For Mounting Under a Kitchen Cabinet (Fig 1)
1. Select preferred duct location (vertical or horizontal).
2. Begin installation by removing the fi lters (if installed).
3. Reinforce cabinet with 1"x2" wood strips if additional
strengthening is required or if cabinets are framed.
4. Temporarily position the range hood in the desired
mounting location. Measure and mark the mounting
holes, duct and electrical locations with a pencil.
5. Drill/cut out the required openings for duct and
electrical access by following the dimensions on page
8; make sure the duct opening is large enough to apply
duct tape.
6. Fasten hood onto cabinet with (4) M4 wood screws
provided.
7. Install electrical.
8. Install duct work and duct tape.
9. Reinstall fi lters.
10. Power up hood and check for leaks around duct tape.
electrical
Fig 1
(Shown as vertical ducting)
13
Duct
opening
cutout
duct/silver
tape
Add 1x2
wood strips
