Vaderstad RAPID RDA S Series Instructions Manual

Seed drill
Hide thumbs Also See for RAPID RDA S Series:
Table of Contents

Advertisement

Quick Links

Instructions
Seed drill
RAPID
series
RDA 500-800 S
No. 12 000-12 799
Ver.2 01.11.2002
900225-en

Advertisement

Table of Contents
loading

Related Manuals for Vaderstad RAPID RDA S Series

Summary of Contents for Vaderstad RAPID RDA S Series

  • Page 1 Instructions Seed drill RAPID series RDA 500-800 S No. 12 000-12 799 Ver.2 01.11.2002 900225-en...
  • Page 2 Ver.2 01.11.2002...

  • Page 5: Table Of Contents

    RDA 500-800 S Safety regulations Before using the drill ................8 Warning decals ................... 8 Other safety precautions ..............10 Location of warning decals on the machine ........... 10 Data plates ..................11 Assembly instructions Lifting and unloading the drill .............. 12 Removal of transport locking devices ..........
  • Page 6 3.24 Locking the lifting rams during service ..........65 3.25 Adjusting the seed coulters ..............66 3.26 Scrapers ..................67 3.27 Wing packers (option) ................ 67 Advice on sowing Sowing depth ..................68 Checking the seed feed ..............69 Sowing headlands ................70 Engaging the drill ................
  • Page 7 RDA 500-800 S INTRODUCTION Väderstad Rapid A 500-800 S is a high-capacity cultivation drill. The Rapid drills can be used under a large variety of conditions, from "direct drilling" to sowing straight after the plough. This versatility is made possible by the drill's coulter system design and its unique depth control system, amongst other features.

  • Page 8: Safety Regulations

    Safety regulations Safety regulations Before using the drill Figure 1.1 ! Always pay extra attention to paragraphs or figures bearing the following symbol: ! Learn to handle the drill correctly and with care. The drill can be dangerous in inexperienced or careless hands.
  • Page 9 RDA 500-800 S Drills with a PTO driven hydraulic pump: Pay attention to the rotating transmission for the hydraulic pump. Do not stride across or stay close to the rotating parts. Disconnect the trans- mission, switch off the ignition of the tractor and take out the key whenever work close to the hydraulic pump or other maintenance work is required.

  • Page 10: Other Safety Precautions

    Safety regulations Other safety precautions ! Observe the greatest caution when transporting the drill on a public road. When driving with a full hopper, remember that the following weight is great and that the view to the rear is very restricted.

  • Page 11: Data Plates

    RDA 500-800 S Data plates 1.5.1 Serial number plate Figure 1.4 Model number Manufacturing Number. Always state this number in connection with orders of spare parts, service or warranty claims. 1.5.2 CE plate Tillv. nr 12000-12461 Tillv. nr 12462- Figure 1.5 Working width Transport width Serial (CE) number...

  • Page 12: Assembly Instructions

    Assembly instructions Assembly instructions The drill is delivered completely assembled to the customer. The assembly instructions in NOTE! the following are intended to be used by assembly staff and service personnel at the dealership. On delivery, the drill may be almost fully assembled depending on the method of transport etc. Use the following instructions where necessary.

  • Page 13: Removal Of Transport Locking Devices

    RDA 500-800 S Removal of transport locking devices Figure 2.3 For the sake of transport, the front swivel rods between the seed boxes have been removed and connected to special plates (A) or secured by elastic straps. Before use, it is necessary to install the swivel rods onto the seed box arms (B).

  • Page 14: Fitting The Pre-Implements

    Assembly instructions Fitting the pre-implements Fit the pre-implements as explained in the spare parts manual or, in certain cases, according to the attached instructions. Fitting the drawbar Figure 2.5 Fit the drawbar to the centre section using the bolts provided. Place the drawbar on the supporting leg with the towhook about 40-50 cm over the ground.

  • Page 15: Removal Of The Transport Plates, Centre Section

    RDA 500-800 S Removal of the transport plates, centre section Figure 2.7 Lower the drill onto the ground so it is resting on the discs. Undo the swivel rods from the transport plates (A). While connecting the swivel rod to the seed box arm (B), the related wheel on the drill should be slightly raised.

  • Page 16: Mounting The Fan And Radar Unit (Hydraulic Feed Output)

    Assembly instructions Mounting the fan and radar unit (hydraulic feed out- put) Figure 2.9 1 Mount the rear bracket of the fan according to ”2.8 Fitting a fan” on page 15 in position B. Place it to allow the front part of the support to rest against the weld bead (A) on the draw-bar. 2 Secure the lower mounting point of the fan to the special bracket (C) with a screw.

