Pack 08 | Build Instructions
Your Shelby GT500 Super Snake is a finely detailed model replicating every
aspect of the original car. From the paint color to the smallest interior details,
every piece is precisely reproduced.
In your model pack, you will assemble:
STAGE 56: SHOCK ABSORBER AND
STAGE 61: STEERING COLUMN
LEFT REAR BRAKE
AND STEERING WHEEL
STAGE 57: LEFT REAR WHEEL
STAGE 62: TRUNK PANEL
STAGE 58: SHOCK ABSORBER AND
STAGE 63: SPARE WHEEL , STEERING
REAR RIGHT BRAKE
WHEEL AND FLOOR ASSEMBLY
STAGE 59: RIGHT REAR WHEEL
STAGE 64: TRUNK PANELS , JACK,
AND FIXING THE SPARE WHEEL
and fixing the rear wheels
STAGE 60: EXHAUST SYSTEM ASSEMBLY
1
AGORAMODELS
SHELBY SUPER SNAKE
Advertisement
Related Manuals for Agora Shelby GT500 Super Snake 1967
Summary of Contents for Agora Shelby GT500 Super Snake 1967
- Page 1 Pack 08 | Build Instructions Your Shelby GT500 Super Snake is a finely detailed model replicating every aspect of the original car. From the paint color to the smallest interior details, every piece is precisely reproduced. In your model pack, you will assemble: STAGE 56: SHOCK ABSORBER AND STAGE 61: STEERING COLUMN LEFT REAR BRAKE...
- Page 2 Stage 56: Shock Absorber and Left Rear Brake You will start Pack 8 by assembling a shock absorber and fixing it to the chassis. S T A G E 5 6 P A R T S L I S T Name Quantity Left Rear Brake...
- Page 3 Stage 56: Shock Absorber and Left Rear Brake S T E P 1 J O I N T H E S H O C K A B S O R B E R C Y L I N D E R T O T H E S H O C K A B S O R B E R S U P P O R T Align the shock absorber cylinder with the shock absorber support and position the parts together so that the three...
- Page 4 Stage 56: Shock Absorber and Left Rear Brake S T E P 3 J O I N T H E S H O C K A B S O R B E R P I S T O N T O T H E S P R I N G P L A T E A N D F I X B A C K O N T H E C H A S S I S Take the spring plate removed in step 2 and insert...
- Page 5 Stage 56: Shock Absorber and Left Rear Brake Stage 56 complete! AGORAMODELS SHELBY SUPER SNAKE...
- Page 6 Stage 57: Left Rear Wheel You will now build the left rear wheel and fix it to the chassis assembly. S T A G E 5 7 P A R T S L I S T Name Quantity Hubcap Tire Screws TYPE MP03 2 [inc.
- Page 7 If you are struggling to fit the tires, there’s extra help available in the build diary on the Agora Models Forum. S T E P 2 P O S I T I O N T H E B R A K E O N T H E R I M Take the brake supplied in the previous stage.
- Page 8 Stage 57: Left Rear Wheel S T E P 3 F I X T H E L E F T R E A R W H E E L T O T H E C H A S S I S Present the wheel &...
- Page 9 Stage 57: Left Rear Wheel Stage 57 complete! AGORAMODELS SHELBY SUPER SNAKE...
- Page 10 Stage 58: Shock Absorber and Right Rear Brake You will now add the rear right shock absorber and brake. S T A G E 5 8 P A R T S L I S T Name Quantity Right Rear Brake Shock Absorber Piston Shock Absorber Cylinder Shock Absorber Support...
- Page 11 Stage 58: Shock Absorber and Right Rear Brake S T E P 1 J O I N T H E S H O C K A B S O R B E R C Y L I N D E R T O T H E S H O C K A B S O R B E R S U P P O R T Align the shock absorber cylinder with the shock absorber support and position the parts together so that the three...
- Page 12 Stage 58: Shock Absorber and Right Rear Brake S T E P 3 J O I N T H E S H O C K A B S O R B E R P I S T O N T O T H E S P R I N G P L A T E A N D F I X B A C K O N T H E C H A S S I S Take the spring plate removed in step 2 and insert...
- Page 13 Stage 59: Right Rear Wheel Another wheel! You will now build the right rear wheel. S T A G E 5 9 P A R T S L I S T Name Quantity Hubcap Tire Screws TYPE MP03 2 [inc. 1 spare] Tire Screws Hubcap...
- Page 14 If you are struggling to fit the tires, there’s extra help available in the build diary on the Agora Models Forum. S T E P 2 P O S I T I O N T H E B R A K E O N T H E R I M Take the brake supplied in the previous stage.
