- Page 1 MANUAL CONTROL SYSTEMS...
-
Page 2: Table Of Contents
Prisma Light Remote .................................... Prisma Light Detect ....................................Prisma Light Nema ....................................... Prisma Light SR .......................................... Remote control ........................................Detect, Android-app 8-23 .................................. Troubleshooting Back cover ..............................Warranty Back cover ........................................Support, contact information Back cover ................Prisma Light | prismatibro.se... -
Page 3: Introduction Prisma Light Constant
If you want to make any changes to the power output you will have to send the luminaire back to PrismaTibro. Prisma Light DALI With a DALI-driver it is possible to change the power output and night reduction after the luminaire has been installed. -
Page 4: Prisma Light Remote
Prisma Light Detect Our most powerful system: Detect, light when it is needed. Communication Accessories • Between luminaries • Gateway • Between luminaries and those who need light • Dongle • Between luminaries and you • Android-app Prisma Light | prismatibro.se... -
Page 5: Prisma Light Nema
The luminaire have a built in SR-driver using the Zhaga-standard. On the outside a SR-socket is mounted – easy to connect the external node when you have choosen how to control your installation. Remove the dust cap and connect your external node. prismatibro.se | Prisma Light... - Page 6 STOPP* The setting is saved. DIMMING LEVEL + Power, 2 digits (e.g. 05) + Reponse: Blink, blink The setting is saved. POWER + Power, 2 digits (e.g. 20) + Response: Blink, blink The setting is saved. Prisma Light | prismatibro.se...
- Page 7 Unlock the luminaire to be able to change the settings. START STOP Requires PIN code that can be LEVEL obtained through support@prismatibro.se ON/OFF Switch on or off the luminaire. WATT NIVÅ (Level) The power during Prisma Moon- light. STOPP (Stop) Hours until Prisma Moonlight is stopped.
- Page 8 • Company name • End customer • Project Start dongle Press the button, release when it turns white. It will then go from green to blue. When it white blue it is ready turns to use. Prisma Light | prismatibro.se...
- Page 9 In this example: BA:52 Select project You can have access to several projects. Choose the project in the list that you want to look at this time. In this example: Showroom prismatibro.se | Prisma Light...
- Page 10 In this case we choose to call it ”Gata 4” NOTE! The installation need to have power on. Add luminaries to the site: Press on the ”lock”. When it is unlocked a will be shown. Press to add luminaire. Prisma Light | prismatibro.se...
- Page 11 Repeat item 4 and 5 until all lumniaries are added to the site. All luminaries that are added to the site will disapear from the list. If the area is big you might have to move to get contact with all luminaries. prismatibro.se | Prisma Light...
- Page 12 ANDROID-APP Create site Create links automatically Send link Remember to press ”Save” Remove marked luminaire Prisma Light | prismatibro.se...
- Page 13 ANDROID-APP End create site It is possible to create a link on your own for example when you come to an intersection. Important: You don’t create a loop Finally: Press ”Lock” prismatibro.se | Prisma Light...
- Page 14 Select by pressing the name of site you want to work with. A map of that site will be shown, picture below. Symbols Prisma Light Wireless link Unlock to make changes Gateway Your position Zoom in site Prisma Light | prismatibro.se...
- Page 15 The luminarie will also blink to say that it is ready. More info A click in the circle with the ”i” will show the picture below. Select all ”Select all” can be used to configure, not to show information. prismatibro.se | Prisma Light...
- Page 16 • ID-number • Mac-adress • Software • Hardware Measurements • Voltage • Current • Power • Power factor • Temperature Note: High temperature because this luminaire is mounted indoors. • Average Signal Quality • Instant Signal Quality Prisma Light | prismatibro.se...
- Page 17 Note: This site is mounted in our factory and is rarely turned off • ON-timed • Motion, detection • Temperature: Min/Max/Avg • Power used • Lamp cycles • Lamp ON time Continue on the next page..prismatibro.se | Prisma Light...
- Page 18 Show the statistics since the site was mounted Note: This site is mounted in our factory and is rarely turned off • Total ON time • Motion, detection • Temperature: Min/Max/Avg • Power used • Lamp cycles • Lamp ON time Prisma Light | prismatibro.se...
- Page 19 • Pole height (not mandatory) • Power when nobody is • present • Indicate: If you press, the • luminaire you are configuring • will start to blink. Motion: Detect of presence prismatibro.se | Prisma Light...
- Page 20 Press send to save the setting. Power at absence Power when no one is there Swipe until the right percent is showing. Press ”Send” to save the setting. Prisma Light | prismatibro.se...
- Page 21 • light (Dim Down) • The amount of neigbouring • luminaries that react in each • direction – ”Motion range”. Power at presence Swipe until the right percent is showing. Press ”Send” to save the setting prismatibro.se | Prisma Light...
- Page 22 ANDROID-APP Factory settings Configure luminaire predefined. Choose from the list If you wish to return to factory settings choose an alternative from the list. Manual settings Configure luminaire manually Description can be found on page 19-21. Prisma Light | prismatibro.se...
- Page 23 All at the same time Select all. Slide to the right to choose to make settings for the entire site at the same time. Show list Press ”List” to change from map view to list view. prismatibro.se | Prisma Light...
-
Page 24: Troubleshooting
Or scan the QR-code For complete warranty terms visit our website www.prismatibro.se or call +46 504-400 40 or send an e-mail to support@prismatibro.se DOWNLOAD DOCUMENTS This and a lot of other documents can be downloaded from: www.prismatibro.se...