  • Page 17: Fitting The Air Hose

    RDA 500-800 S 2.10 Fitting the air hose Figure 2.10 Figure 2.11 Fit the air hose from the fan to the branch pipe of the centre section using the hose clamp. Push the hose about 4 cm onto the branch. To make fitting easier, the hose can be slightly flattened and lubricated inside with soapy water.

  • Page 18: Installation Of The Control Station On The Tractor

    Assembly instructions 2.12 Installation of the Control Station on the tractor Figure 2.13 Be sure to install the control box securely in the tractor cab. Place the control box within the field of vision while looking in the travelling direction. Install the bracket as shown in the figure. Check for hidden cables before drilling holes in the tractor cab.

  • Page 19: Fitting The Bout Markers

    RDA 500-800 S 2.13 Fitting the bout markers Figure 2.14 Fit the bout marker arm (A) in the wing bracket (B). Fold in the bout marker arm and check that the catch of the arm (C) fits against the roller (D) on the wing.

  • Page 20: Fitting The Platform

    Assembly instructions 2.14 Fitting the platform Figure 2.15 Install the outer end plates in the installation holes on the hopper. Install the platform on the outer end plates. The angled corner (A) of the platform should be out- side the outer end plate (B). Install the guard rails and the ladder.

  • Page 21: Fitting The Following Harrow

    RDA 500-800 S 2.16 Fitting the following harrow Figure 2.17 1 Install the thills (A) and tighten the bolt joints. 2 Install the bushings (B) in the holes of the thills (C). Slip over the brackets (D). Insert and tight- en the screws (E).

  • Page 22: Fitting The Pre-Emergence Bout Markers

    Assembly instructions 2.17 Fitting the pre-emergence bout markers Set the drill on firm ground while hitched to the tractor. Raise or lower the drill until the seed boxes are a couple of centimetres above the ground. Engage the floating position or turn off the tractor to release the hydraulic pressure allowing the drill to sink to the ground.

  • Page 23: Installation Of Lights

    RDA 500-800 S 2.17.2 Hydraulics Figure 2.19 Remove the three plugs (E), one from the top of the valve block and two from the rear at the points marked 8 and 9. Remove the plugs carefully as there may be some residual hydraulic pressure. Fit the cartridge valve (F), the solenoid (G).

  • Page 24: Instructions And Settings

    Instructions and settings Instructions and settings All basic adjustments must be carried out with the Rapid drill on a level surface, with the NOTE! wing sections lowered and with the drill hitched to a tractor. Tractor Figure 3.1 Figure 3.2 To reduce damaging soil compaction, the tractor in use during sowing should be fitted with extra wide tyres, e.g.

  • Page 25: Hitching And Unhitching The Seed Drill

    RDA 500-800 S Hitching and unhitching the seed drill Figure 3.4 Hitch the drill to the tractor. Install the hydraulic pump on the tractor's PTO connector and connect the torque rod. (Applies to drills with a PTO driven hydraulic fan. Also see ”3.19.2 PTO driven hydraulic fan (option)” on page 47.
  • Page 26 Instructions and settings 3.3.3 Connecting hoses to the hydraulic fan Figure 3.5 Figure 3.6 Connect the two thin hoses to a two-way hydraulic connector designed for continuous operation of a hydraulic motor. If available, use a priority connector. The thicker hose of these two hoses is the pressure hose to the hydraulic motor, while the thinner is the oil leakage hose.

  • Page 27: Adjusting Hose Length And Connecting Intermediate Cable

    RDA 500-800 S Adjusting hose length and connecting intermediate cable Figure 3.7 The machine is fitted with an adjustable hose bracket. Fit the hydraulic hoses through the smaller holes in the hose bracket and adjust to a suitable length by adjusting the size of the loops before tightening the wing nuts.

  • Page 28: Switching Between Transport And Working Modes

    Instructions and settings Switching between transport and working modes 3.5.1 Changing from transport to working mode Extend the wheels on the wing sections fully using the lifting system. Figure 3.9 Turn both valves quickly from position A to position B. Warning: Do not stand with your feet under the tool bar as the machine can drop slightly.
  • Page 29 RDA 500-800 S Figure 3.12 Figure 3.13 Unlock the wing sections using the operating cord from the tractor cab. Keep the cord taut until the second section has begun to unfold. Figure 3.14 Figure 3.15 Unfold the drill while driving slowly forward. Keep holding the hydraulic lever until the fold- ing ram is fully extended and the piston rod on the weight transfer ram has retracted to approx- imately half its length.

  • Page 30: Horizontal Alignment

    Instructions and settings Horizontal alignment Figure 3.16 The pitch of the drill is adjusted in the field using the push rod (A). The outer side plates must be completely parallel to the ground when the drill is sowing at the correct depth. Check the horizon- tal alignment by ensuring that the forward seed coulters sow at the same depth as those at the rear.

