Cyclo BBB 4 Series: Taconite Seal Lubrication Procedure
I ntroduction
0 B
Taconite seals may be used in high dust operating environments. They use a grease purging system to prevent outside contaminants
from entering the speed reducer/gearmotor. Figure 1 below details the taconite seal assembly as utilized in the 4-Series Bevel
Buddybox.
Oil Seal
(grease retainer)
P rocedure
1 B
Please follow these instructions to maintain lubrication of the Taconite Seal system:
a. Unless otherwise specified, the Taconite output seals are each packed with NLGI #2 EP mineral grease prior to unit
shipment from the factory location.
b. Grease does not need to be added to the seals prior to unit start-up.
c. Add grease to the seals according to the guidelines indicated in Table 1. Refer to Table 2 for recommended greases.
Table 1: Lubrication Cycle
Output Shaft RPM
>200
Please note that a highly contaminated environment may require a more frequent lubrication cycle.
d. If the unit will n ot
U
seals to prevent dry-out. Before starting the unit, check the seals' integrity and replace if required. If seal replacement is
required, purge and add grease to the newly installed seals prior to unit operation.
www.sumitomodrive.com
Figure 1: Taconite Seal Assembly
Hours of Operation
5,000
be operated for a period greater than 6 months, apply a thin layer of grease to the outside surface of the
U
Grease Nipple
Grease In
Seal Plate
Oil Seal
(grease retainer)
Grease Out
Grease Purge Fitting
Author: T.Bobak; Review: Dan Rosseljong
EDOC1-12-024
