- Page 1 GLC1320G-55 Fiber-based, Gigabit Ethernet Line Card Version 4.02 Edition 1, 6/2013 Quick Start Guide User’s Guide www.zyxel.com Copyright © 2013 ZyXEL Communications Corporation...
- Page 2 • MSC1024GB and MSC1224GB Management Switch Card User’s Guides These user’s guides cover the configuration of your IES-5000 or IES-6000. Refer to these user’s guides for information on your GLC1320G-55’s default settings. • ZyXEL Web Site Please refer to www.zyxel.com for additional support documentation and product certifications.
-
Page 3: Contents Overview
Contents Overview Contents Overview Introducing the GLC1320G-55 ........................7 Product Specifications ..........................15 Troubleshooting ............................19 GLC1320G-55 User’s Guide... - Page 4 Contents Overview GLC1320G-55 User’s Guide...
-
Page 5: Table Of Contents
Table of Contents Table of Contents Contents Overview ........................3 Table of Contents ........................5 Chapter 1 Introducing the GLC1320G-55 ....................7 1.1 GLC1320G-55 Overview ......................7 1.2 Features ..........................7 1.3 Front Panel ..........................12 1.4 Ports and LEDs ........................13 1.4.1 Ports ...........................13 1.4.2 LEDs ..........................13... - Page 6 Table of Contents GLC1320G-55 User’s Guide...
-
Page 7: Introducing The Glc1320G-55
Introducing the GLC1320G-55 1.1 GLC1320G-55 Overview The GLC1320G-55 is a Gigabit Ethernet Line Card with 20 SFP slot connector slots for fiber-based SFP (mini-GBIC) transceivers (16 for SFP transceiver and 4 for CSFP/SFP). It connects through fiber-optic cables to other Ethernet switches that support fiber connections (like the FSG1100HN, GS2200-8 or FMG3024/3025) located at the subscriber’s premises. - Page 8 Subnet based VLAN allows you to group traffic into logical VLANs based on the source IP subnet you specify. When a frame is received on a port, the GLC1320G-55 checks if a tag is added already and the IP subnet it came from. The untagged packets from the same IP subnet are then placed in the same subnet based VLAN.
- Page 9 Alarm LED An ALM (alarm) LED lights when the GLC1320G-55 is overheated, the voltage readings are outside the tolerance levels, a fan fails, or another alarm with a severity level of MAJOR or CRITICAL occurs.
- Page 10 IGMP multicast servers. IGMP Statistics The GLC1320G-55 records the number of active users in an IGMP multicast channel (multicast group). The GLC1320G-55 also records IGMP message statistics on a per port basis to ease management and troubleshooting. GLC1320G-55 User’s Guide...
- Page 11 Chapter 1 Introducing the GLC1320G-55 IGMP Message Rate Limiting The GLC1320G-55 can limit how many IGMP message packets a subscriber can send per second. This prevents subscribers from flooding the multicast server. Static Multicast Use static multicast to allow incoming frames based on multicast MAC address(es) that you specify.
-
Page 12: Front Panel
Chapter 1 Introducing the GLC1320G-55 Anti-IP Address Spoofing With DHCP snooping, the GLC1320G-55 records which IP addresses are assigned on each port. The GLC1320G-55 drops packets from a device using a different IP address. Anti-MAC Address Spoofing The GLC1320G-55 checks to make sure the MAC addresses of the devices connected to the subscriber ports are not the same as MAC addresses of devices connected to the Ethernet network. -
Page 13: Ports And Leds
MSC. 1-16 These are slots for SFP transceivers. 17/21-20/24 These are slots for CSFP/SFP transceivers. 1.4.2 LEDs The following table describes the LED indicators on the front panel of the GLC1320G-55. Table 2 LED Descriptions COLOR STATUS DESCRIPTION Green The line card is turned on. - Page 14 Chapter 1 Introducing the GLC1320G-55 GLC1320G-55 User’s Guide...
