- Page 1 INSTALLATION INSTRUCTIONS EVOLVER ALUMINUM FRAMED COMPOSITE FENCING FENCING INSTALLATION: EVOLVER...
-
Page 2: Table Of Contents
TABLE OF CONTENTS English Introduction.................3 Fence Layout................5 Post I nstallation..............7 Not Embedded............7 Embedded..............9 Rail & Fence Board Installation..........11 Degree Converter Installation........14 Care & Maintenance............16 Warranty................17 About California Proposition 65: https://fortressbp.com/about/californiaproposition65 FENCING INSTALLATION: EVOLVER... -
Page 3: Introduction
Contact your local Building Code Department for required permits and laws regarding your fence project. If applicable, also contact your Home Owners Association for rules and regulations regarding fence installations in your neighborhood. Call 811 before you dig post holes to locate and identify any buried utilities. Components Post Bottom Rail Top Rail Side Rail Support Locking Clip Fastener Post Slide Cover Intermediate Rail Fence Board Converter Post Cap Post Base 70-1/2” 70-7/8” [1791mm] [1800mm] FENCING INSTALLATION: EVOLVER... - Page 4 Drill Bits: Pencil 1/16” [2mm] Extender Head Bit Ground Stakes String Pliers Rubber Mallet Hand saw Wheelbarrow Miter or Post Hole Spade Concrete/ Circular Saw Digger Shovel Gravel Standard Panel Style Privacy Customizable Panel Styles Semi-Privacy Reinforced Decorative Portal FENCING INSTALLATION: EVOLVER...
-
Page 5: Fence Layout
Sketch Layout of Fence Perimeter 1. Identify the property line and determine the perimeter of your fence project. 2. Using a tape measure, determine the length of each fence run. 3. Evolver Fence is easiest to install when starting from a corner. If no gates are used, only one board in each line should need to be cut. 4. Use the graph on page 6 to sketch out your fence project. Fig. 1 TOP VIEW End Post HOUSE Corner Post Line Post Corner Post FENCING INSTALLATION: EVOLVER... - Page 6 FENCING INSTALLATION: EVOLVER...
-
Page 7: Post I Nstallation
Bases. Spacing between each Post Base CANNOT exceed 73”[1860mm ] (Fence Board width is 70-1/2”[1791mm]). Layout post spacing so that minimal panel cuts are required. As shown in Fig. 2. 5. Once spacing is confirmed, Use pencil to mark position of each post base. 6. Use 3/8” [9mm] Concrete Anchors to anchor Post Bases to foundation. As shown in Fig. 3. 7. Use a level to confirm that each Post Base is mounted straight at a 90 degree angle. Fig. 1 TOP VIEW HOUSE Ground Stake Foundation Guide String FENCING INSTALLATION: EVOLVER... - Page 8 2. Be sure to have each fence board slot facing the slot of the opposite post. As shown in Fig. 2. 3. Use a level to confirm that the post is mounted at degree angle. 4. Pre-drill screw holes into Post Base & Post with a 1/16” [2mm] drill bit. 5. Use a drill to fasten screws into the post to the mounted post base. As shown in Fig. 3. Note: • Closed wall sides are aesthetically best position for forward facing posts. • Post Slide Covers can be used to cover unused fence slots. STEP 2.1 Slide your post over FENCING INSTALLATION: EVOLVER...
-
Page 9: Embedded
3. Determine spacing required between Corner & Line Post Bases. Spacing between each Post Base CANNOT exceed 73”[1860mm ] (Fence Board width is 70-1/2”[1791mm]). Layout post spacing so that minimal panel cuts are required. As shown in Fig. 1. 4. Once spacing is confirmed, Use spray paint to mark post hole locations. 5. Holes should be 10” [250mm] in diameter. Check local building codes for post hole depth. 6. Place Embedded Post Base into holes along Guide Strings. Posts should have at least 12” [300mm] exposed FENCING INSTALLATION: EVOLVER... - Page 10 Fig. 1 HOUSE Ground Stake Guide String Max. Post Base Spacing is 73” [1860mm ] . Fence Board Width is 70-1/2” [1791mm]. Post Base SECTION VIEW Fig. 2 Post Base Concrete 11-13/16” [300mm] Max Check Local Code Gravel Step 2: Mount Post (Embedded/No Foundation) 1. Reference Post Mounting instructions on page 8, step 2. FENCING INSTALLATION: EVOLVER...
-
Page 11: Rail & Fence Board Installation
No other fastening is needed for these, as the weight of the boards will hold them in place 1. Place Post Cover Sliders into slots where Fence Boards are Installation Guide - 2017 not needed. As shown in Fig. 1. FENCING INSTALLATION: EVOLVER... - Page 12 • Semi-Privacy Fence - Use Side Rail Supports between each board. As shown in Fig. 3. • Decorative Fence - Use Intermediate Rail before final board. As shown in Fig. 4. • Portal Fence - Use Side Rail Support after final board & between two top rails. As shown in Fig. 5. Note: • Customized fence styles will require the purchase of additional items. Fig. 1 Fig. 2 Intermediate Rails Reinforced Privacy FENCING INSTALLATION: EVOLVER...
