the possibility of a fire or explosion, be careful when working around gasoline or batteries. Use only a nonflammable solvent, not gasoline, to clean parts. Keep all cigarettes, sparks and flames away from the battery and all fuel-related parts. ©2003 American Honda Motor Co., Inc. - All Rights Reserved...
- Page 3 Modifications and Accessories Modifications which you may have made, or should make in the future, to any Honda product, shall be deemed by our company to have been performed at your sole risk and responsibility, and without our company's or the manufacturer's approval, or consent, implied or expressed.
- Page 4 WHEEL BRACE BOLTS SIDE BRACES FRAME BOLTS NUTS Remove the nuts, plate, and bolts. PLATE Using two people, carefully remove the crate frame; the metal frame can damage the motorcycle. ©2003 American Honda Motor Co., Inc. - All Rights Reserved...
- Page 5 2003 ST1300 / ST1300A 4. Loose Parts Information. Unpack the remaining loose parts and check them against this illustration. Report any damaged or missing parts immediately to American Honda by calling (800) 421-1900, ext. 1. DESCRIPTION PART NUMBER Cover, R, mirror...
- Page 6 Identify the missing parts by referring to the “Loose Parts Information.” Order the parts using normal parts ordering procedures. For parts lost, damaged in transit or left out by the factory, submit a M/C Warranty/Transportation Claim Form via DCS. ©2003 American Honda Motor Co., Inc. - All Rights Reserved...
- Page 7 Lift the motorcycle free from the crate base and remove the base. On a firm, level surface, lower the centerstand and lower the motorcycle until it is resting on its rear wheel SHIPPING and centerstand. BRACE ©2003 American Honda Motor Co., Inc. - All Rights Reserved...
- Page 8 Torque the bolts. 6 X 16 MM Torque: 9 ft-lbs (1.2 kg-m, 12 N 6 X 18 MM RUBBER WASHER 6 X 20 MM REFLECTOR STAY REFLECTOR 6MM NUT ©2003 American Honda Motor Co., Inc. - All Rights Reserved...
-
Page 9: Install The Front Wheel
On ST1300A, verify the clearance is as shown. Reinstall the caliper bolts and tighten to the specified torque. Torque: 23 ft-lbs (3.2 kg-m, 31 N 0.4 - 1.2 MM (0.02 - 0.05 in) ©2003 American Honda Motor Co., Inc. - All Rights Reserved... - Page 10 4 X 25 MM SCREW BOLTS WINDSHIELD Tighten the screw bolts securely. BRACKET 6 X 18 FLANGE BOLTS PLASTIC WINDSHIELD WASHER BRACKET COVER PLASTIC ADJUSTER WASHER RUBBER WINDSHIELD ADJUSTER 6 MM NUTS ©2003 American Honda Motor Co., Inc. - All Rights Reserved...
-
Page 11: Install The Mirrors
Install the mirror rubber cover, then install the mirror cover. Check that the mirror rubber cover and mirror cover are installed securely. SHIPPING BOLTS (DISCARD) MIRROR RUBBER COVER HOLE TERMINALS SUSPENSION BAND MIRROR COVER ©2003 American Honda Motor Co., Inc. - All Rights Reserved... - Page 12 Insert the ignition switch key into the saddlebag lever lock and turn it clockwise to the position shown. Push in on the saddlebag lever lock while aligning it with the cutout in the saddlebag as shown. ©2003 American Honda Motor Co., Inc. - All Rights Reserved...
- Page 13 12. Remove the saddlebag. LATCH LEVER Insert the ignition key and turn it clockwise to open the latch lever. Remove the right side saddlebag by lifting up and pulling it out. SADDLE BAG ©2003 American Honda Motor Co., Inc. - All Rights Reserved...
- Page 14 Do not allow the positive (+) cable to contact any metal parts. Reinstall the side cover and saddlebag in the reverse order of removal. ©2003 American Honda Motor Co., Inc. - All Rights Reserved...
- Page 15 Slide the seat height adjuster toward the rear, then seat it in the guide. Be sure to align the hole in the rear of the front seat GUIDE with the adjuster when installing. HIGH Position MID Position LOW Position ©2003 American Honda Motor Co., Inc. - All Rights Reserved...
-
Page 16: Install The Seat
Close the latch lever and turn the ignition key counterclockwise. Be sure the seats are locked securely in position. Replace the ignition key. REAR SEAT LATCH LEVER IGNITION KEY IGNITION ©2003 American Honda Motor Co., Inc. - All Rights Reserved... -
Page 17: Check The Oil Level
Classification - SG or higher except oils labeled as INSPECTION WINDOW energy conserving on the cirular API service label Crankcase capacity (after draining) – 3.8 US Quarts, 3.6 Liters LOWER UPPER LEVEL LEVEL MARK MARK ©2003 American Honda Motor Co., Inc. - All Rights Reserved... -
Page 18: Check The Coolant Level
LOWER LOWER LEVEL LEVEL Add Pro Honda DOT 4 brake fluid or equivalent from a MARK MARK sealed container to bring the level up to the upper level mark. Reinstall the cap or the diaphragm, cover, and screws. - Page 19 RIGHT RUNNING (ORANGE) CONNECTOR LIGHT CONNECTOR RIGHT HEADLIGHT SOCKET LEFT RUNNING LIGHT CONNECTOR HEADLIGHT AIMING MOTOR 3P (GRAY) LEFT POSITION LIGHT SOCKET CONNECTOR LEFT HEADLIGHT SOCKET RIGHT POSITION LIGHT SOCKET ©2003 American Honda Motor Co., Inc. - All Rights Reserved...
- Page 20 24 hours after attaching the pads. 27. Complete the Set-Up/Pre-Delivery Checklist. Complete an On-Road Motorcycle Set-up/Pre-delivery Checklist (Reorder No. S0297) by checking the boxes confirming that the steps were done. ©2003 American Honda Motor Co., Inc. - All Rights Reserved...
- Page 21 2003 ST1300 / ST1300A ©2003 American Honda Motor Co., Inc. - All Rights Reserved...
- Page 22 ©2003 American Honda Motor Co., Inc. - All Rights Reserved...
- Page 23 Printed in U.S.A.