  • Page 31: Adjusting Sowing Depth

    RDA 500-800 S Adjusting sowing depth 3.7.1 Adjusting the master and slave system Figure 3.18 The sowing depth of the drill is controlled by three hydraulic rams connected in series in a so- called master and slave system. Before using the drill for the first time, the rams must be bled and their position zeroed in relation to each other thus: Raise the drill to its topmost position so that all hydraulic rams are fully extended.

  • Page 32: Adjusting Weight Transfer

    Instructions and settings Adjusting weight transfer Figure 3.19 Figure 3.20 The weight transfer system is usually preset to 30-50 bar. This pressure works well under most conditions and does not normally require adjustment. The pressure can be checked on the manom- eter on the front of the seed drill, when the machine is unfolded on a level surface.

  • Page 33: Adjusting The Changeover Valve

    RDA 500-800 S Adjusting the changeover valve Figure 3.21 The valve is normally pre-adjusted on delivery from the factory. The changeover valve (A) alter- nates control between folding of the wing sections and operation of the tool bar. When the drill is lowered in working mode, one of the double acting hydraulic takeoff points of the tractor is con- nected to the tool bar and when the drill is raised onto its wheels, this same double acting takeoff is now connected to the wing folding system.

  • Page 34: Adjusting The Tool Bars

    Instructions and settings 3.10 Adjusting the tool bars Figure 3.22 The tool bars are normally preset at the factory. The tool bars are connected to a Master and Slave type lifting system. Before adjusting a tool bar, the hydraulic system must be bled and zeroed in the same way as that of the lifting system, see ”3.7 Adjusting sowing depth”...

  • Page 35: Setting The Radar (Hydraulic Feed Output)

    RDA 500-800 S 3.11 Setting the radar (hydraulic feed output) Figure 3.23 To achieve maximum reliability, the radar unit must be set at a certain angle towards the ground. The radar angle is optimal when the surface (A) is parallel with the ground and the drill is in the working position.

  • Page 36: Setting The Seed Rate, Mechanical Feed Output

    Instructions and settings 3.12 Setting the seed rate, mechanical feed output Figure 3.25 Figure 3.26 ! The seed boxes should be set according to the sowing table prior to filling the seed hopper. Use the crank to set the desired value on the scale. The scale setting can be reduced in intervals of 5-10 scale divisions even after the hopper has been filled.

  • Page 37: Calibration, Mechanical Feed Output

    RDA 500-800 S 3.14 Calibration, mechanical feed output Figure 3.28 Figure 3.29 ! Undo the protective cover on the drive wheel transmission. Put the high/low gear in the correct position. ! Adjust the seed rate. See ”3.12 Setting the seed rate, mechanical feed output” on page 36, and select a scale setting from the sowing table and based on previous experience.
  • Page 38 Instructions and settings H= 12 L= 26 Figure 3.32 Figure 3.33 ! The drive wheel is released by removing the ring cotter from the upper cog wheel (output shaft). Then mount the crank onto the shaft and lock it with the R-clip. NOTE! Don't forget to return the pin to its original position when the test is over.

  • Page 39: Calibration, Hydraulic Feed Output

    RDA 500-800 S 3.15 Calibration, hydraulic feed output 1 Set the seed boxes. See ”3.13 Seed box settings with hydraulic feed output” on page 36. Figure 3.35 2 Use the enclosed bags for calibration. Prior to calibration, reset the scale with the bags empty. Push the bags into the seed boxes from below through the spring-loaded doors.
  • Page 40 Instructions and settings 5 Simultaneously press the buttons on the Control Station to access the calibra- tion menu. Figure 3.37 6 Use the dial to select menu items, and confirm your selections with Select: desired feed output in kg/ha, percentage increase/decrease for electric control of the sown amount.
  • Page 41 RDA 500-800 S 11 Weigh the contents in both bags and add up the values.(If the weights of the contents in the bags differ from each other, each setting of the seed boxes should be verified and adjusted if needed. See ”3.15.2 Individual adjustment of the seed box scale values” on page 42. Also check to make sure that seed does not stick and build up on feed rollers and in the seed boxes) Figure 3.41 12 Input the value in kg into the Control Station and confirm by pressing...
  • Page 42 Instructions and settings 3.15.1 Decreasing the scale value of the seed boxes when the seed hopper is full The scale value can be reduced in steps of 5-10 scale divisions even after the seed hopper has been filled. Keep on the Control Station pressed for a few seconds and then continue to reduce the scale value.

