Datadock - XYBIX SYSTEMS T2 Product Manual & Trouble Shooting Manual

W E L C O M E TO Y O U R X Y B I X F U R N I T U R E
Data Dock - Cable Organizer
Data Dock is a concealed data connection bay that is located on the back
edge of the keyboard surface. DataDock allows for easy access to cables
and plug&play connectivity to PC's.
• Configurable for USB, RJ11, RJ45 connections
• Instantly replace keyboards and mice
• Cable organizer tray keeps cables hidden yet accessible.
USB Port
USB Port - Charge Only
Xybix Systems, Inc. • 8207 SouthPark Circle • Littleton, CO 80120 • 800.788.2810 • www.xybix.com
Ext Cable USB Type A to Type A
Panel Mount for Datadock
(used for multiple computer devices)
USB charge only Type A to Type A
Panel Mount for Datadock
(used for multiple computer devices)
Datadock - Panel Mount RJ11
CAT3 Coupler (used for phone)
RJ11
Datadock - Panel Mount RJ45 CAT5
Coupler (used for data)
RJ45
