FLX Babymaker Owner's Manual page 11

The Babymaker | Owners Manual
STEP 6: Installing the Brake levers
Note: If your brake levers are already attached, you may check that the
brake levers are properly secured, and move on to the next step.
If they are not properly secured, use the torx bit to tighten the bolts
(see Figure 17).
Figure 16. Locating the Brake Lever Bolts
Tip: In the US, it is standard to have the front brake on the left side and the
rear brake on the right side. You may choose to set-up your brakes based on
what is standard in your country.
3. Tighten the bolts the rest of the way. They should not be able to rotate at all.
Figure 17. Attaching the Brake Levers
18
1. Using the T25 Torx bit, unscrew the two
bolts on each brake lever.
2. Place the lever over the handlebars and
tighten the bolts just enough so that you
can still adjust the angle of the brake
levers to suit your comfort prefrerence.
Figure 18. Attached Brake Levers
www.flx.bike
Step 7: Tighten the Display
1. Grab the 2.5mm allen key, and locate
the bolt on the bottom side of the LCD
display
2. Make sure the display is at a comfort-
able angle for you, then tighten the bolt
(clockwise) until it is fully secured.
STEP 8: Charge Your Battery
Figure 21. Charging Your Battery
Figure 20. Charging Light
The Babymaker | Owners Manual
Figure 19. Tightening the LDC Display
1. Connect the charger into the charging
port located on the right side of your
Babymaker.
Tip: Allow the battery to fully charge
before riding (about 4-8 hours the
first few cycles). After this, you may
charge normally (2 hours).
2. Plug your charger into an outlet. The
indicator light will turn green.
Green Light:
Not charging/Fully charged
Red Light:
Charging/Not fully charged
www.flx.bike
19