  • Page 43: Prior To Filling The Hopper

    RDA 500-800 S 3.16 Prior to filling the hopper Check that: ! the machine is empty, clean and dry ! the seed housings are set as shown in the Sowing Table. ! the emptying hatches are closed. 3.16.1 Filling from bulk sacks Figure 3.44 Pay attention to safety.
  • Page 44 Instructions and settings 3.16.2 Filling from small sacks Pay attention to safety. Do not walk under a suspended load! Make sure there is nobody on the drill when feeding the seed. Make sure there is nobody on the hopper. Avoid contact with and in- halation of seed disinfectant.

  • Page 45: Operation Test

    RDA 500-800 S 3.17 Operation test Figure 3.48 To check the actual feed rate of the drill, a so-called operation test can be made. This is particularly recommended when the drill is new or when it is being run on a different surface than previously. For example, the drive wheels tend to slip more during sowing in heavy autumn soil.

  • Page 46: Adjusting The Air-Flow

    Instructions and settings 3.19 Adjusting the air-flow 3.19.1 Hydraulic fan "Fenix" The air volume is adjusted using the fan speed. The fan speed can be adjusted in various ways, depending on the tractor on which it is mounted: The fan is controlled using the tractor’s flow valve. A flow valve is available on most tractors with a constant pressure hydraulic system.
  • Page 47 RDA 500-800 S 3.19.2 PTO driven hydraulic fan (option) Connection of the hydraulic pump to the PTO shaft: Connect the hydraulic pump as explained below. Items 3 and 4 should only be performed during initial installation or when the pump is moved from one tractor to another. 1 Install the hydraulic pump on the tractor's 1000 rpm PTO shaft.
  • Page 48 Instructions and settings 5 Clamp the top rod to eliminate any lateral play. If necessary, use the enclosed spacers between the rod and the top rod mount. Lock the bolt with the locking nut on the outside. Figure 3.57 6 When parking the drill, set the PTO pump in the holder on the draw-bar. The holder can be folded down to keep it out of the way during driving.
  • Page 49 RDA 500-800 S Operation: Figure 3.58 The air volume is adjusted by using the sliding damper. The damper has four positions. Refer to the table below for recommended settings. Table 3.2 Table of sliding damper settings Rev speed RDA 500 S RDA 600 S RDA 800 S 4300 rpm Sliding damper position 1= fully opened.

  • Page 50: Control Station

    Instructions and settings 3.20 Control station Figure 3.59 Ver.2 01.11.2002...
  • Page 51 RDA 500-800 S 3.20.1 Functional description 1 Main switch 2 Master stop (all feeding stops and "STOP" is displayed on the 3rd and 4th row) 3 Not used 4 Not used 5 LCD display 6 Tramlining indicator lamps Off = No tramlining Green light = Tramlining and correct operation Red light = Incorrect tramlining 7 - Auto advance block.
  • Page 52 Instructions and settings Figure 3.60 Ver.2 01.11.2002...
  • Page 53 RDA 500-800 S 21 Manual start. By keeping the button pressed, seed is fed out without the machine advancing. This is used e.g. when starting in a corner of the field or when verifying the feed output. Use the programming menu for presetting the seed output amount in relation to the drive speed. 22 - Electric adjustment of sown seed amount, increase (in max.
  • Page 54 Instructions and settings Low-lift/Full lift Use push-button to switch between low-lift and full lift. The indicator lamps next to the button show which function has been engaged. Use low-lift when drilling. This prevents the ma- chine from being raised too much, while allowing proper operation of the following harrow in the headland.
  • Page 55 RDA 500-800 S Limited operation, left or right side Seed on the left or right side of the machine can be switched off by depressing the push-button on the left or right side. The indicator lamps show which side of the machine that has been switched off.
  • Page 56 Instructions and settings Information Press to access the information menu. Advance by turning the knob. If an alarm simulta- neously appear on the Control Station, the alarm texts are shown first. The information menu shows: seed trip meter (kg), , trip area meter (ha), , trip seasonal area meter (ha), , trip total area meter (ha),...
  • Page 57 RDA 500-800 S 3.20.3 Programming The Control Station has been preset at the Väderstad factory depending on the type and size of the machine it is supplied with. The Control Station settings need to be reentered after replacement or a reset. It is also possible to use the settings to adjust e.g., alarm delays, area metering, etc.
  • Page 58 Instructions and settings .Drive wheel circumference Default setting 240 cm. AUTO . Automatic calibration. Measure a given distance (at least 10 m). Press at the starting point. This will reset the pulse counter. Drive the selected distance with the ma- chine lowered to the drilling position.
  • Page 59 Väderstad-verken AB. Proceed as follows: 1 Log on to the Väderstad home page at http://www.vaderstad.com. 2 Click on "Downloads" to download the installation programme onto your computer. 3 Run the new software application while following the on-screen instructions. New files are cre- ated and/or updated.
  • Page 60 Instructions and settings 3.20.6 Tramlining flaps Figure 3.63 Figure 3.64 Tramlining is carried out by the spring loaded tramlining flaps (A) which are integrated into the outlets of the seed distributor heads in the seed hopper. In the activated position (Position 1) the flaps are raised into place to close the outlet while opening a trap to allow seed to return to the hopper.
  • Page 61 RDA 500-800 S 3.20.7 Tramline options With the RDA 500 S it is possible to produce tramlines spaced at 10, 15, 20, 25 m etc. With the RDA 600 S, tramlines can be produced at 12, 18, 24, 30 m etc and with the RDA 800 S, at 16, 24, 32 m etc.
  • Page 62 Instructions and settings Table 3.3 The most common tramlining systems on the RDA 500 S Tramline, Tramlining Start- value Note spacing programme 10 m First bout: drive with half the drill shut off Second bout: overlap half the first bout. 15 m 20 m First bout: drive with half the drill shut off...