- Page 13 Install Rail & Fence Board 1. Slide Bottom Rail into the Post Slots. As shown in Fig. 1. 2. Slide Fence Boards and/or Intermediate Rail one after the other. As shown in Fig. 2. 3. Slide down Top Rail. As shown in Fig. 3. 4. Slide Locking Clip into place with supplied screws and fasten. As shown in Fig. 4. 5. Slide Post Cap into place. As shown in Fig. 5. Note: • Rubber Mallet can be used to seat Fence Boards, Top/ Bottom/Intermediate Rails & gently knock Post Caps down into place down, if necessary. FENCING INSTALLATION: EVOLVER...
-
Page 14: 45 O Degree Converter Installation
Fig. 1 Fig. 2 Fig. 3 Fig. 4 Fig. 5 CONVERTER INSTALLATION Required Components: • 45 Degree Converter • Fastener Step 1: Install 45 Converter 1. Position the 45 Degree Converter on desired face of post. As shown in Fig. 1. FENCING INSTALLATION: EVOLVER... - Page 15 2. Fasten the 45 Degree Converter into place using provided screws. As shown in Fig. 2. Step 2: Rail & Fence Board Installation 1. Reference Post & Fence Board installation steps on pages 11 - 14. TOP VIEW TOP VIEW Fig. 1 Fig. 2 FENCING INSTALLATION: EVOLVER...
-
Page 16: Care & Maintenance
STEP 3: Rinse fence boards with clean water. STEP 4: If fence boards are still dirty, a pressure washer can be used. Note: • If using a pressure washer, keep nozzle at least 12” [300m] away from Fence Board surface. General Care • Wash Evolver™ profile periodically using standard household cleaners. • Clean up spills as soon as is possible to prevent them from becoming stains. FENCING INSTALLATION: EVOLVER... -
Page 17: Warranty
Fortress does not warrant against and is not responsible for any condition attributable to: (1) improper installation of Evolver®and/ or failure to abide by Fortress installation guidelines, including but not limited to improper gapping; (2) use of Evolver® beyond normal and proper use, or in an application not recommended by Fortress guidelines and local building codes; (3) movement, distortion, collapse or settling of the ground or the supporting structure on which Evolver® is installed; (4) any act of God (such as flooding, hurricane, earthquake, lightning, etc.), environmental condition (such as air pollution, mold, mildew, etc.), staining from foreign substances (such as dirt, grease, oil, etc.), or normal weathering (exposure to sunlight, weather and atmosphere which will cause any colored surface to gradually fade, chalk, or accumulate dirt or stains); (5) improper handling, storage, abuse or neglect by Purchaser, the transferee or third parties; or (6) ordinary... - Page 18 OF PURCHASE MUST ACCOMPANY ALL WARRANTY CLAIMS. The original residential purchaser will be notified by Fortress as to whether the warranty claim is approved or denied. Conditions And Exclusions Of This Warranty THIS WARRANTY MUST BE REGISTERED WITHIN 30 DAYS OF INSTALLATION WITH FORTRESS BUILDING PRODUCTS. THIS WARRANTY IS NOT TRANSFERABLE. THE AMOUNT OF YOUR RESTITUTION WILL NOT INCLUDE LABOR TO REMOVE EXISTING COMPONENTS OR INSTALL THE REPLACEMENT COMPONENTS, SHIPPING CHARGES, SALES TAX OR ANY OTHER CHARGES, NOR IS FORTRESS FENCE PRODUCTS REQUIRED TO PROVIDE SUCH LABOR OR SERVICE. THIS LIMITED WARRANTY IS IN LIEU OF ALL OTHER EXPRESS WARRANTIES. FORTRESS FENCE PRODUCTS MAKES NO OTHER EXPRESS WARRANTIES AND DOES NOT AUTHORIZE ANY OTHER PERSON OR AGENT TO MAKE ANY OTHER EXPRESS WARRANTIES. FORTRESS BUILDING PRODUCTS NEITHER ASSUMES NOR AUTHORIZES ANY OTHER LIABILITY OR OBLIGATION IN WARRANTY, INCLUDING WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE WITH RESPECT TO THIS PRODUCT, IS LIMITED IN DURATION TO THE TWENTY (20) YEAR TERM OF THIS LIMITED WARRANTY. IN NO EVENT SHALL FORTRESS FENCE PRODUCTS BE LIABLE FOR ANY CONSEQUENTIAL, SPECIAL, OR INCIDENTAL DAMAGES ARISING OUT OF OR CONNECTED WITH THE PURCHASE OR USE OF THIS PRODUCT OR FOR ANY BREACH OF WARRANTY. MAY HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE. THIS WARRANTY IS APPLICABLE ONLY TO SYSTEMS INSTALLED WITHIN THE CONTINENTAL UNITED STATES AND CANADA. FENCING INSTALLATION: EVOLVER...
- Page 19 This Agreement shall be governed by and construed in accordance with the laws of the State of Texas, without regard to its conflict of laws. Any legal action arising out of this Agreement shall be litigated and enforced under the laws of the State of Texas. In addition, you agree to submit to the jurisdiction of the courts of the State of Texas, and that any legal action pursued by you shall be within the exclusive jurisdiction of the courts in the State of Texas, U.S.A. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, OR THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSION MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE. THIS WARRANTY IS APPLICABLE ONLY TO SYSTEMS INSTALLED WITHIN THE CONTINENTAL UNITED STATES AND CANADA. FENCING INSTALLATION: EVOLVER...
- Page 20 JOIN THE REVOLUTION. FortressBP.com | 866.323.4766 © 2020 Fortress Building Products. Unless otherwise noted, all proprietary names are trademarks of Fortress Iron, LP. All rights reserved. FENCING INSTALLATION: EVOLVER 08/2020...
