4.

Technical data

Technical data
KBN
Pressure outlet
Free passage
Power cable
Cable length
Weight
Voltage/frequency
Type of current
Nominal current
Motor power P1
Speed
Motor protection
Plug
Protection class
Motor insulation class
Motor protection activation temperature
Maximum total head
Maximum immersion depth
Fluid temperature
Materials
Pump housing
Impeller
Seals
Motor shaft
Pump curve – see page 28, figure 2.
Dimensions – see page 29, figure 3
The noise emission value is less than 70 dB (A).
TP12N
G 1¼" female thread
G 1¼" female thread adaptor
G ¾" male thread adaptor; hose connection 1" and ¾"
12 mm
H07RN8-F 3G 1.0
10 m
3.8 kg
1 x 230 V / 50 Hz
Alternating current
1.6 A
0.36 kW
2900 r/min
Temperature limiter built into the winding
Schuko plug
IP68
B
120 °C
6.0 m
10 m
Max. 40 °C, 60 °C for 5 minutes
Polypropylene
Polyamide
NBR
Stainless steel 1.4057 (AISI 431)