  • Page 63: Tramlining

    RDA 500-800 S 3.21 Tramlining 3.21.1 Adjusting track width Figure 3.66 The Rapid drill is usually supplied with the row shutoff and track width specified by the customer. However, it is possible to change these if necessary: ! A different track width can be obtained by shifting the feed hoses to the seed coulters. Example: A track width of 1.75 m can be increased to 2.0 m by moving the front left and rear right one step outwards.

  • Page 64: Adjusting The Following Harrow

    Instructions and settings 3.22 Adjusting the following harrow Figure 3.68 1 Select a suitable work angle from hole series B. 2 The work pressure of the following harrow is adjusted using the adjusting screw (A). Depend- ing on the work pressure set on the following harrow, the cotter (C) should be positioned be- tween the trailing edge and centre of the oblong groove (D).

  • Page 65: Adjusting Low Lift Height

    RDA 500-800 S 3.23 Adjusting Low lift height Figure 3.70 Low lift height can be adjusted by moving the reed switch up or down in its holder using the wing bolt (A) which is tightened using the wing nut (B). This setting must be exact.

  • Page 66: Adjusting The Seed Coulters

    Instructions and settings 3.25 Adjusting the seed coulters Figure 3.73 Figure 3.74 Before carrying out any work under the drill, make sure it is fully secure. NOTE! To ensure a satisfactory sowing result, it is important that the seed boxes are correctly installed on the drill.

  • Page 67: Scrapers

    RDA 500-800 S 3.26 Scrapers Figure 3.75 The scrapers have two positions. When the scraper blade (A) can no longer be adjusted, the play of the scraper itself (B) can be adjusted . Under no circumstances should the distance between the edge of the scraper blade and the NOTE! tyre be less than 5 mm.

  • Page 68: Advice On Sowing

    Advice on sowing Advice on sowing Sowing depth Figure 4.1 See ”3.7 Adjusting sowing depth” on page 31 and ”3.8 Adjusting weight transfer” on page 32. The most important task for the Rapid operator is to carefully and continually check the sowing depth.

  • Page 69: Checking The Seed Feed

    RDA 500-800 S Checking the seed feed Figure 4.2 The seed feed should be checked at the same time as the sowing depth, i.e. after every 4 hectares or once an hour. In connection with output verification, check that both sides of the machine appear to be outputing the same amount from each coulter.

  • Page 70: Sowing Headlands

    Advice on sowing Figure 4.3 Check regularly whether the seed level is sinking evenly in both windows. Get into the routine of quickly looking over the drive shafts, gears and chains to see that every- thing looks normal and is still in place. Regularly ensure that the seed box rollers rotate at uniform speed.

  • Page 71: Engaging The Drill

    RDA 500-800 S Engaging the drill Figure 4.5 The drill must always be moving when lowered to ground. Keep the hydraulic lever in the pres- surised piston, i.e., lowering position, until the bout marker has been completely folded out. Using the Control Station, verify that tramlining has been advanced and that the correct lamp goes out and the correct one lights and that the alternate during subsequent raising.

  • Page 72: Obstructions

    Advice on sowing Obstructions Shut off the Autostep before the drill is lifted for sowing around a pole, well or other obstructions in the bout. NOTE! When the drill is lifted over an obstruction in the middle of the bout the drive wheel will also be lifted and the feeding will stop.
  • Page 73 RDA 500-800 S Ver.2 01.11.2002...

  • Page 74: Maintenance And Service

    Maintenance and service Maintenance and service Figure 5.1 Figure 5.2 Figure 5.3 During all work under the drill or where there is a danger of crushing, the drill must be com- NOTE! pletely and securely supported. Secure the drill on trestles or stands and lock all lifting rams with their yellow locking devices.
  • Page 75 RDA 500-800 S Figure 5.4 Ver.2 01.11.2002...

