Pack 05 | Build Instructions Your Shelby GT500 Super Snake is a finely detailed model replicating every aspect of the original car. From the paint color to the smallest interior details, every piece is precisely reproduced. . In your fifth model pack, you will assemble:...
Page 2
Stage 31: Stabilizer Bar and Lower Suspension Arms In stage 31, you will continue to build the suspension system. S T A G E 3 1 P A R T S L I S T Name Quantity Stabilizer Bar and Lower Suspension Arms Pins Screws TYPE MP03 3 [inc.
Page 3
Stage 31: Stabilizer Bar and Lower Suspension Arms S T E P 1 A T T A C H T H E S T A B I L I Z E R B A R A N D L O W E R S U S P E N S I O N A R M S T O T H E C H A S S I S A S S E M B LY .
Page 4
Stage 31: Stabilizer Bar and Lower Suspension Arms S T E P 2 F I T T H E T I E - R O D A S S E M B LY T O T H E C H A S S I S Turn the Chassis Assembly over again and position the Tie-Rod Assembly completed in Stage 30, onto the chassis as shown.
Page 5
Stage 31: Stabilizer Bar and Lower Suspension Arms Stage 31 complete! AGORAMODELS SHELBY SUPER SNAKE...
Page 6
Stage 32: Attaching the Upper Suspension Arms Construct the Upper Suspension Arms and attach them to the chassis. S T A G E 3 2 P A R T S L I S T Name Quantity Upper Suspension Arms Suspension Arm Supports Pins Screws TYPE MD06 5 [inc.
Page 7
Stage 32: Attaching the Upper Suspension Arms S T E P 1 C O N S T R U C T T H E U P P E R S U S P E N S I O N A R M S Take one of the Upper Suspension Arms and one of the Suspension Arm Supports.
Page 8
Stage 32: Attaching the Upper Suspension Arms S T E P 2 F I X T H E U P P E R S U S P E N S I O N A R M S T O T H E C H A S S I S Take the Chassis Assembly and position the Upper Suspension Arms created in STEP 1 on the side of the chassis as shown.
Page 9
Stage 33: Attaching the Gear Lever to the Front Interior Floor You are now going to start building the front interior of the Shelby Super Snake. S T A G E 3 3 P A R T S L I S T Name Quantity Front Interior Floor...
Page 10
Stage 33: Attaching the Gear Lever to the Front Interior Floor S T E P 1 F I X I N G T H E G E A R L E V E R Position the interior floor on your workbench as shown. Take the Gear Lever and align the lug on the base with the hole in the Floor.
Page 11
Stage 34: Front Side Walls, Pedals and Switches You will continue building the front interior, adding switches and pedals. S T A G E 3 4 P A R T S L I S T Name Quantity Front Floor Right Side Wall Front Floor Left Side Wall Switch Holder Accelerator Pedal Switch...
Page 12
Stage 34: Front Side Walls, Pedals and Switches S T E P 1 F I X T H E S I D E W A L L S T O T H E F R O N T I N T E R I O R F L O O R Take the Front Interior Floor from stage 33 and align the Right Side Wall as shown.
Page 13
Stage 34: Front Side Walls, Pedals and Switches S T E P 2 C O N S T R U C T T H E S W I T C H E S A N D F I X T O T H E F R O N T I N T E R I O R F L O O R Now take the Switch Support Box and position the Accelerator and Brake switches as shown.
Page 14
Stage 34: Front Side Walls, Pedals and Switches S T E P 3 A T T A C H T H E P E D A L S Turn the Floor the right way up and position the Pedals as shown. Note that the brake pedal and the accelerator pedal have tabs.
Page 15
Stage 35: Dashboard And Fuse Cover You are now going to start building the dashboard. S T A G E 3 5 P A R T S L I S T Name Quantity Dashboard Fuse Cover Screws TYPE MP03 2 [inc. 1 spare] Dashboard Fuse Cover Screws...