- Page 15 Stage 59: Right Rear Wheel S T E P 3 F I X T H E R I G H T R E A R W H E E L T O T H E C H A S S I S Present the wheel &...
- Page 16 Stage 59: Right Rear Wheel Stage 59 complete! AGORAMODELS SHELBY SUPER SNAKE...
- Page 17 Stage 60: Exhaust System Assembly You will start to add the exhaust system to your assembly. S T A G E 6 0 P A R T S L I S T Name Quantity Exhaust System Resonator Half Pipe 1 Resonator Half Pipe 2 Screws TYPE MP02 5 [inc.
- Page 18 Stage 60: Exhaust System Assembly MP03 S T E P 1 R E M O V E T H E F L O O R P A N Place your chassis assembly on your worktable the right way MP01 up. Begin by removing the rear floor pan mounted in stage 16.
- Page 19 Stage 60: Exhaust System Assembly S T E P 3 R E F I T T H E F L O O R P A N Turn the chassis over again, so it is facing the right way up, and refit the floor pan. Begin by easing the lug underneath the eyelet at the far end of the floor pan and then check the alignment of the remaining screw holes before refitting the 11 x screws.
- Page 20 Stage 60: Exhaust System Assembly S T E P 5 F I T T H E E X H A U S T S Y S T E M T O T H E C H A S S I S With the chassis upside down on your worktable, position the exhaust system so that the resonators are directed towards the rear.
- Page 21 Stage 60: Exhaust System Assembly Stage 60 complete! AGORAMODELS SHELBY SUPER SNAKE...
- Page 22 Stage 61: Steering Column and Steering Wheel In this stage you will build the steering column. S T A G E 6 1 P A R T S L I S T Name Quantity Upper Column Cover Lower Column Cover Steering Wheel Steering Column Steering Wheel Emblem...
- Page 23 Stage 61: Steering Column and Steering Wheel S T E P 1 F I X T H E P I N I O N T O T H E S T E E R I N G C O L U M N To begin this stage, place the pinion on the end of the steering column.
- Page 24 Stage 61: Steering Column and Steering Wheel S T E P 3 A D D T H E S T E E R I N G W H E E L Now rotate the column until the central section at its end (indicated by the right arrow) is aligned with the side controls (left arrow).
- Page 25 Stage 61: Steering Column and Steering Wheel Stage 61 complete! AGORAMODELS SHELBY SUPER SNAKE...
- Page 26 Stage 62: Trunk Panel There is no building in this stage. You can remove the panel from its packaging and move straight to the next stage. S T A G E 6 2 P A R T S L I S T Name Quantity Trunk Partition Panel...
- Page 27 Stage 63: Spare Wheel, Steering Wheel and Floor Assembly You are now going to build the spare wheel, then fit the steering wheel and the floor assembly to the chassis. S T A G E 6 3 P A R T S L I S T Name Quantity Spare Tire...
- Page 28 Stage 63: Spare Wheel, Steering Wheel and Floor Assembly S T E P 1 S O A K A N D F I T T H E T I R E Soak the tire and fit to the rim following the same procedure as for the other four wheels.
- Page 29 Stage 63: Spare Wheel, Steering Wheel and Floor Assembly S T E P 3 F I T T H E F L O O R T O T H E C H A S S I S A N D A D D T H E S T E E R I N G C O L U M N A D J U S T E R Place the chassis assembly on your worktable and position the floor assembly on top.
- Page 30 Stage 63: Spare Wheel, Steering Wheel and Floor Assembly S T E P 4 S E C U R E T H E F L O O R T O T H E C H A S S I S Turn the chassis over and fix the floor in place using 2 x TYPE MP01 screws supplied with stage 61.
- Page 31 Stage 64: Trunk Panels and Fitting The Spare Wheel You are now going to fit the interior trunk partition panels and the spare wheel. S T A G E 6 4 P A R T S L I S T Name Quantity Trunk Left Side Partition Panel...
- Page 32 Stage 64: Trunk Panels and Fitting The Spare Wheel S T E P 1 A S S E M B L E A N D T H E T R U N K P A R T I T I O N P A N E L S Take the trunk partition panel from Stage 62 and align it with the left side partition panel as shown.
- Page 33 Stage 64: Trunk Panels and Fitting The Spare Wheel S T E P 3 C O M P L E T E A S S E M B LY O F T H E S P A R E W H E E L Place the spare wheel from stage 63 on your worktable with the inside of the rim facing upwards.
- Page 34 Stage 64: Trunk Panels and Fitting The Spare Wheel Stage 64 complete! AGORAMODELS SHELBY SUPER SNAKE...