  • Page 76: General Maintenance

    Maintenance and service General maintenance Figure 5.5 A machine is only as good as the service it receives! Before starting work, check that all nuts and screws are tightened. During the season, check the tightness of nuts and screws regularly, as well as the wear on linkages and the hydraulic ram mountings.

  • Page 77: Drive Wheel Transmission

    RDA 500-800 S Drive wheel transmission Figure 5.8 Remove the chain casing and check the tension in the chain and the condition of the chain. Grease the chain every 200 ha. Locking device Figure 5.9 Grease the locking device regularly. Use grease on the angled surface of the locking bar and around where the bar is in contact with the hopper.

  • Page 78: Cleaning

    Maintenance and service Cleaning Figure 5.11 Figure 5.12 Figure 5.13 At regular intervals and at the end of the season, check that there is no seed or packaging debris stuck in the seed hoses or in the seed outlets on the distributor head. At the same time, check the function of the tramlining flaps.

  • Page 79: Storing The Drill

    RDA 500-800 S Storing the drill Figure 5.15 The drill should be stored indoors when not in use. This is particularly important because the drill contains electronic equipment. The electronic components are of very high quality and can with- stand a lot of moisture but we still recommend that the drill be stored indoors. The Control Box should be stored at room temperature during the winter and between seasons.

  • Page 80: Lubrication Points

    Maintenance and service Lubrication points Be safety conscious and do not crawl under the drill to lubricate. Lubricate from above, or support the drill securely on trestles. See ”1 Safety regulations” on page 8. Lubricate regularly as shown below: the disc bearings should be greased until grease appears or by 2-3 strokes of the grease gun.

  • Page 81: Changing Disc Bearings

    RDA 500-800 S 5.10 Changing disc bearings Figure 5.16 Figure 5.17 Figure 5.18 These consist of a ball bearing which is pressed onto the disc hub and secured with a circlip. Cir- clip pliers and a puller should be use to dismantle the bearing. A special puller can be ordered from Väderstad-Verken AB, Part No.

  • Page 82: Changing Seed Coulter Mounting Bolts

    Maintenance and service 5.11 Changing seed coulter mounting bolts Figure 5.19 Figure 5.20 The disc arm has two recessed bolts for the coulter mounting. If these cannot be driven out, they must be cut and ground level with the arm. It may be necessary to remove the entire disc arm to do this.

  • Page 83: Changing The Seals On The Hydraulic Rams

    RDA 500-800 S 5.13 Changing the seals on the hydraulic rams Figure 5.22 During service work on the hydraulic system, the wing sections and the drill must be fully NOTE! lowered, with no pressure in their hydraulic systems. Before service work on the folding and weight transfer systems, see ”5.15 Bleeding the hydraulic system accumulators”...

  • Page 84: Changing The Valve Seals On The Master Ram

    Maintenance and service 5.14 Changing the valve seals on the master ram Figure 5.23 Unscrew the guide (C) carefully if there is still hydraulic pressure in the system Change O-ring (A) and also O-ring (B) on the guide if necessary. O-ring (A), Part No.

  • Page 85: Repairing And Replacing Seed Hoses

    RDA 500-800 S 5.17 Repairing and replacing seed hoses Figure 5.26 Repair If a seed hose is worn or bent, it can be patched with a joint, Part No. 415397 for Ø32 mm hose. This dimension refers to the internal diameter of the hose and the external diameter of the joint. Cut the hose in the centre of the damaged area.

  • Page 86: Hydraulic Drive Transmission

    Maintenance and service 5.19 Hydraulic drive transmission Figure 5.28 Check the chain and lubricate it every 500 ha or once every season. See ”5.8 Lubrication points” on page 80. To gain access to the chain, first undo the protective cover. Move the cover aside to- wards the centre of the machine.

  • Page 87: Pto Driven Hydraulic Fan

    RDA 500-800 S 5.21 PTO driven hydraulic fan The fan has an inherent oil system with a special oil and a separate filter. The system has a capacity of approx. 40 liters of oil (SHS 46 quality). During maintenance work, always pay attention that the oil does not become contaminated. The service life of the system entirely depends on the quality of the oil both in terms of cleanliness and its condition.

  • Page 88: Intermediate Packer (Option)

    Maintenance and service 5.21.3 Draining condensing water Prior to first use each season or following extended interruption, be sure to drain condensing water from the tank. ! Park the machine on an inclination to have the tank inclined towards the drain connector at its bottom.

