Installation and configuration guide
Panoramic Power – advanced cellular bridge
For firmware version 2x (Build 107)
Version 2: January 2018
Revision 1. 2 November 2017
© 2017 Centrica plc.
Registered office: Millstream, Maidenhead Road, Windsor, Berkshire. SL4 5GD. Registered in England & Wales No 3033654
Page 1 of 22
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Centrica Panoramic Power PAN-2-H-US/EU
Summary of Contents for Centrica Panoramic Power PAN-2-H-US/EU
- Page 1 Panoramic Power – advanced cellular bridge For firmware version 2x (Build 107) Version 2: January 2018 Revision 1. 2 November 2017 © 2017 Centrica plc. Registered office: Millstream, Maidenhead Road, Windsor, Berkshire. SL4 5GD. Registered in England & Wales No 3033654 Page 1 of 22...
- Page 2 Copyright Notice Copyright © 2016 Panoramic Power Ltd. All rights reserved. PANORAMIC POWER® is a registered trademark of Panoramic Power Ltd. A Centrica Business Solutions Company. All other trademarks are the property of their respective owners. Regulatory Compliance Conforms to UL Std 61010-1, certified to CAN/CSA Std C22.2 No. 61010-1...
-
Page 3: Table Of Contents
Verifying the Wi-Fi or Cellular Connectivity ................18 Upgrading the Firmware Version ..................... 19 Troubleshooting ........................21 Revision 1. 2 November 2017 © 2017 Centrica plc. Registered office: Millstream, Maidenhead Road, Windsor, Berkshire. SL4 5GD. Registered in England & Wales No 3033654 Page 3 of 22... -
Page 4: Panoramic Power And The Bridge
Basic Bridge (PAN-2-H-US/EU) • Advanced Cellular Bridge (PAN-2-H-3G-US/EU), featuring a SIM card slot. Revision 1. 2 November 2017 © 2017 Centrica plc. Registered office: Millstream, Maidenhead Road, Windsor, Berkshire. SL4 5GD. Registered in England & Wales No 3033654 Page 4 of 22... - Page 5 Basic Bridge, see the Installation and Configuration Guide for Panoramic Power® Basic Cellular Bridge, version 4.21. Revision 1. 2 November 2017 © 2017 Centrica plc. Registered office: Millstream, Maidenhead Road, Windsor, Berkshire. SL4 5GD. Registered in England & Wales No 3033654 Page 5 of 22...
-
Page 6: Unpacking The Hardware
Screw the cellular antenna to its connector. Position the antennas as shown below. Mounting the Bridge Revision 1. 2 November 2017 © 2017 Centrica plc. Registered office: Millstream, Maidenhead Road, Windsor, Berkshire. SL4 5GD. Registered in England & Wales No 3033654 Page 6 of 22... -
Page 7: Connecting The Bridge
An Ethernet cable if you connect to the Internet via wired LAN Revision 1. 2 November 2017 © 2017 Centrica plc. Registered office: Millstream, Maidenhead Road, Windsor, Berkshire. SL4 5GD. Registered in England & Wales No 3033654 Page 7 of 22... -
Page 8: Configuring The Bridge
Activate your web browser. In the address bar, enter IP address 10.0.0.10. The Status page appears. It displays the current configuration. Revision 1. 2 November 2017 © 2017 Centrica plc. Registered office: Millstream, Maidenhead Road, Windsor, Berkshire. SL4 5GD. Registered in England & Wales No 3033654 Page 8 of 22... -
Page 9: Entering Credentials
For Wi-Fi and Ethernet connections, verify that the system administrator has opened port 8051 for inbound/outbound TCP/IP traffic. How to proceed Revision 1. 2 November 2017 © 2017 Centrica plc. Registered office: Millstream, Maidenhead Road, Windsor, Berkshire. SL4 5GD. Registered in England & Wales No 3033654 Page 9 of 22... - Page 10 For enterprise WPA and enterprise WPA2 security, enter your password in the field shown below. (This is for use with RADIUS server authentication.) Revision 1. 2 November 2017 © 2017 Centrica plc. Registered office: Millstream, Maidenhead Road, Windsor, Berkshire. SL4 5GD. Registered in England & Wales No 3033654 Page 10 of 22...
