Connect to the EIA Console Port
Note Disconnect the router console terminal before uninstalling the driver.
SUMMARY STEPS
1. Choose Start > Control Panel > Add or Remove Programs.
2. Scroll to Windows Driver Package - Exar corporation (xrusbser) Ports and click Remove. The
Program Maintenance window is displayed.
3. Click Yes to uninstall the driver.
DETAILED STEPS
Step 1
Choose Start > Control Panel > Add or Remove Programs.
Step 2 Scroll to Windows Driver Package - Exar corporation (xrusbser) Ports and click Remove. The Program Maintenance
window is displayed.
Step 3 Click Yes to uninstall the driver.
Connect to the EIA Console Port
Note
The US-to-RJ45 adapter cable and the DB9 console cable are not included with the router; they can be ordered
separately from Cisco.
Note
The serial console cable kit is not included with the router; it is ordered separately.
To connect a terminal to the EIA Console port on the router, follow these steps:
Step 1 Connect the USB end of the USB-to RJ-45 cable to the EIA Console port.
Step 2
Connect the RJ-45 end of the DB-9 adapter cable to the USB-to RJ-45 cable, as shown in the figure below.