  • Page 89: Troubleshooting

    RDA 500-800 S Troubleshooting General information on troubleshooting Many of the functions of the drill are controlled by a series of electrical, hydraulic and mechanical components. A good way to exclude many of the sources of faults from the start is to first deter- mine whether the fault is electrical.
  • Page 90 Troubleshooting 6.1.3 Hydraulic electric valves Figure 6.1 Figure 6.2 An electric valve contains a coil that operates as an electromagnet when current is fed to the valve. Do as follows to check whether the valve receives current: The LED on the connector lights and the coil becomes warm after a few minutes. Also, the nut on the top of the valve becomes magnetic.
  • Page 91 RDA 500-800 S 6.1.4 Magnetic switch Figure 6.3 A reed switch is a switch (or a sensor) that reacts to a magnetic field. Inside the reed switch is a glass tube containing two metal reeds that attract to each other when subjected to a magnetic field from a magnet.

  • Page 92: Troubleshooting Chart

    Troubleshooting Troubleshooting chart The Control Station does not op- erate when the main switch is switched on! - See ”6.1.1 Electric fault” on page 89. The bout marker(s) cannot be unfolded! - Check according to ”6.1.1 Electric fault” on page 89. - Check according to ”6.1.2 Hydraulic fault”...
  • Page 93 RDA 500-800 S Unintentional very slow unfold- ing of retracted bout marker(s)! - Check that the indicator lamp of the bout marker is not lit on the Control Station. - Check that the electric valve (A) or (B) of the bout marker does not receive current.
  • Page 94 Troubleshooting The drill can be raised although the lift stop is engaged! - Check whether the magnetic valve (C) on the valve block receives current. See Hydraulic electric valves under ”6.1.3 Hydraulic electric valves” on page 90. - Check the low-lift switch as explained above. If the lift stop valve does not receive - See ”6.1.1 Electric fault”...
  • Page 95 RDA 500-800 S Leakage from the shaft seal on - Leakage from the shaft seal of the hydraulic motor the fan's hydraulic motor! may be caused by: - Damage caused during assembly. - Wear due to dirt. - Wear due to too high pressure in the drain line. - A damaged seal caused by very high pressure in the drain line.
  • Page 96 Troubleshooting The Control Station generates a seed box drive alarm! - Check whether the drive wheel has been lowered and In case of doubtful drive: drives against the ground. - Check the transmission between the drive wheel and the seed boxes. - Check the sensor operation.
  • Page 97 RDA 500-800 S The drill is sinking, i.e. it drills deeper than the set drilling depth! - Is the O-ring on the master ram's cut-off valve dam- aged or missing? See ”5.14 Changing the valve seals on the master ram” on page 84. - Does the stop bolt touch the bottom at the rod's upper end? In this case the spring has been compressed or is damaged.

  • Page 98: Alarm List

    Troubleshooting Alarm list 2 Low seed level, right-hand side. - Check the seed level of the seed hopper. If there is seed in the seed hopper: - The sensitivity of the sensor has been incorrectly set. 3 Low seed level, left-hand side. - See alarm no.
  • Page 99 RDA 500-800 S 18 Seed fan, low rpm. - Check that the hydraulic hoses have been correctly connected to the tractor. - Check whether the hydraulic oil flow from the tractor has been correctly set. - Check the alarm time limits that were programmed into the Control Station.
  • Page 100 Troubleshooting 25 Seed box clutch, right-hand side. - This alarm is generated when seed shut-off on the right side does not operate. - Check the cable, switch and connection of the mag- netic clutch in the right seed box. An LED on the seed box switch lights when the clutch receives current.
  • Page 101 RDA 500-800 S 41 Hydraulic motor, seed output. - Is the hydraulic oil flow sufficient? Does the seed out- put fan start? - Check whether the seed boxes can rotate by hand. - Check the cable, connector and connection of the sen- sor.

  • Page 102: Appendices

    Appendices Appendices Sowing table ! Always perform seed calibration. The information in the sowing table should be used only as a guideline. For small seed output amounts, new seed calibrations should be performed regu- larly. Check the processed area and the output amount after each fill-up. Ver.2 01.11.2002...
  • Page 103 RDA 500-800 S Ver.2 01.11.2002...

  • Page 104: Calibration Results

    Appendices Calibration Results Table 7.1 Crop kg/dm High/low gear Scale reading Ver.2 01.11.2002...
  • Page 105 RDA 500-800 S Ver.2 01.11.2002...

