Summary of Contents for Prismatibro Prisma Light Eliott
- Page 1 MANUAL MOUNTING AND INSTALLATION...
-
Page 2: Product Facts
PRODUCT FACTS PRODUCT DESCRIPTION Prisma Light Eliott is a luminaire produced in Sweden for street light with LED-technology. Add: pole fitting and cable. AREA OF USE Outdoors: Main roads, urban roads, bicycle paths, parking lots, industrial areas, skiing tracks. MOUNTING HEIGHT... -
Page 3: Installation
That is way it is two item numbers for the same fitting. ±10° ±10° Item Item 353-0004 353-0003 Mounting The fitting is mounted on the pole and the two screws are tightened Using torque: 8Nm +/- 2 Nm. prismatibro.se | Prisma Light... -
Page 4: Electrical Installation
ELECTRICAL INSTALLATION Only 230 V • Prisma Light Eliott Constant • Prisma Light Eliott Remote • Prisma Light Eliott Detect The luminaire should not be mounted or demounted with power on. Supply voltage 110-230 V AC, 50 Hz. Wattage 5-90W depending on model 1. - Page 5 Instructions on next page. the factory setting that the customer Manual can also be wanted when ordered. downloaded from: • Prisma Light Eliott has a circuit board www.prismatibro.se with built in IR-communication. Prisma Light Detect DEPLOYMENT • Power on the luminaire When it starts up the luminaire will blink as it calibrates.
-
Page 6: Gateway Installation
Connect the power cable to the backside of the Gateway: Press down the coupling ring, and keep turning the ring (clock wise) until you feel a ”click”. Now the connector is locked. Mount the Gateway to the light cabinet - use the supplied screws. Prisma Light | prismatibro.se... - Page 7 Connect the power cable to backside of the Gateway: Press down the coupling ring, and keep turning the ring (clock wise) until you feel a ”click”. Now the connector is locked. Mount the Gateway: Use the supplied screws. prismatibro.se | Prisma Light...
-
Page 8: Warranty
Or scan the QR-code For complete warranty terms visit our website www.prismatibro.se or call +46 504-400 40 or send an e-mail to support@prismatibro.se RECYCLING AND PACKAGING The packaging material is reuseable and/or recyclable.
