BUILT-IN GAS COOKTOPS
for residential use only
VDGCT212F..
Models:
VDGCT424FSS
VDGCT530FSS
VDGCT536FSS
INSTALLATION INSTRUCTIONS
IMPORTANT - PLEASE READ AND FOLLOW
• Before beginning, please read these instructions completely and carefully.
• Do not remove permanently affixed labels, warnings, or plates from the product. This may
void the warranty.
• Please observe all local and national codes and ordinances.
• Please ensure that this product is properly grounded.
• The electrical plug should always be accessible.
• The installer should leave these instructions with the consumer who should retain
for local inspector's use and for future reference.
Installation must conform with local codes or in the absence of codes, the National Fuel Gas
Code ANSI Z223.1/NFPA 54 - Iatest edition. Electrical installation must be in accordance with
the National Electrical Code, ANSI/NFPA70 - latest edition and/or local codes.
IN CANADA: Installation must be in accordance with the current CAN/CGA-B149.1 National
Gas Installation Code or CAN/CGA-B149.2, Propane Installation Code and/or local codes.
Electrical installation must be in accordance with the current CSA C22.1 Canadian Electrical
Codes Part 1 and/or local codes.
INSTALLATION IN MANUFACTURED (MOBILE) HOME: The installation must conform with
the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280 [formerly
the Federal Standard for Mobile Home Construction and Safety, Title 24, HUD (Part 280)] or,
when such standard is not applicable, the Standard for Manufactured Home Installations,
ANSI/NCSBCS A225.1, or with local codes where applicable.
INSTALLATION IN RECREATIONAL PARK TRAILERS: The installation must conform with
state or other codes or, in the absence of such codes, with the Standard for Recreational Park
Trailers, ANSI A119.5.
Installation of any gas-fired equipment should be made by a licensed plumber. A manual shut-
off valve must be installed in an accessible location in the gas line external to the appliance
for the purpose of turning on or shutting off gas to the appliance (In Massachusetts such shut-
off devices should be approved by the Board of State Examiners of Plumbers & Gas Fitters).
If an external electrical source is utilized, the appliance, when installed, must be electrically
grounded in accordance with local codes or, in the absence of local codes, with the national
Electrical Code, ANSI/NFPA 70.
Some models are supplied with a protective film on steel and aluminium
parts. This film must be removed before installing/using the appliance.
THIS COOKTOP IS FOR RESIDENTIAL USE ONLY
R
Advertisement
Table of Contents
Related Manuals for Verona VDGCT212F Series
Summary of Contents for Verona VDGCT212F Series
- Page 1 BUILT-IN GAS COOKTOPS for residential use only VDGCT212F.. Models: VDGCT424FSS VDGCT530FSS VDGCT536FSS INSTALLATION INSTRUCTIONS IMPORTANT - PLEASE READ AND FOLLOW • Before beginning, please read these instructions completely and carefully. • Do not remove permanently affixed labels, warnings, or plates from the product. This may void the warranty. • Please observe all local and national codes and ordinances. • Please ensure that this product is properly grounded. • The electrical plug should always be accessible. • The installer should leave these instructions with the consumer who should retain for local inspector’s use and for future reference.
-
Page 2: If The Information In This Manual Is Not Followed Exactly, A Fire Or Explosion May Result Causing Property Damage, Personal Injury, Or Death
WARNING ! If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury, or death. – Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. – NEVER use this appliance as a space heater to heat or warm the room. Doing so may result in carbon monoxide poisoning and overheating of the appliance. – WHAT TO DO IF YOU SMELL GAS: • Do not try to light any appliance. • Do not touch any electrical switch. - Page 3 Dear Customer, Thank you for having purchased and given your preference to our product. The safety precautions and recommendations reported below are for your own safety and that of others. They will also provide a means by which to make full use of the features offered by your appliance. Please preserve this booklet carefully.
