ML-2 application notes Converting PPU-2 to PPU-3 4189341126 UK 1. General information 1.1. Warnings, legal information and safety....................3 1.1.1. Warnings and notes ........................3 1.1.2. Legal information and disclaimer ....................3 1.1.3. Safety issues ..........................3 1.1.4. Electrostatic discharge awareness ....................3 1.1.5. -
Page 3: General Information
1.1.2 Legal information and disclaimer DEIF takes no responsibility for installation or operation of the generator set. If there is any doubt about how to install or operate the engine/generator controlled by the Multi-line 2 unit, the company responsible for the installation or the operation of the set must be contacted. -
Page 4: Factory Settings
1.2 About the Application Notes 1.2.1 General purpose This document includes application notes for DEIF's Multi-line 2 unit. It mainly includes examples of different applications suitable for the unit. For functional descriptions, the procedure for parameter setup, parameter lists, and so on, see the Designer's Reference Handbook. -
Page 5: Application And Installation
2.1 About the application 2.1.1 General description This document mainly includes general information (in point form) on how to upgrade a standard PPU-2 to a PPU-3 system, including mounting instructions and wiring descriptions, parameter and general standard con- versions. Upgrading of a GPU-2 to a GPU-3 is a similar setup. Contact DEIF support for more details. -
Page 6: Description Of Options
ML-2 application notes Converting PPU-2 Application and installation to PPU-3 4189341126 UK 2.1.3 Description of options The unit housing is divided into board slot positions. This means that the unit consists of a number of printed circuit boards (PCBs) mounted in numbered slots - #1, 3, 4 and 5. Some of these board slots are standard and some are intended for options. - Page 7 ML-2 application notes Converting PPU-2 Application and installation to PPU-3 4189341126 UK The illustration below shows the location of the various options related to slots #2, 4, 6, 7 and 8. DEIF A/S Page 7 of 18...
- Page 8 Application and installation to PPU-3 4189341126 UK The table below provides an overview and description of the PPU-2 options and shows which options that can be converted to PPU-3. PPU-2 options B1 and C1 are implemented as standard software in PPU-3.
- Page 9 ML-2 application notes Converting PPU-2 Application and installation to PPU-3 4189341126 UK PPU-2 Description PPU-3 Option type Option EF4 +/-20 mA for speed governor or AVR Hardware 2 × relay outputs for speed governor or AVR Option EF5 1 × PWM (Pulse Width Modulated) output for...
- Page 10 ML-2 application notes Converting PPU-2 Application and installation to PPU-3 4189341126 UK PPU-2 Description PPU-3 Option type Option M15 4 analogue inputs in slot #8 Hardware 4 analogue inputs in slot #6 and/or slot #8 Option M15.x Hardware Option M20...
-
Page 11: Installation And Parameter Setup
ML-2 application notes Converting PPU-2 Application and installation to PPU-3 4189341126 UK 2.2 Installation and parameter setup 2.2.1 Wiring installation Terminals for NEL and GB feedback have been changed. The table below shows an overview of the terminals on PPU-2 and PPU-3. - Page 12 ML-2 application notes Converting PPU-2 Application and installation to PPU-3 4189341126 UK General de- Terminal Terminal descrip- Terminal Terminal descrip- Note scription PPU-2 tion PPU-3 tion Mode 3 Digital input Digital input Ext. GOV set point/configu- rable Mode 4 Digital input...
-
Page 13: Parameter Settings - System Setup
2.2.2 Parameter settings - system setup The PC utility software is a software program that can be used for configuration of the Multi-line 2 products. There are two versions, 1.x for PPU-2 and 3.x. for PPU-3. The utility software can be downloaded at www.deif.com. -
Page 14: Parameter Setup Regulator Governor
2.2.5 Parameter setup governor relay The PPU-2 standard unit controls the governor on relay output terminals 65-68, slot #4, these are not configu- rable. The PPU-3 standard unit has four configurable relay outputs, placed in slot #4, terminals 65-72. The table below shows the differences in the standard parameter settings. -
Page 15: Synchronisation Setup
2113 Sync. blackout enable 2.2.7 Protection setup The following adjustment points are available in PPU-2: Set points, delay timer, output A or B. The protection has a commissioning window where live status is shown. DEIF A/S Page 15 of 18... - Page 16 ML-2 application notes Converting PPU-2 Application and installation to PPU-3 4189341126 UK In PPU-3, the same adjustment points are present, but "Fail class" is added. Here it is possible to set an alarm to for example Trip of GB, Warning shutdown, and so on. Inhibits are also added in the protection pa- rameter.
-
Page 17: Mode Selection
2.2.8 Mode selection The setup for regulation mode has been changed and works differently in PPU-3. In the PPU-2 system, the selection of running modes is a combination of digital inputs, see the table below. In the PPU-3 system, the four different modes can be configured in the utility software - I/O settings. - Page 18 ML-2 application notes Converting PPU-2 Application and installation to PPU-3 4189341126 UK M-Logic is a simple tool based on logic events. One or more input conditions are defined, and at the activa- tion of those inputs, the defined output will occur. A great variety of inputs can be selected, such as digital inputs, alarm conditions and running conditions.