- Page 11 10. To use settings displayed on the screen to configure another bridge, select Save Configuration to File. Revision 1. 2 November 2017 © 2017 Centrica plc. Registered office: Millstream, Maidenhead Road, Windsor, Berkshire. SL4 5GD. Registered in England & Wales No 3033654 Page 11 of 22...
-
Page 12: Configuring The Bridge For Cellular Connection
(could take up to 30 seconds). Then enter the APN you received from the cellular network operator. If required, enter PPP details. Revision 1. 2 November 2017 © 2017 Centrica plc. Registered office: Millstream, Maidenhead Road, Windsor, Berkshire. SL4 5GD. Registered in England & Wales No 3033654 Page 12 of 22... - Page 13 11. Reconnect the bridge to the power source. Revision 1. 2 November 2017 © 2017 Centrica plc. Registered office: Millstream, Maidenhead Road, Windsor, Berkshire. SL4 5GD. Registered in England & Wales No 3033654 Page 13 of 22...
-
Page 14: Configuring The Bridge For Wired Lan
Install the bridge as explained in Mounting the Bridge. Reconnect the bridge to the power source. Revision 1. 2 November 2017 © 2017 Centrica plc. Registered office: Millstream, Maidenhead Road, Windsor, Berkshire. SL4 5GD. Registered in England & Wales No 3033654 Page 14 of 22... -
Page 15: Loading The Bridge Configuration From A Configuration File
To access these fields, select Administration in the bridge web interface. Revision 1. 2 November 2017 © 2017 Centrica plc. Registered office: Millstream, Maidenhead Road, Windsor, Berkshire. SL4 5GD. Registered in England & Wales No 3033654 Page 15 of 22... -
Page 16: Modifying The Default Credentials For The Bridge Web Interface
Bridge versions (if asked by the support team) • Configured interface • Connection details (allocated IP, etc.) Revision 1. 2 November 2017 © 2017 Centrica plc. Registered office: Millstream, Maidenhead Road, Windsor, Berkshire. SL4 5GD. Registered in England & Wales No 3033654 Page 16 of 22... -
Page 17: Understanding The Bridge Leds
Use the following information to familiarize with the bridge status during normal operation in Wi-Fi, cellular, or Ethernet. Revision 1. 2 November 2017 © 2017 Centrica plc. Registered office: Millstream, Maidenhead Road, Windsor, Berkshire. SL4 5GD. Registered in England & Wales No 3033654 Page 17 of 22... -
Page 18: Verifying The Wi-Fi Or Cellular Connectivity
How to proceed Access the bridge web interface. Select Diagnostics. Revision 1. 2 November 2017 © 2017 Centrica plc. Registered office: Millstream, Maidenhead Road, Windsor, Berkshire. SL4 5GD. Registered in England & Wales No 3033654 Page 18 of 22... -
Page 19: Upgrading The Firmware Version
Make sure you have the following items: • Micro USB adapter cable Revision 1. 2 November 2017 © 2017 Centrica plc. Registered office: Millstream, Maidenhead Road, Windsor, Berkshire. SL4 5GD. Registered in England & Wales No 3033654 Page 19 of 22... - Page 20 Disconnect the USB flash drive. Disconnect the micro USB adapter cable. Revision 1. 2 November 2017 © 2017 Centrica plc. Registered office: Millstream, Maidenhead Road, Windsor, Berkshire. SL4 5GD. Registered in England & Wales No 3033654 Page 20 of 22...
-
Page 21: Troubleshooting
If you are using Internal Cellular: Revision 1. 2 November 2017 © 2017 Centrica plc. Registered office: Millstream, Maidenhead Road, Windsor, Berkshire. SL4 5GD. Registered in England & Wales No 3033654 Page 21 of 22... - Page 22 Enter configuration mode and check the running firmware version in the Status page). Contact Customer Support for further help. Revision 1. 2 November 2017 © 2017 Centrica plc. Registered office: Millstream, Maidenhead Road, Windsor, Berkshire. SL4 5GD. Registered in England & Wales No 3033654 Page 22 of 22...
