PotteryBarn Stella Medicine Cabinet Recessed Assembly Instructions

-

Note: Professional installation required

Important safety instructions:

Please read all instructions carefully before assembling. For your safety, mounting by two people is recommended.
The maximum individual shelf weight capacity is 10lbs. Do not exceed the load capacity.

Tools Required (Not Included):

Stud Finder Phillips Screwdriver
Pencil Level
Tape Measure

Parts Included:

Wooden Cabinet (1pc) - A

Hardware Included :

Shelf support (12pcs) – a

Removing Parts from Packaging:

Remove all parts and hardware from the box and lay them out on a clear workspace, along with any plastic
protective packaging. Do not dispose of any contents until assembly is complete to avoid accidentally
discarding small parts or hardware.
Professional Mounting Instructions: See Figure 1
1. Mark the desired location on the wall for installation.
2. After verifying the dimensions of the recessed portion of the cabinet, use appropriate tools to cut a rectangle in the
wall covering (sheetrock) measuring approximately 20.25 inches wide and 27.3 inches high. Use the level to make sure
that the cutout is true and level.
Note to the professional installer: Once the sheetrock cutout is removed, it is likely that at least one wall stud will interfere
with the inserted portion of this cabinet (A) and that some internal framing will be required. This will likely include cutting
a section from the interfering stud and adding stud sections to ensure that there is wood support located adjacent each
side of this cabinet (A) when it is inserted.
3. After the appropriate stud cutting and framing has been done, insert the cabinet (A) into the recess and ensure that it
fits snugly and is true. Adjust and shim as necessary and make sure that the outer molding of the cabinet (A) lies flush
Stella Medicine Cabinet Recessed
Glass Shelf (3pcs) -B
Rubber bumper (2pcs) – b
Page 1 of 3
Mounting Screws (4pcs) - c
