  • Page 1 Operators Manual / Manual de uso EN p. 2 19" Electric Mower MEC1218E ES p. 29 Cortadora de césped eléctrica de 19” MEC1218E By Ben Means at 4:43 pm, Dec 06, 2017 MNL_MEC1218E_V1 Read all safety rules and instructions carefully before operating this tool.

  • Page 2: Table Of Contents

    ASSEMBLY OPERATION 17-18 MAINTENANCE 19-23 TROUBLESHOOTING WARRANTY EXPLODED VIEW / PARTS LIST 26-27 NOTES SPECIFICATIONS Electric Mower MEC1218E Voltage 120V~60Hz Electricity 12.5 A Motor Speed 3800 /min Deck Width 19 inch (483mm) Cutting Width 18 inch (457mm) Cutting Height Adjustment 1.4-3.4 inch (35-85mm);...

  • Page 3: Introduction

    INTRODUCTION This product has many features for making its use more pleasant and enjoyable. Safety, performance, and dependability have been given top priority in the design of this product making it easy to maintain and operate. GENERAL SAFETY RULES WARNING READ AND UNDERSTAND ALL INSTRUCTIONS.
  • Page 4 GENERAL SAFETY RULES operating this product. order. removing the grass catcher, or unclogging the discharge guard. children. immediately. Damaged cords increase the risk of electric shock. SW, SOW, STW, STOW, SJW, SJOW, SJTW, or SJTOW.

  • Page 5: Specific Safety Rules

    GENERAL SAFETY RULES be used for this measure of safety. from oil or grease. SPECIFIC SAFETY RULES accessories approved by the manufacturer. accident. direction on slopes. accident. Walk, never run.
  • Page 6 SPECIFIC SAFETY RULES before removing the grass catcher or unclogging the chute. The cutting blade continues to rotate until you are sure the blade has stopped rotating. accidentally. create a risk of serious injury to the user, or damage to the product. authorized service center to avoid risk.

  • Page 7: Symbols

    SYMBOLS Some of the g symbols may be used on this product. Please study them and learn their meaning. Proper interpr roduct better and safer. Volts Voltage Alternating Current Type of current Hertz Watt Hours Time Class II Construction Double-insulated construction Safety Alert Precaution that involves your safety.
  • Page 8 SYMBOLS rds and meanings ar product. SYMBOL SIGNAL MEANING Indicates an imminently hazardous situation, , if not avoided, DANGER: l result in death or serious injury. Indicates a potentially hazardous situation, , if not avoided, WARNING: could result in death or serious injury. Indicates a potentially hazardous situation, , if not avoided, may CAUTION:...

  • Page 9: Electrical

    ELECTRICAL DOUBLE INSULATION insulation. Double insulated tools do not need to be grounded. WARNING The double insulated system is intended to protect the user from shock resulting from a break in the NOTE: ELECTRICAL CONNECTION volts, 60 Hz, AC only (normal household current). Do not operate this product on direct current (DC). EXTENSION CORDS...
  • Page 10 ELECTRICAL Volts Total length of cord feet 120V Ampere rating Ampere rating more than not more than 0 - 6 6 - 10 10 - 12 12 - 16 Not Recommended WARNING result in serious personal injury. WARNING shock resulting in serious injury.

  • Page 11: Features

    FEATURES Fig. 1 KNOW YOUR LAWN MOWER (See Fig 1) The safe use of this product requires an understanding of the information on the product and in this operator’s manual as well as a knowledge of the project you are attempting. Before use of this product, familiarize yourself with all operating features and safety rules.
  • Page 12 FEATURES Unpack This product requires assembly. ■ Carefully remove the product and any accessories from the box. Make sure that all items listed in the packing list are included. Look under the interior bottom carton flaps for any missing small items. ■...

