Page 1: Quick Installation Guide
ZyAIR B-122 CardBus 11Mbps Wireless LAN Card Quick Installation Guide Version 1.00 December 2003... -
Page 2: Important Note
Important Note Federal Communications Commission (FCC) Interference Statement The Wireless LAN Adapter has been tested to the FCC exposure requirements (Specific Absorption Rate). The equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment, under 47 CFR 2.1093 paragraph (d) (2). This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. -
Page 3: About Your Zyair
About Your ZyAIR The ZyAIR is an IEEE 802.11b compliant wireless LAN PC card that fits into any 32-bit CardBus slots. Its maximum 11 Mbps data rate, which gives Ethernet equivalent speed, is ideal in the corporate or home environment. 1. - Page 4 2. Click Next to accept the default file location or click Browse to select an alternate folder. 3. If a warning window displays, click Yes (Windows 2000) or Continue Anyway (Windows XP). 4. Windows 2000/XP: Click Finish to complete the installation. Windows 98 SE/Me: Click Finish to restart the computer.
- Page 5 5. Locate an available CardBus slot on the computer. 6. With the pin connectors facing the slot and the LED side facing up, slide the ZyAIR into the slot. The LEDs turn on if the ZyAIR is properly inserted. Never bend, force or twist the ZyAIR into the slot. 7.
-
Page 6: Led Display
If the ZyAIR Utility icon displays, the ZyAIR is installed properly. Refer to the ZyAIR Utility User’s Guide to configure LINK The following table describes the LEDs on the ZyAIR. COLOR STATUS Blue Blinking LINK Blue Blinking the ZyAIR. LED Display DESCRIPTION The ZyAIR is receiving or sending data. -
Page 7: Troubleshooting
PROBLEM Windows does not Make sure the ZyAIR is inserted into the computer PCMCIA slot auto-detect the properly and then restart your computer. Check the LEDs on ZyAIR. the ZyAIR. Perform a hardware scan by clicking Start, Settings, Control Panel and double-clicking Add/Remove Hardware. (Steps may vary depending on the version of Windows).
