Page 1: Quick Start Guide
P-660RU-Tx v2 ADSL2+ Ethernet / USB Router Quick Start Guide Version 3.40 Edition 4 10/2008... - Page 2 P-660RU-Tx v2 Quick Start Guide Overview The P-660RU-Tx v2 is an ADSL router with both USB and Ethernet ports. See your User’s Guide for background information on all features. This Quick Start Guide shows you how to: • Connect the hardware.
-
Page 3: Hardware Connections
P-660RU-Tx v2 Quick Start Guide 1 Hardware Connections There are two ways to connect your computer or computer network to the P-660RU-Tx v2: Option A: Connect via Ethernet. See Option B: Connect via USB (you will need to install the USB driver). - Page 4 P-660RU-Tx v2 starts up and stays on once it is ready. • The light is on when the P-660RU-Tx v2 has a DSL con- nection. • The light is on when you are able to access the Internet and blinks when the P-660RU-Tx v2 is sending or receiving data.
- Page 5 P-660RU-Tx v2 Quick Start Guide If any of these lights are not on, check your connections and inspect your cables for damage. If the lights are still off, contact your local vendor. Option B: Connect via USB...
- Page 6 5 Look at the lights on the front panel. • The light blinks while your P-660RU-Tx v2 starts up and stays on once it is ready. • The light is on when the P-660RU-Tx v2 has a DSL con- nection.
-
Page 7: System Requirements
If you want to connect to the Internet through the P-660RU-Tx v2's USB port, install the USB driver before you connect the P-660RU-Tx v2 to the USB port. Follow the steps for your operating system to install the USB driver. - Page 8 P-660RU-Tx v2 Quick Start Guide 3 Click the Setup icon on the main screen. 4 Select the Windows version of your computer. 5 An install warning may appear in the Windows Vista OS. Click Allow to continue. 6 Click Next in the Welcome screen to begin the USB Installation Wizard.
- Page 9 P-660RU-Tx v2 Quick Start Guide Macintosh Computer System Requirements • Macintosh operating system versions 10.1, 10.2 and 10.3. • An available USB port Procedures 1 Save your work and close all applications. 2 Insert the included CD. A CD’s icon automatically displays on the desktop.
- Page 10 P-660RU-Tx v2 Quick Start Guide 5 Double-click one of the following. If you selected MAC10.1, double click the P-660RU-T icon. If you selected MAC 10.2_10.3, double click the P-660RU- Tx.dmg icon.
-
Page 11: Connection Setup: Wizard
Web Configurator Wizard. You should have the information from your Internet Service Provider (ISP). 1 Open your browser and enter the P-660RU-Tx v2's IP address (default 192.168.1.1) as the URL. If your browser does not display a login screen, see Troubleshooting for... - Page 12 P-660RU-Tx v2 Quick Start Guide 2 Enter the admin password admin (default). Click Login. 3 Select Go to Wizard setup. Click Apply. 4 Click INTERNET SETUP.
- Page 13 P-660RU-Tx v2 Quick Start Guide 5 Follow the instructions in the wizard. Enter your Internet connection information exactly as provided by your ISP. If you do not see the following screen, go to section 3. 3 Connection Setup: Manual Use this section to set up your Internet connection manually if you do not see the ISP Parameters for Internet Access screen when you run the wizard (see section 2).
- Page 14 P-660RU-Tx v2 Quick Start Guide 2 Select Go to Advanced setup. Click Apply. 3 The Status screen appears. Click Network > WAN in the navigation panel on the left of the screen. 4 The Internet Connection screen appears. Enter the information exactly as provided by your ISP and click Apply.
- Page 15 P-660RU-Tx v2 Quick Start Guide The fields available in this screen depend on the Mode you select. 5 If you still cannot access the Internet, see Troubleshooting and/or contact your Internet Service Provider (ISP) for assistance.
-
Page 16: Troubleshooting
Troubleshooting 1 If you want to verify your USB installation, • Check the status of the P-660RU-Tx v2 in the Device Man- ager window. Click Start > Settings > Control Panel > Sys- tem > Hardware and then click Device Manager. (Steps may vary depending on the version of Windows.) - Page 17 If you cannot access the Internet after you take the steps above, either try the following or contact your ISP: E) Turn your P-660RU-Tx v2 off and on. Open your Internet browser if it is not already open. Let the P-660RU-Tx v2 complete the DSL connection test (this may take several minutes).
- Page 18 DHCP is set to None. Your ISP gives your computer an IP address directly. If you want to access the P-660RU-Tx v2 again, you need to use a static IP address in the same subnet as your P-660RU- Tx v2 (the P-660RU-Tx v2’s default IP address is...
