Technical Specifications
Power supply
CR2032 battery
Interfaces
Loxone Air:
868MHz (SRD Band Europe),
4 channels available
915MHz (ISM Band Region 2),
10 channels available
max. Power 3.16mW
Sensor
Reed contact
Ambient temperature
0 ... 55°C / 32 ... 131°F
Battery lifetime
up to 2 years
Humidtiy
max. 95% r.H. (non condensing)
Learn button
can also be used as a push
button
IP20
Safety rating
This device is free of main-
Maintenance & Cleaning
tenance and may only be
cleaned with a dry cloth.
Need Help?
loxone.com/support
Loxone Electronics GmbH
Smart Home 1
4154 Kollerschlag
Austria
loxone.com
Door &
Window
Contact
Air
Part No: 100210 (white)
Part No: 100213 (anthracite)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for LOXONE Door & Window Contact Air
Summary of Contents for LOXONE Door & Window Contact Air
- Page 1 IP20 Safety rating Contact This device is free of main- Maintenance & Cleaning tenance and may only be Loxone Electronics GmbH cleaned with a dry cloth. Smart Home 1 4154 Kollerschlag Austria Part No: 100210 (white) Part No: 100213 (anthracite)
- Page 2 About the product The Loxone Window & Door Contact will quickly detect any open windows or doors in your smart home and similar non Magnet safety critical applications. Features • 1 reed contact • 1 push button Installation & electrical connection If the device is not installed according to manufacturers guidelines the protection of the device may be affected.
