below to the dethatcher in order to familiarize yourself with the location of the various controls and adjustments. Save this manual
for future reference and reread it prior to each dethatching session.
1.
2. Safety lock button
3. Extension cord restraint holder
4. Upper handle
5. Upper handle knob and bolt (2)
6. Appliance cord
7.
8. Cable clip (2)
9. Lower handle knob and bolt (2)
10. Thatch bag cover
11. Lower handle bar (2)
12. Thatch collection bag
13. Rear wheel (2)
14. Front wheel (2)
15. Raking depth adjustment lever
16. Air vent

Technical Data

age 1
Depth Adjustment 5-position
*Note: The negative raking depth indicates that the tines are raking below the horizon (i.e. penetrating the soil layer).
1
2
3
5
8
9
12
13
14
4
7
6
15 16
(0.5 mm thick)
10
11
