Team C LUPUZ Manual page 32

10 Differential
Differential
T02007(2.5x25)
T02048(2.37)
T02049 17x23x1 Washer
Beilagscheibe
T02078 10x15x4 Contain oil ball bearing
......2
11 Transmission
Getriebe
T02100(5x10x4)
Apply grease
Schmiermittel verwenden
T02078(10x15x4)
T02050(2.6x6x3)
T02004
T02049(17x23x1)
T02077(5x8x2.5)
Gleitlager
........................2
T02052
T02041
T02079(5x10x4)
T02207
T02046
T02049(17x23x1)
T02046
T02078(10x15x4)
T02077 5x8x2.5 Contain oil ball bearing
Gleitlager
.................................2
T02048 2.37mm Ball T02007 M2.5 Nylon Nut
Kugeldiff Kugeln
..................12
T02079(5x10x4)
T02051
T02079(5x10x4)
T02003
T02100 5x10x4 ball bearing
5
T02077(5x8x2.5)
T02047
T02007
T02007 M2.5x25 Screw
Nylon Mutter
...............1
T02207
T02082(M3x12)
T02082 M3x12 Screw
Schraube
T02051 5x16.8 Idler gear shaft
Getriebewelle
T02041 5x8 Top shaft spacer
Wellenspacer
T02079 5x10x4 Contain oil
Kugellager
Gleitlager
...............1
T02007(M2.5)
Schraube
......1
............1
...............1
............1
ball bearing
...............5
