Attention!
•
This user guide is addressed exclusively to technical personnel, qualified in the
installation area and not to the final user, i.e. the installer is fully responsible for
informing user about all the instructions for the proper use of the device, potential
hazards which can occur afterwards as well as the necessity of the periodical
maintenance.
•
The process of installation must be executed exclusively by qualified personnel,
fully observing instructions concerning automatic gates, particularly compliance
with the 89/392 directive and EN 12453 - EN 12445 standards.
•
ACHILLES was conceived as device of the sliding gate automation management,
thus it is strictly forbidden to use the product in an improper way or for any other use
not complying with the goals set by the producer.
•
Only use of the original components is authorized. Stagnoli excludes any
responsibility for the damage caused by the use of not original components.
•
Please ensure that the structure of the gate
motorized.
•
Please ensure that the gate, while moving, is not subjected to friction at any point
and there is no possibility to derail the gate.
•
Please ensure, before any action is taken at the gate, that the power supply is cut off.
•
Connect tension cable exclusively to the voltage lines equipped with the proper
electric protections; particularly, the gate must be provided with a device allowing
complete disconnection from the power and having a distance between contacts
of at least 3.5 mm.
•
Evaluate with particular attention safety devices and the places they should be
installed; furthermore, always ensure an emergency stop device allowing obligatory
disconnection from the power.
•
All maintenance operations, particularly the access to the internal parts of the gear
motor must be executed exclusively by the qualified personnel.
•
Non reversibility of the gear motor avoids the installation of any electrical locks, in
Istruzioni, instructions, instrucciones
is reliable
and adaptable to be
8
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Stagnoli ACHILLES-4000
Summary of Contents for Stagnoli ACHILLES-4000
- Page 1 • Only use of the original components is authorized. Stagnoli excludes any responsibility for the damage caused by the use of not original components. •...
- Page 2 Technical specification The ACHILLES 4000 gear motor by Stagnoli, is adapted for the automation of sliding gates up to 4000 kg of weight. Following table presents technical specification of the various models:...
- Page 3 Istruzioni, instructions, instrucciones Dimensions and height Before starting installation process, please check the gear motor placement area in relation to its heights and dimensions (fig.1). Fig.1 Fixing of the foundation plate Unscrew four lateral screws in order to remove the cover of Achilles 4000 (fig.2).
- Page 4 Istruzioni, instructions, instrucciones Fig.3 Installation of the gear motor Fix the gear motor on the flange slots to the body of the foundation (fig.4). Before locking completely four nuts, please adjust the distance from the gate. Take the first section of the rack and position it above the gear, ensure a space of at least 1 mm between the gear itself and the rack, than fix it to the gate...
- Page 5 Istruzioni, instructions, instrucciones afterwards fix the brackets definitely Fig.6 Manual release In order to execute any manual manoeuvre proceed as follows (fig.7): 1. Rotate the key clockwise. 2. Lift the door. 3. Using the hexagonal key, size 22, unscrew the nut positioned at the edge of the cylinder, till it is not easily taken out from its seating inside the body of the gear motor.
