Ezzy Slalom Quick Start Manual

Ezzy Sails Rigging and Tuning for the 94 Ezzy Slalom and Race
1994 Ezzy
Slalom / Race
Rigging &
Fine Tuning Guide
1) Lay the sail flat on the ground and slide the
mast through the sleeve above the cams and do
not attach the cams
(see diagram 1). Thread the mast extension with
no downhaul tension; just cleat the downhaul
line.
Caution:If using a two -piece mast, check and
make sure your mast is together at the joint.
2) Attach the boom front to the mast and outhaul
the sail flat in the boom area.
Quick Tip: Attach your boom at, or below the
center of the boom cut-out to prevent the top of
the boom cut-out from getting caught on the
boom while downhauling.
3) Attach the cams to the mast by pushing down
on the batten with the palm of your hand,
approximately 12" (30cm) from the luff sleeve,
and pushing the cam on to the mast with your
other hand (see diagram 2).
Quick Tip: If the cams are difficult to put on the
mast, check that the batten tension webbing is
loosened until the Velcro touched the buckle
(see diagram 3). This will allow the cam to slide
further into the sail and will make it easier to get
the cam on to the mast.
Ezzy Sails Rigging and Fine Tuning Guides
Page 1