Page 16
Stage 35: Dashboard And Fuse Cover S T E P 1 A T T A C H T H E F U S E C O V E R T O T H E D A S H B O A R D Align the Dashboard and Fuse Cover as shown in the picture.
Page 17
Stage 35: Dashboard And Fuse Cover Stage 35 complete! This picture shows the Dashboard resting in place on the Front Floor. There may be a carpeted peg or screw in the front floor (inset). This must be removed before positioning the Dashboard. AGORAMODELS SHELBY SUPER SNAKE...
Page 18
Stage 36: Dashboard Trim, Dials and Shelby Badge In this stage you will continue to construct the dashboard. S T A G E 3 6 P A R T S L I S T Name Quantity Adhesive Dials Glass Dial covers Dashboard Trim Dashboard Strip Shelby Badge Support...
Page 19
Stage 36: Dashboard Trim, Dials and Shelby Badge S T E P 1 A T T A C H T H E D I A L A D H E S I V E S T O T H E D A S H B O A R D In picture 1, the adhesive dials have been identified by letters to allow them to be placed in the correct order.
Page 20
Stage 36: Dashboard Trim, Dials and Shelby Badge S T E P 2 P O S I T I O N T H E D I A L G L A S S O N T H E D A S H B O A R D T R I M A N D F I X B O T H T H E D A S H B O A R D T R I M A N D D A S H B O A R D S T R I P T O T H E D A S H B O A R D A S S E M B LY .
Page 21
Stage 36: Dashboard Trim, Dials and Shelby Badge S T E P 3 F I X T H E S H E L B Y S T I C K E R S U P P O R T T O T H E D A S H B O A R D S T R I P Take the Shelby Badge Support and place sticker F into place on the Support.
Page 22
Stage 36: Dashboard Trim, Dials and Shelby Badge Stage 36 complete! AGORAMODELS SHELBY SUPER SNAKE...
Page 23
Stage 37: Central Dials, Car Radio and Glove Compartment You will continue adding more details to the dashboard. S T A G E 3 7 P A R T S L I S T Name Quantity Car Radio Adhesive Dials Central Dial Support Dial Glass Dial Frames...
Page 24
Stage 37: Central Dials, Car Radio and Glove Compartment S T E P 1 A T T A C H T H E C A R R A D I O Align the lugs on the Car Radio with the holes on the Dashboard and press into position.
Page 25
Stage 37: Central Dials, Car Radio and Glove Compartment S T E P 2 C O N S T R U C T T H E C E N T R A L D I A L S Identify the stickers using the letters as indicated in picture 1.
Page 26
Stage 37: Central Dials, Car Radio and Glove Compartment S T E P 3 A T T A C H T H E C E N T R A L D I A L S T O T H E D A S H B O A R D Place the part assembled in step 2 through the central groove on the Dashboard, ensuring that the projecting...
Page 27
Stage 37: Central Dials, Car Radio and Glove Compartment S T E P 5 A T T A C H T H E D A S H B O A R D T O T H E F R O N T I N T E R I O R F L O O R Fit the Dashboard to the Interior Floor by fitting the Dashboard projections over the screw holes as shown.
Page 28
Stage 38: Rear Floor and Front Seat Belts You are now going to attach the front floor to the rear floor and add the front seat belts. S T A G E 3 8 P A R T S L I S T Name Quantity Rear Floor...
Page 29
Stage 38: Rear Floor and Front Seat Belts S T E P 1 F I T T H E F R O N T S E A T B E LT A N C H O R S Align the lugs on the Passenger’s Seat Belt Anchor with the holes on the right side of the Rear Floor as shown.
Page 30
Stage 38: Rear Floor and Front Seat Belts S T E P 3 F I T T H E F R O N T S E A T B E LT S Take one of the Front Seat Belts and align with the groove in the Floor.
Page 31
Stage 38: Rear Floor and Front Seat Belts Stage 38 complete! AGORAMODELS SHELBY SUPER SNAKE...
