Graco Lube Sentinel II Instructions Manual page 21

W1zx
W2zx
W3zx
W4zx
W5zx
W6zxxxx
W7zxxxx
W8zxxxx
W9xxxx
313903B
Set Zone Enable/Disable.
a. BYTE z = 1 or 2 for the zone being addressed.
b. BYTE x = 0 or 1 to disable or enable the zone.
Set zone unit of measure.
a. BYTE z = 1 or 2 for the zone being addressed.
b. BYTE x = selects units to display.
0 = Ounce
1 = Pints
2 = Gallons
3 = Liters
4 = Millimeters
5 = Counts
Set Zone Interlock.
a. BYTE z = 1 or 2 for the zone being addressed.
b. BYTE x = Interlock of alarms.
0 = Alarm Disabled
1 = Alarm Zones Interlocked (First Alarm)
2 = Alarms Independent
Set high/low alarm limits.
a. BYTE z = 1 or 2 for the zone being addressed.
b. BYTE x = Alarm generation.
0 = Low Flow Alarm Only.
1 = High Flow Alarm Only.
2 = Both Low and High Flow Alarms.
BYTE - Turns the Tachometer On or Off.
0 = Disabled
1 = Enabled
Set the port total.
a. BYTE z = 1 or 2 for the zone being addressed.
b. INTEGER xxxx = 5 to 9999 (thousandths of a cu-in.).
Set Low Flow Alarm.
a. BYTE z = 1 or 2 for the zone being addressed.
b. INTEGER xxxx = 5 to 65535 per sentinel specifications. Low Flow Alarm should
be at least 10% less than the High Flow Alarm.
Set High Flow Alarm.
a. BYTE z = 1 or 2 for the zone being addressed.
b. INTEGER xxxx = 5 to 65535 per sentinel specifications. High Flow Alarm
should be at least 10% greater than the Low Flow Alarm.
Set normal tachometer speed.
INTEGER xxxx = 50 to 5001
Definitions
21
