DUPLOMATIC E.M.6427 RELEASE 7.1 05-03 SM-TURRETS CONTROL UNIT DDC1-12-H**/22 CONTROL UNIT DDC1-30/12-H**/20 Software: SFW062G002, SFW062G003, SFW062G006, SFW062G012, SFW062I238 SFW062I239, SFW062I229, SFW062I245, SFW062I003 INSTALLATION MANUAL INSTRUCTIONS FOR ELECTRICAL CONNECTIONS OF INTEGRATED CONTROL UNIT Correspondence between electronic unit code and software Electronic unit...
OPERATING FUNCTION N °7: SAFETY DIAGNOSTIC ALARMS AND WARNINGS EXTENDED ALARM DESCRIPTION/TROUBLESHOOTING The information described in this manual may be subject to variations due to technical modifications. DUPLOMATIC S.p.A. reserves the right to modify the contents of this manual without prior notice. 6427071-230-en...
1. GENERAL INFORMATION The Duplomatic control unit is a compact system that controls all functions regarding positioning and driving of the SM* turrets Duplomatic. The interfacing to the lathe is powerful and simplified for an easy installation. Serial line RS232 is set for diagnostic and remote control by PC.
DUPLOMATIC E.M.6427 RELEASE 7.1 05-03 CHARACTERISTICS OF THE CONTROL UNIT TYPE DDC1-30/12-K**/22 CHARACTERISTICS OF THE CONTROL UNIT TYPE DDC1-12-H**/20 • Best path research. • External selection of rotation direction. • Automatic reference search. • Parity control on position code. •...
DUPLOMATIC E.M.6427 RELEASE 7.1 05-03 3. INTERFACING TO CNC OPERATING FUNCTIONS The control unit offers several operating functions (also called MODES). Setting MODE01, MODE02, and MODE03 signals can make the selection of the operating functions. N° OPERATING INPUTS DESCRIPTION FUNCTIONS...
DUPLOMATIC E.M.6427 RELEASE 7.1 05-03 OPERATING FUNCTIONS DESCRIPTION AUTOMATIC OPERATING FUNCTIONS (1,2,3) • Set the code of the position required. • Wait until the position code output is stable (it depends on what type of PLC/CNC outputs are used - relay, static…).
Page 10
DUPLOMATIC E.M.6427 RELEASE 7.1 05-03 INDEXD SIGNAL The INDEXD signal must be used with the LOCKED signal to detect the end of cycle of the turret and can be ignored once the turret is locked. The INDEXD output goes and stay LOW also when the emergency mode is set and if the three- phase power supply is OFF.
DUPLOMATIC E.M.6427 RELEASE 7.1 05-03 OPERATING FUNCTION N°0: EMERGENCY / RESET OPERATING FUNCTION N°0 INPUTS MODE01 MODE02 MODE03 Emergency/reset This operating function has two purposes: 1) Stop all turret movement (EMERGENCY). 2) Acknowledge all alarms, if they are present (RESET).
(It must stay ON for more than 30 ms). Locking and unlocking don’t require PSTART signal. OPERATING FUNCTION N°6: MAINTENANCE Can be used to test the functionality of the control unit with RS232 and a special software for Windows on a PC (SERVICE DUPLOMATIC). 6427071-230-en...
DUPLOMATIC E.M.6427 RELEASE 7.1 05-03 OPERATING FUNCTION N °7: SAFETY The standard behaviour of the turret can be changed in order to allow the turret to work even if there are problems mainly on proximity switches. WARNING: all the functions are intended to be used only in case of effective problems.
Page 14
DUPLOMATIC E.M.6427 RELEASE 7.1 05-03 (6) In this case a slow SSI - like protocol (Serial Synchronous Interface) is enabled using the ALBITs outputs. SIGNAL READY CLOCK DATA ALBIT1 ALBIT2 ALBIT4 OUTPUT The READY signal is independent an is ON if the turret is OK.
Power off causes the reset of the active alarm. A better identification of the alarm codes is possible by a PC with RS232 interface and a Duplomatic diagnostic software. available Please refer to the EXTENDED ALARM DESCRIPTION to get a more complete description of the alarm and to have information about troubleshooting.
DUPLOMATIC E.M.6427 RELEASE 7.1 05-03 EXTENDED ALARM DESCRIPTION/TROUBLESHOOTING ALARM Description CODE Fault in internal supply: check the 230 V auxiliary supply. Drop on the Three-Phase voltage during tool change. Check the Three-Phase voltage. (only SW rel I) Overvoltage: - Check all external three-phase supplies.
Page 17
-the 24 V DC supply is delayed for more than 500 ms in respect of the 230 V AC auxiliary supply (the configuration has not been loaded correctly). Note: the code number is memorised by the control unit and can be read with a Duplomatic diagnostic software installed on a PC with the RS232 interface.
