ATBTLC1000 BluSDK
HID Mouse Device – Getting Started Guide
USER GUIDE
Introduction
This getting started guide describes the setup of ATBTLC1000 with a
supported platform
bringing up an
example profile supplied as part of BluSDK. This document explains the bring-up of HID Mouse device
example application that is embedded as part of the software release package.
Atmel-42524C-ATBTLC1000-BluSDK-HID-Mouse-Device-Getting-Started-Guide_USERGUIDE_022016
Advertisement
Table of Contents
Related Manuals for Atmel ATBTLC1000 BluSDK
Summary of Contents for Atmel ATBTLC1000 BluSDK
- Page 1 ATBTLC1000 BluSDK HID Mouse Device – Getting Started Guide USER GUIDE Introduction This getting started guide describes the setup of ATBTLC1000 with a supported platform bringing up an example profile supplied as part of BluSDK. This document explains the bring-up of HID Mouse device example application that is embedded as part of the software release package.
-
Page 2: Table Of Contents
Build Procedure ........................... 10 Console Logging ....................... 14 Running the Demo ..................... 14 BluSDK Software Architecture ................. 19 10 ATMEL EVALUATION BOARD/KIT IMPORTANT NOTICE AND DISCLAIMER ..20 11 Revision History ......................21 HID Mouse Device – Getting Started Guide [USER GUIDE] Atmel-42524C-ATBTLC1000-BluSDK-HID-Mouse-Device-Getting-Started-Guide_USERGUIDE_022016... -
Page 3: Description
Pressing the button on the SAM L21 platform simulates movement of mouse in a pre-defined pattern as described in later in this document. HID Mouse Device – Getting Started Guide [USER GUIDE] Atmel-42524C-ATBTLC1000-BluSDK-HID-Mouse-Device-Getting-Started-Guide_USERGUIDE_022016... -
Page 4: Demo Setup
Demo Setup Figure 2-1. Demo setup of HID Mouse Device Application on ATBTLC1000 Android Mobile phone ATBTLC1000+ (HOGP Host role) Supported Atmel MCU (HID Mouse Device Application) BLE L Supported Hardware Platforms and IDEs BluSDK – Supported Hardware and IDEs Table 3-1. -
Page 5: Hardware Setup
ATBTLC1000 Xplained Pro Extension Connected to a SAM L21 Xplained Pro SAM D21 Xplained Pro HID Device Setup Figure 4-2. BTLC1000 Xplained Pro Extension Connected to a SAM D21 Xplained Pro HID Mouse Device – Getting Started Guide [USER GUIDE] Atmel-42524C-ATBTLC1000-BluSDK-HID-Mouse-Device-Getting-Started-Guide_USERGUIDE_022016... -
Page 6: Sam G55 Xplained Pro Hid Device Setup
ATBTLC1000 Xplained Pro Extension Connected to a SAM G55 Xplained Pro SAM 4S Xplained Pro HID Device Setup Figure 4-4. ATBTLC1000 Xplained Pro Extension Connected to a SAM 4S Xplained Pro HID Mouse Device – Getting Started Guide [USER GUIDE] Atmel-42524C-ATBTLC1000-BluSDK-HID-Mouse-Device-Getting-Started-Guide_USERGUIDE_022016... -
Page 7: Configuration For Hid Mouse Application
The user may need to modify few macros in hid_device.h (HID Profile) for configuring the profile for HID Mouse application as per the desired application use-case. Figure 5-1. HID Code Hierarchy HID Mouse Device – Getting Started Guide [USER GUIDE] Atmel-42524C-ATBTLC1000-BluSDK-HID-Mouse-Device-Getting-Started-Guide_USERGUIDE_022016... - Page 8 Currently the maximum number of report supported is 10. #define HID_NUM_OF_REPORT User should configure the desired number of service instances. Currently the maximum number of service supported is 2. #define HID_SERV_INST HID Mouse Device – Getting Started Guide [USER GUIDE] Atmel-42524C-ATBTLC1000-BluSDK-HID-Mouse-Device-Getting-Started-Guide_USERGUIDE_022016...
-
Page 9: Software Setup
Software Setup Installation Steps Atmel Studio installation [Atmel Studio 7.0 (build 594) Installer – with .NET] http://www.atmel.com/tools/atmelstudio.aspx (Note: SAM L21 Rev B/SAM D21/SAM G55/SAM 4S part pack is built-in as part of Atmel Studio 7.0) Atmel USB Driver Installer from http://www.atmel.com/tools/atmelstudio.aspx. -
Page 10: Build Procedure
The following procedure is explained for SAML21 application example. The same procedure is valid for the case of all the other supported platform as well. Select New Example Project. Figure 6-1. Creating a New Project HID Mouse Device – Getting Started Guide [USER GUIDE] Atmel-42524C-ATBTLC1000-BluSDK-HID-Mouse-Device-Getting-Started-Guide_USERGUIDE_022016... - Page 11 Enter “BLE-HID” in search window and expand Atmel Corp Projects. The location and the name of the project can be selected in the respective fields. Click OK. Figure 6-2. Selecting HID Device Application from Example Projects Accept the license Agreement. The studio will generate the BLE-HID Mouse project for SAM L21.