  • Page 13: Assembly

    ASSEMBLY WARNING If any parts are damaged or missing do not operate this product until the parts are replaced. Failure to WARNING Any such alteration or modification is misuse and could result in a hazardous condition leading to possible serious personal injury. WARNING starting and possible serious personal injury.
  • Page 14 ASSEMBLY ASSEMBLING THE COLLECTION BAG (See Figs. 8-9) Your LawnMaster mower comes with a tool-less collection bag. ® To assemble: ■ Check the collection bag before assembling to make sure there is no damage. ■ Pull the collection bag over the steel frame as shown.
  • Page 15 ASSEMBLY ATTACHING/REMOVING THE MULCHING PLUG (See Figs. 11-13) NOTE: Mulch plug MUST be removed if collection bag is used during mowing operation. The mulching plug (7) prevents grass from being collected by blocking the collection chute. This allows the grass clippings to be deposited back on the lawn during cutting. ■...
  • Page 16 ASSEMBLY SETTING CUTTING HEIGHT (See Fig. 15) WARNING Do not at any time make any adjustment to the lawn mower without first stopping the motor and disconnect the plug form power source. When shipped, the rear wheels on the mower are set to a low-cutting position. Before using the mower for the first time, adjust the cutting position to the height best suited for your lawn.

  • Page 17: Operation

    OPERATION WARNING fraction of a second is sufficient to inflict serious injury. WARNING WARNING Do not use any attachments or accessories not recommended by the manufacturer of this product. The use of attachments or accessories not recommended can result in serious personal injury. APPLICATIONS Bale Switch Switch Button...
  • Page 18 OPERATION the cord retainer provided. discharge of the clippings. clippings. any other accumulated debris. MOWING ON A SLOPE (See Fig. 19) direction on slopes. Fig. 19...

  • Page 19: Maintenance

    MAINTENANCE WARNING When servicing, use only identical replacement parts. Use of any other parts may create a hazard or cause product damage. WARNING GENERAL MAINTENANCE various types of commercial solvents and may be damaged by their use. Use clean cloths to remove dirt, dust, oil, grease, etc.
  • Page 20 Failure to heed this warning could result in serious personal injury. REPLACING THE MOWER BLADE (See Figs. 24-25) NOTE: Unplug mower from power supply before performing any maintenance! NOTE: Only use identical replacement blades. LawnMaster mower blade replacement part #RMB1218E. ®...
  • Page 21 MAINTENANCE SHARPENING THE BLADE (See Fig. 26-27) For best mowing performance, the mower blade must be kept sharp. A dull blade does not cut grass evenly and overloads the motor. Under normal circumstances, sharpening the blade twice during the mowing season is usually sufficient. However, if your lawn has sandy soil, more frequent sharpening may be required.
  • Page 22 MAINTENANCE REPLACING WHEELS (See Fig. 28-29) To replace a wheel: NOTE: before replacing a rear wheel, set the mower at the highest position. ■ Disconnect the plug form power supply at first before replacing the wheel. ■ Turn the mower upright. ■...
  • Page 23 MAINTENANCE STORING THE MOWER (See Fig. 30) missing parts. edges of the handle mounting brackets. HANDLE CAM LOCKS UPPER HANDLE LOWER HANDLE ASSEMBLY FIXED PLATE Fig. 30...

  • Page 24: Troubleshooting

    TROUBLESHOOTING Problem Possible Cause Solution Carriage bolts not seated properly. Adjust the height of the handle and make sure the carriage bolts are seated properly. Cam locks not tightened. Tighten cam locks. Reconnect the cord and use the cord retainer to keep the cord close to the motor/blade control.

  • Page 25: Warranty

    WARRANTY under normal household use. If product is to be used for commercial, industrial or rental use, a 30 Warranty does not apply to defects due to direct or indirect abuse, negligence, misuse, accidents, repairs or alterations and lack of maintenance. Please keep your (866) 384-8432.

  • Page 26: Exploded View / Parts List

    EXPLODED VIEW / PARTS LIST...
  • Page 27 EXPLODED VIEW / PARTS LIST CLMFT6018A MANUAL PARTS LIST Key Number Part Number Description Quantity 111242101 Motor cover handle assembly 111242102 Motor cover assembly 111242103 Motor assembly 111007103 Drive belt 111198110 Side discharge door assembly 111008129 Cable clamp assembly 111198111 Side discharge chute 111242104 Wheel assembly (235mm)

  • Page 28: Notes

    NOTES...
