- Page 1 Instructions The electromechanical gear motor for sliding gates HERCULES...
- Page 2 Instructions 2x1.5 1xRG 58...
- Page 3 HERCULES is made specifically to control the automation of sliding gates and therefore it is forbidden to use it for any other purposes or improperly. • Use original components only. Stagnoli is not liable for damages if any other components are used. •...
- Page 4 Instructions Technical features Stagnoli’s HERCULES gearmotor is particularly suitable for sliding gates up to 500 kg and is available in the 230Vac and 24Vdc versions. HERCULES 24Vdc is available in the chain drive version too. The following table lists the features of the various models:...
- Page 5 Instructions Anchoring the foundation plate Before commencing to anchor the foundation plate to the ground, first prepare one or two sheaths for passing the cables through (Fig.1) After having verified the optimum conditions for placing the plate, bend the fish-tail clamps vertically and concrete the plate in (Fig.1).
- Page 6 Instructions Installing the gear motor Unscrew the two side screws to remove the top (Fig.4). Position Hercules on the foundation plate, taking care to centre the antiskid device (Fig.5). Fix the gear motor to the foundation plate with the screws but before tightening them completely, adjust the distance between Hercules and the gate.
- Page 7 Instructions 47x4 37x4 44x2 HERCULES 230V Rev.1 del 25/08/04 HERCULES TRASMISSIONE SU CREMAGLIERA 52x2 HERCULES TRASMISSIONE A CATENA 41x2 HERCULES 24V Rev.1 del 25/ 0 8/04 71x2...
- Page 8 Instructions Rev. 0 - 03/07 Stagnoli s.r.l. Via Mantova, Traversa 1^, 105 A/B-25017 Lonato (Bs) - Italia Tel. +39 030 9139511 Fax. +39 030 91380 www.stagnoli.com...
