Galvanized Box Fan 130
3.
Wiring diagram
4.
Voltage (V)
5.
Frequency (Hz)
6.
Nominal current (A)
7.
Rotation speed (RPM)
8.
Power (kW or PK)
9.
Cos phi
10.
Service factor
11.
Service factor ampere
12.
Full load ampere
13.
Capacitor (µF/V)
14.
Max. ambient temperature °C
15.
Min. ambient temperature °C
16.
IE2
17.
µ 100%
18.
µ 75%
19.
µ 50%
20.
Thermal protection (*)
21.
Year of construction
22.
Bar code
23.
Winding diagram
24.
Weather proof
*) Thermal protection (NC) (for single phase: 250V 10A cos Φ =1 / for 3-
phase: 250V 2.5A cos Φ =1)
**) E = suitable for electronic voltage control (TRIAC / phase cutting).
**) T = suitable for transformer voltage control.
**) F = suitable for frequency control / VFD (Variable Frequency Drive).
A frequency controller in combination with a single phase motor is possible.
A QR-code is displayed on the rating plate. This QR-code contains a link to
an information page about this product. Here you can find a digital copy of
these instructions as well as other information about this product.
5.4
Intended use
This Galvanized Box Fan 130 is intended to be used as an exhaust fan for the
mechanical ventilation of livestock houses (pigs, poultry, dairy) and
greenhouses or industrial applications.
NOTICE
This fan is intended for moving air only.
DANGER
Do not use this fan in explosive or potentially explosive atmo-
spheres.
5.5
Technical information
Sound pressure levels are measured at a distance of 2 meters and corrected
for the human ear (A-weighting) in dB(A). The technical datasheet contains
calculated sound pressure levels in dB(A) at a distance of 7 meters assuming
free field conditions.
INS00025-A
Original instructions
Explanation type plates
27.
Insulation class
28.
TEAO (Totally Enclosed Air Over)
29.
Number of phases
30.
Manufacturers name
31.
Manufacturers address
32.
Manufacturers country
33.
cURrus logo
34.
CE-logo
35.
CSA-logo
36.
W333 bin
37.
Tester code
38.
Work order date
39.
Fan type
40.
Imax (A)
41.
P
42.
VSD used
43.
Part number customer
44.
Weight (kg)
45.
Controllability (**)
46.
Energy efficiency category
47,
Energy efficiency static or total
48.
µ Overall
Technical specifications regarding performances are guaranteed until 1000
meters above sea level.
For detailed technical information please visit our website from which
technical datasheets can be viewed and downloaded.
5.6
6
51.
Air volume at 0 Pa (m
52.
Static pressure (x Pa)
53.
Air volume at x Pa (m
54.
PSE-logo
55.
Fan current (A)
56.
Pressure at 0 inwg.
57.
Air volume at 0 inwg.CFM
58.
Pressure at –x- inwg.
59.
Air volume at –x- inwg.
60.
Max. ambient temperature °F
61.
Min. ambient temperature °F
62.
Order
63.
CCC-logo
64.
Motor data. For.....
65.
House code
66.
Acceptable for field wiring
-1
67.
Min
68.
Cos phi application
69.
Wiring diagram application
70.
QR code
71.
Rotor code
72.
EAC logo
http://productselector.vostermans.com
Other information
DANGER
Ventilation system failure
This fan is manufactured to the highest quality standards. Neverthe-
less, failure of a fan can always occur.
This fan is intended to be used as a component of a ventilation sys-
tem. Where the health and well-being of humans and/or animals is
dependent on the functioning of this ventilation system, an appropri-
ate backup system must be provided such that in the event of failure
of the main system, sufficient air renewal is guaranteed to preserve
the health and well-being of the humans and/or animals.
An alarm system, which will operate even if the principal electricity
supply to it has failed, must be provided to give warning of any fail-
ure in the system.
Installation
WARNING