- Page 12 Building the HID Device Application Download the application via the DEBUG USB to the SAM L21 board using Device Programming option available in Tools as shown below Figure 6-4. Selecting Device Programming Option HID Mouse Device – Getting Started Guide [USER GUIDE] Atmel-42524C-ATBTLC1000-BluSDK-HID-Mouse-Device-Getting-Started-Guide_USERGUIDE_022016...
- Page 13 Program the device to download the HID Device application as shown below. Figure 6-5. Flashing the Application on Atmel MCU HID Mouse Device – Getting Started Guide [USER GUIDE] Atmel-42524C-ATBTLC1000-BluSDK-HID-Mouse-Device-Getting-Started-Guide_USERGUIDE_022016...
-
Page 14: Console Logging
Android from version 4.4 (Android KitKat) and upwards. The phone must include support a Bluetooth chipset supporting BT 4.0 or upwards on the mobile phone, In Bluetooth settings scan for the devices, device with “ATMEL-HID” will be found as shown below. Click on “ATMEL-HID” to get connected. - Page 15 Figure 8-4. Enter PIN as Indicated by the Terminal Console on the Device Side Figure 8-5. Click OK to Start Pairing HID Mouse Device – Getting Started Guide [USER GUIDE] Atmel-42524C-ATBTLC1000-BluSDK-HID-Mouse-Device-Getting-Started-Guide_USERGUIDE_022016...
- Page 16 Once the pairing done connected device is listed in paired device. Figure 8-6. ATMEL-HID Device Shown as Connected Console log on HID device side for pairing and connection procedure. Figure 8-7. HID Mouse Device Console Log after Connection and Pairing Completion HID Mouse Device –...
- Page 17 Next 5 Button Press: Cursor moved up The same sequence is repeated based on user input. A snapshot of the console logs are shown below. Figure 8-9. HID Device Console Log for Movement HID Mouse Device – Getting Started Guide [USER GUIDE] Atmel-42524C-ATBTLC1000-BluSDK-HID-Mouse-Device-Getting-Started-Guide_USERGUIDE_022016...
- Page 18 (5 moves RIGHT) Cursor position after pressing SW0 button 15 Cursor position after pressing SW0 button 10 times from start (5 moves LEFT) times from start (5 moves DOWN) HID Mouse Device – Getting Started Guide [USER GUIDE] Atmel-42524C-ATBTLC1000-BluSDK-HID-Mouse-Device-Getting-Started-Guide_USERGUIDE_022016...
-
Page 19: Blusdk Software Architecture
BluSDK Software Architecture The following diagram illustrates the various layers in the BLE subsystem for the ATBTLC1000 configuration. The External host can be supported platform. Figure 9-1. BluSDK Software Architecture HID Mouse Device – Getting Started Guide [USER GUIDE] Atmel-42524C-ATBTLC1000-BluSDK-HID-Mouse-Device-Getting-Started-Guide_USERGUIDE_022016... -
Page 20: Atmel Evaluation Board/Kit Important Notice And Disclaimer
User indemnifies Atmel from any claim arising from user's handling or use of this evaluation board/kit. Except for the limited purpose of internal development and evaluation as specified above, no license, express or implied, by estoppel or otherwise, to any Atmel intellectual property right is granted hereunder. -
Page 21: Revision History
Figure 4.4 is updated with SAM4S Xplained Pro image. Section 6.1 Installation Steps are updated. Figure 3-1 is updated. 42524B 11/2015 The screenshots in Chapter 6 are updated. 42524A 09/2015 Initial document release. HID Mouse Device – Getting Started Guide [USER GUIDE] Atmel-42524C-ATBTLC1000-BluSDK-HID-Mouse-Device-Getting-Started-Guide_USERGUIDE_022016... - Page 22 DISCLAIMER: The information in this document is provided in connection with Atmel products. No license, express or implied, by estoppel or otherwise, to any intellectual property right is granted by this document or in connection with the sale of Atmel produ cts. EXCEPT AS SET FORTH IN THE ATMEL TERMS AND CONDITIONS OF SALES LOCATED ON THE ATMEL WEBSITE, ATMEL ASSUMES NO LIABILITY WHATSOEVER AND DISCLAIMS ANY EXPRESS, IMPLIED OR STATUTORY WARRANTY RELATING TO ITS PRODUCTS INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, OR NON-INFRINGEMENT.
