Yealink SIP-T19P Quick Installation Manual

Configuring Your Phone
Configuring via web user interface
Accessing the web user interface:
1. Press when the phone is idle to get the IP address of the phone.
2. Open the web browser on your computer, enter the IP address into the address bar
(e.g., "http://192.168.0.10" or "192.168.0.10") and press Enter.
3. Enter the user name (default: admin) and password (default: admin) in the login page
and click Confirm.
Note: Please locate your computer in the same network segment of the IP phone (192.168.0.X) to access
the web user interface. Contact your system administrator for more information.
Network Settings: Click on Network->Basic->IPv4 Config
You can configure the network in the following ways:
DHCP: By default, the phone attempts to contact a DHCP server in your network to obtain its
valid network settings, e.g., IP address, subnet mask, gateway address and DNS address.
Static IP Address: If the phone cannot contact a DHCP server for any reason, you need to
configure IP address, subnet mask, gateway address, primary DNS address and
secondary DNS address for the phone manually.
PPPoE: If you are using an xDSL modem, you can connect your phone to the Internet via PPPoE
mode. Contact the ITSP for the user name and password.
Note: The wrong network settings may result in inaccessibility of the phone and may have an impact on
the network performance. Contact your system administrator for more information.
Account Settings: Click on Account->Register
Parameters of the account:
It shows the register status of the current account.
Register Status:
You can select Enabled/Disabled to enable/disable the account.
Line Active:
It is shown on the LCD to identify the account.
Label:
It is shown as caller ID when placing a call.
Display Name:
It is provided by ITSP for registration (required).
User Name:
It is an authenticated ID for authentication provided by ITSP (required).
Register Name:
It is provided by ITSP for registration (required).
Password:
Server Host: It is provided by ITSP for registration (required).
Register status icons on the LCD screen:
Registered Register Failed
Note: Check with your system administrator if any error appears during the registration process or a
specific configuration is required for your registration.
Configuring via phone user interface
Network Settings:
Press the Menu soft key when the phone is idle, select Settings->Advanced Settings
(password:admin)->Network->WAN Port/VLAN/Webserver Type/802.1x Settings to configure
the network.
Account Settings:
Press the Menu soft key when the phone is idle, select Settings->Advanced Settings
(password:admin)->Account to configure the account.
Note: For more information on account parameters, refer to Configuring via web user interface.
For more information, refer to the User Guide available online:
http://www.yealink.com/DocumentDownload.aspx?CateId=142&flag=142
Copyright c 2013 YEALINK NETWORK TECHNOLOGY CO.,LTD.
Registering
www.yealink.com
Enterprise IP Phone
Quick Installation Guide
Applies to firmware version 71 or later.
SIP-T19P