-
Page 15: Product Specifications
1000BASE-SX (MMF with link span up to 550m) 1000BASE-LX (SMF with link span up to 20km) 1000BASE-LHX (SMF with link span up to 40km) Compatible CSFP 1000BASE-BX10-U (SMF with link span up to 20km) Transceivers 1000BASE-BX10-D (SMF with link span up to 20km) GLC1320G-55 User’s Guide... - Page 16 MAC Count Limit • Rate Limiting • Loop Guard • Subnet Based VLAN • xVLAN This table lists the standards the GLC1320G-55 supports. Table 4 Supported Standards STANDARD DESCRIPTION RFC 867 Daytime protocol RFC 868 Time protocol RFC 1305 Network Time Protocol (NTP)
-
Page 17: Firmware Naming Conventions
"0" is this firmware's release number. This varies as new firmware is released. Your firmware's release number may not match what is displayed in this User's Guide. 2.3 Console Cable Pin Assignments The following diagram and chart show the pin assignments of the console cable. GLC1320G-55 User’s Guide... - Page 18 Chapter 2 Product Specifications Figure 3 Console Cable Mini RJ-11 Male Connector Table 5 Console Cable Connector Pin Assignments MINI RJ-11 MALE Pin 2: TXD Pin 3: RXD Pin 4: GND GLC1320G-55 User’s Guide...
-
Page 19: Chapter 3 Troubleshooting
Table 7 ALM LED Troubleshooting STEPS CORRECTIVE ACTION Use the command to verify the cause of the alarm. See step 2 sys monitor status if the unit is overheated, and step 3 if the voltages are out of the allowed ranges. GLC1320G-55 User’s Guide... -
Page 20: Data Transmission
SFP slot or the configuration for the SFP slot. If using a different slot does not work, try a different Ethernet switch with the original slot. 3.3 Local Server The computer behind an Ethernet switch cannot access a local server connected to the line card. GLC1320G-55 User’s Guide... -
Page 21: Management And Configuration
Debug Mode within 3 seconds To upload the configuration file, do the following: Type atlc after the Enter Debug Mode message. Wait for the Starting XMODEM upload message before activating XMODEM upload on your terminal. GLC1320G-55 User’s Guide... -
Page 22: Uploading The Firmware Via Boot Commands
Usually you should use FTP with the MSC to upload the line card’s firmware. If you cannot manage the line card from the MSC, use the following procedure to upload firmware to the line card. Obtain the firmware file, unzip it and save it in a folder on your computer. GLC1320G-55 User’s Guide... - Page 23 This is an example Xmodem configuration upload using HyperTerminal. Click Transfer, then Send File to display the following screen. Figure 5 Example Xmodem Upload Type the firmware file's location, or click Browse to search for it. Choose the 1K Xmodem protocol. Then click Send. GLC1320G-55 User’s Guide...
- Page 24 Now, console speed will be changed to 115200 bps atur Starting XMODEM upload (CRC mode)..CCCCCCCC Total 2003968 bytes received. Erasing..................................................................................................System Reboot... Console speed will be changed to 9600 bps GLC1320G-55 User’s Guide...
-
Page 25: Appendix A Legal Information
ZyXEL Communications Corporation. Published by ZyXEL Communications Corporation. All rights reserved. - Page 26 To obtain the services of this warranty, contact your vendor. You may also refer to the warranty policy for the region in which you bought the device at http://www.zyxel.com/web/ support_warranty_info.php. GLC1320G-55 User’s Guide...
- Page 27 Cover empty slots with slot covers. "PRODUCT COMPLIES WITH 21 CFR 1040.10 AND 1040.11" "PRODUIT CONFORME SELON 21CFR 1040.10 ET 1040.11". CLASS 1 LASER PRODUCT APPAREIL À LASER DE CLASSE 1 This product is recyclable. Dispose of it properly. GLC1320G-55 User’s Guide...
- Page 28 Appendix A Legal Information GLC1320G-55 User’s Guide...
-
Page 29: Index
MAC count filter DHCP Relay Option82 MAC count limit DHCP snooping MAC filter disclaimer multicast bandwidth control double-tagged frames multicast group limit Multicast VLAN MVLAN error log packet filter policy port isolation FCC interference statement product registration GLC1320G-55 User’s Guide... - Page 30 SYS LED system error log Telco-50 connector pin assignments terminal emulation Transparent LAN Service (TLS) USER Telco-50 connectors VDSL profile VLAN VLAN Stacking VLAN stacking VT100 GLC1320G-55 User’s Guide...