  • Page 106: Hydraulic Diagram

    Appendices Hydraulic diagram 7.3.1 Hydraulic diagram, RDA 500-600 S Figure 7.1 428717 Ver.2 01.11.2002...
  • Page 107 RDA 500-800 S 1 Master and slave system for lifting and sowing depth 2 Master and slave system for lifting and sowing depth 3 Master and slave system for lifting and sowing depth 4 Hydraulic ram, drive wheel 5 Hydraulic ram, RH bout marker 6 Hydraulic ram, LH bout marker 7 Hydraulic ram, pre-emergence bout marker 8 Master and slave system, tool bar...
  • Page 108 Appendices 7.3.2 Hydraulic diagram, RDA 800 S Figure 7.2 428718 Ver.2 01.11.2002...
  • Page 109 RDA 500-800 S 1 Master and slave system for lifting and sowing depth 2 Master and slave system for lifting and sowing depth 3 Master and slave system for lifting and sowing depth 4 Hydraulic ram, drive wheel 5 Hydraulic ram, RH bout marker 6 Hydraulic ram, LH bout marker 7 Hydraulic ram, pre-emergence bout marker 8 Master and slave system, tool bar...
  • Page 110 Appendices 7.3.3 Fenix fläkt, standard Figure 7.3 Hydraulic motor Valve block Tractor Ver.2 01.11.2002...
  • Page 111 RDA 500-800 S 7.3.4 Fenix fan, PTO Figure 7.4 Hydraulic pump Hydraulic motor Choke valve Radiator Air filter Oil filter Contamination indicator Hydraulic tank Tractor Ver.2 01.11.2002...
  • Page 112 Appendices 7.3.5 Hydraulic feed output Figur 7.5 429874 Seed box Hydraulic motors Oil filter 3-port pressure-compensating flow valve Damping valve 2-way cock Tractor Ver.2 01.11.2002...

  • Page 113: Electrical System

    RDA 500-800 S Electrical system 7.4.1 Workstation connections Tabell 7.2 Workstation Function Hydraulic block connection connection WS1-1 Right-hand level guard WS1-2 Left-hand level guard WS1-3 Rotation guard, right-hand seed output roller WS1-4 Rotation guard, left-hand seed output roller WS1-5 Fan revolution counter WS1-6 Speedometer, drive wheel/radar WS1-8...
  • Page 114 Appendices 7.4.2 Level guards; capacitive sensors Figur 7.6 Tabell 7.3 Workstation Ter- Cable Ter- Function Matter Matter not connection minal colour minal detected detected WS1-1 Black Matter detected = Soil, LED lights Max. 1 V Min. 8 V WS1-2 White Matter not detected = Soil Min.
  • Page 115 RDA 500-800 S 7.4.4 Tramline motors Figur 7.8 Tabell 7.5 Workstation Terminal Cable Terminal Function connection colour WS1-16 Black Tramlining off - 12 V WS1-17 Brown Tramlining on - 12 V Blue 7.4.5 Low-lift switch; magnetic switch Figur 7.9 Tabell 7.6 Workstation Pole Cable...
  • Page 116 Appendices 7.4.6 Hydraulic electric valves Figur 7.10 Tabell 7.7 Workstation Terminal Cable Terminal Function connection colour WS1-12 WS1-14 Brown 12 V supply to valve, red lamp lights WS1-15 WS1-18 WS1-19 Blue WS1-20 WS1-21 7.4.7 Boundary switches Figur 7.11 Tabell 7.8 Workstation Pole Cable...
  • Page 117 RDA 500-800 S 7.4.8 Intermediate cable Figur 7.12 Tabell 7.9 Pole Cable colour Function Blue Yellow CAN LO (communication) Brown 12 V Green CAN HI (communication) 7.4.9 Terminator plug Figur 7.13 Tabell 7.10 Pole Function Terminator resistance: 120 ohms 12 V indication: LED lights Terminator resistance Ver.2 01.11.2002...
  • Page 118 Appendices 7.4.10 Sensor for hydraulic motor of seed housings Figure 7.14 Tabell 7.11 Pole Cable colour Function Green 360 pulses per turn, pulse = ground signal 12 V Black 7.4.11 Radar Figure 7.15 Tabell 7.12 Workstation Pole Cable Pole Function connection colour WS1-6...
  • Page 119 RDA 500-800 S 7.4.12 Mini-remote WS1-23 WS1-8 Figure 7.16 Table 7.13 Workstation Pole Cable Function connection colour WS1-8 Black Seed output by depressing push-button B (contact between terminal 1 and terminal 4 on WS1-8) Blue Table 7.14 Workstation Pole Cable Function connection colour...

  • Page 120: Technical Data

    Appendices Technical data Table 7.15 Machine RDA 500 S RDA 600 S RDA 800 S Working width (m) Transport width (m) Transport height (m) 3,4 * 3,4 * Transport height with advantage collar (m) Filling height (m) Filling height with advantage collar (m) Hopper capacity (litres) 2700 2700...
  • Page 122 590 21 VÄDERSTAD S-590 21 VÄDERSTAD SWEDEN Telefon 0142-820 00 Telephone +46 142 820 00 Telefax 0142-820 10 Telefax +46 142 820 10 www.vaderstad.com...

This manual is also suitable for:

Rapid rda 500 sRapid rda 800 s

Table of Contents
