VWR Vortex Mixer Instruction Manual page 4

F
IXED SPEED VORTEXER MIXER
A
NALOG VORTEXER MIXER
3
S
PECIFICATIONS
Dimensions: 4.8"H x 6.8"W x 4.8"D
Voltage:
Current:
Power:
Weight capacity: .65 lbs (294g) maximum
Speed range -
Orbit:
Controls - fixed speed: None
Product weight:
Ship weight:
I
NTRODUCTION
The Vortexer mixer is used to prepare samples for testing. It operates by mixing
tubes just prior to testing.
The 115v and 230v units are supplied with a 3-prong power cord that should be
plugged into a standard 3-prong grounded outlet. The unit is now on and in a
"standby" mode.
Speed knob Your Vortexer mixer is ready for use for most one-handed applications. To install the
cup head or 3" head attachment, follow these steps:
a. Be sure the Vortexer mixer is un-plugged.
b. Place cup-head on post, aligning the "flat" inside of the head mounting hole,
Power switch
with "flat" on post.
c. Press center of head down firmly until it snaps into place.
d. To remove an installed head, hold housing with one hand and pull head straight
up firmly.
(12.2cm x 17.3cm x 12.2cm)
115v/230v AC, 50/60 hertz
115v - 1.2 amps
230v - 0.6 amps
150 watts
fixed speed: 3200rpm
analog: 100 to 3200 rpm
230v units: 2500rpm
0.190" dia., .095 offset
analog: 3-way power switch
Speed knob, variable 1 to 10 dial markings
11lbs (5kg)
11.7lbs (5.3kg)