-
Page 4: General Information
USER INSTRUCTIONS GENERAL INFORMATION WARNING!! 1. Installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI ELECTRICAL GROUNDING INSTRUCTIONS Z223.1/NFPA 54 - Latest Edition, CAN/CGA-B149.1 or CAN/ The cooktop must be electrically grounded in accordance CGA-B149.2. with local codes or, in the absence of local codes, with the 2. Installation in manufactured (mobile) home: installation must National Electrical Code, ANSI/NFPA No. 70-latest edition, in conform with the Manufactured Home Construction and... -
Page 5: Important Precautions And Recommendations
IMPORTANT PRECAUTIONS AND RECOMMENDATIONS • This appliance is intended for use in your household. Never use the appliance for any other purpose! • Important! The use of suitable protective clothing/gloves is recommended when handling, installing or cleaning of this appliance. • After having unpacked the appliance, check to ensure that it is not damaged. In case of doubt, do not use it and consult your supplier or a professionally qualified technician. • Packing elements (i.e. plastic bags, polystyrene foam, nails, packing straps, etc.) should not be left around within easy reach of children, as these may cause serious injuries. The packaging material is recyclable and is marked with the recycling symbol • To avoid any possible hazard, the appliance must be installed by qualified personnel only. Any repairs by unqualified persons may result in electric shock or short circuit. In order to avoid possible injuries to your body or to the appliance, do not attempt any repairs by yourself. Such work should be carried out by qualified service personnel only. • Do not attempt to modify the technical characteristics of the appliance as this may become dangerous to use. The manufacturer declines all responsibility for any inconvenience resulting from the inobservance of this condition. -
Page 6: Control Panel Description
features Mod. VDGCT212F.. Mod. VDGCT424FSS Fig. 1.1a Fig. 1.1b Mod. VDGCT530FSS Mod. VDGCT536FSS Fig. 1.1c Fig. 1.1d COOKING POINTS CONTROL PANEL DESCRIPTION 1. Semirapid burner (SR) 7000 BTU/hr 9. Semirapid burner control knob 2. Rapid buner (R) 10000 BTU/hr 10. Rapid burner control knob 3. Auxiliary burner (AUX) 4000 BTU/hr 11. Auxiliary burner control knob 4. Semirapid burner (SR) 7000 BTU/hr 12. Semirapid burner control knob 5. Semirapid burner (SR) 7000 BTU/hr... -
Page 7: Using The Gas Cooktop
using the gas cooktop GAS BURNERS Gas flow to the burners is adjusted by turning the knobs (illustrated in fig. 2.1) which control the valves. Turning the knob so that the indicator line points to the symbols printed on the panel achieves the following functions: AUXILIARY burner Knob SEMI-RAPID burner DUAL burner Function position RAPID burner Fig. 2.1 closed valve Caution! Do not cover the hob with aluminium foils. maximum LITE-HI rate... - Page 8 LIGHTING GAS BURNERS FITTED WITH FLAME FAILURE SAFETY DEVICE In order to light the burner, you must: 1. Push and turn the knob in an counterclockwise direction up to the LITE-HI position (maximum rate), push in and hold the knob until the flame has been lit (fig. 2.2). The sparks produced by the lighter situated inside the relative burner will light the flame. In the event that the local gas supply conditions makes it difficult to light the burner in LITE-HI position, try again with the knob in LO position (minimum rate). 2. Wait for a few seconds after the gas burner has been lit before letting go the knob (safety device activation delay). Fig. 2.2 3. Adjust the gas valve to the desired position. If there is no mains electrical supply, the burners can be used with no restriction. In that case, in order to light the burner, you must: 1. Bring a lighted match close to the burner (as per side figure) and keep it in place until the burner has been ignited.
- Page 9 CHOICE OF BURNER (fig. 2.4) The symbols printed on the panel close to the gas knobs indicate the correspondence between the knob and the burner. The most suitable burner is to be chosen according to the diameter and volume capacity of the container to be warmed. It is important that the diameter of the pots or pans suitably match the heating potential of the burners in order not to jeopardise the efficiency of the burners, bringing about a waste of gas fuel. A small diameter pot or pan placed on a large burner does not necessarily mean that boil- ing conditions are reached quicker. Fig. 2.4 DIAMETERS OF PANS WHICH MAY BE USED ON THE HOB BURNERS BURNER MINIMUM MAXIMUM Auxiliary (*) 12 cm (4” 11/16)
-
Page 10: Cleaning And Maintenance
cleaning and maintenance GENERAL RECOMANDATION WARNING • Important: Before you begin cleaning, you must ensure that the appliance is VERY IMPORTANT switched off and disconnected from the electrical power supply. • IMPORTANT: The use of suitable protective clothing/gloves is recommended Before operation cleaning and maintenance when handling or cleaning of this appliance. - Page 11 BURNERS • These parts can be removed and cleaned with appropriate products. These parts must be cleaned using a sponge and soapy water or other suitable non- abrasive products. Dry with a soft cloth. Warning! Not dishwasher safe. • After cleaning, the burners and their flame distributors must be well dried and correctly replaced. • It is very important to check that the burner flame distributor and the cap have been correctly positioned. Failure to do so can cause serious problems. • Check that the probe “T” (figs. 3.1, 3.3) next to each burner is always clean to ensure correct operation of the safety valves. • Check that the electrode “S” (figs. 3.1, 3.3) next to each burner is always clean to ensure trouble-free sparking. • Both the probe and ignition plug (electrode) must be very carefully cleaned. • Note: To avoid damage to the electric ignition do not use it when the burners are not in place. Note: Continuous use may cause a change in the glaze around the burners Fig. 3.1 and grids, corresponding to the areas exposed to the heat. This is a natural...
-
Page 12: Pan Supports
PAN SUPPORTS These parts must be cleaned using a sponge and soapy water or other suitable non-abrasive products. Dry with a soft cloth. Warning! Not dishwasher safe. It is very important to check that the pan supports have been correctly positioned. Failure to do so can cause serious problems. The prongs of the pan supports must always be centred with the burners (figs. 3.6, 3.7, 3.8, 3.9). Models VDGCT424FSS, VDGCT530FSS, VDGCT536FSS: The raised portion of the pan supports shall NOT face the sides of the cooktop (fig. 3.10). Note: Continuous use may cause a change in the glaze around the burners and grids, corresponding to the areas exposed to the heat. This is a natural phenomenon and does not prevent the parts from working properly. Mod. VDGCT212F.. Fig. 3.6 Mod. VDGCT424FSS Fig. 3.7 Mod. VDGCT530FSS Fig. 3.8... - Page 13 Mod. VDGCT536FSS Fig. 3.9 Fig. 3.10...
- Page 16 The manufacturer cannot be held responsible for possible inaccuracies due to printing or transcription errors in the present booklet. The manufacturer reserves the right to make all modifications to its products deemed necessary for manufacture or commercial reasons at any moment and without prior notice, without jeopardising the essential functional and safety characteristics of the appliances. Cod. 1106205-ß0...
