Summary of Contents for Prismatibro Prisma Light Elton
- Page 1 MANUAL MOUNTING AND INSTALLATION...
-
Page 2: Table Of Contents
CONTENT Product facts ............................................... Mechanical installation ................................ Electrical Installation ....................................Deployment Prisma Light Elton DALI ................................Prisma Light Elton Remote ............................. Prisma Light Elton Detect ..............................Prisma Light Elton Nema ............................... Prisma Light Elton SR ..................................Gateway installation 10-11 ................................ - Page 3 PRODUCT FACTS PRODUCT DESCRIPTION Prisma Light Elton is a luminaire with LED-technology. AREA OF USE Outdoors: Main roads, urban roads, bicycle paths, parking lots, industrial areas, skiing tracks, highways, harbours MOUNTING HEIGHT Maximum 20 meters WEIGHT, kg Model Prisma Light Elton 1-S...
-
Page 4: Mechanical Installation
Pole fitting The luminaire can be mounted on a pole top as well as a pole with arm. The picture below show how you release, turn and adjust from a pole top to a pole with arm. Prisma Light | prismatibro.se... - Page 5 Adjust the angle Use you hands or a screwdriver mith maximum torque: 8Nm. ±° ±10° Prisma Light Elton 1-S ±10° Prisma Light Elton 1-M ±15° Prisma Light Elton 1-L ±15° Prisma Light Elton 1-XL Mount on pole top or arm Use you hands or a screwdriver mith maximum torque: 8Nm +/- 2 Nm prismatibro.se | Prisma Light...
- Page 6 OPEN Prisma Light Elton 1-S Grab the clasp in the front of the luminaire, pull up. The lid is now easy to lift up and let it rest in full open position. Prisma Light | prismatibro.se...
- Page 7 OPEN Prisma Light Elton 1-M Prisma Light Elton 1-L Prisma Light Elton 1-XL Grab the clasps at both sides of the luminaire, pull up. The upper part with all the electronics is now easy to lift and to let it rest in full open position.
-
Page 8: Electrical Installation
ELECTRICAL INSTALLATION 230 V CLASS II 230 V CLASS I • Prisma Light Elton DALI • Prisma Light Elton DALI • Prisma Light Elton Remote • Prisma Light Elton SR • Prisma Light Elton Detect • Prisma Light Elton Nema •... - Page 9 • Prisma Light Elton should now have Manual can be downloaded from: the factory setting that the customer www.prismatibro.se wanted when ordered. • Prisma Light Elton has a PCB with built in IR-communication. Prisma Light Detect INSTALLATION • Power on the luminaire When it starts up the luminaire will blink as it calibrates it’s self.
-
Page 10: Gateway Installation
Connect the power cable to the backside of the Gateway: Press down the coupling ring, and keep turning the ring (clock wise) until you feel a ”click”. Now the connector is locked. Mount the Gateway to the light cabinet - use the supplied screws. Prisma Light | prismatibro.se... - Page 11 Connect the power cable to backside of the Gateway: Press down the coupling ring, and keep turning the ring (clock wise) until you feel a ”click”. Now the connector is locked. Mount the Gateway: Use the supplied screws. prismatibro.se | Prisma Light...
-
Page 12: Troubleshooting
More help! the problem. prismatibro.se/en/error-el/ For complete warranty visit our Or scan the QR-code website www.prismatibro.se or call +46 504-400 40 or send an e-mail to support@prismatibro.se RECYCLING AND PACKAGING The packaging material is reuseable and/or recyclable. DOWNLOAD DOCUMENTS...
