Technical Specifications - Hub Controls HUB Controller Installation Manual

Technical Specifications

Screen
· TFT LCD resistive touch screen
· Resolution: 800 x 480px
· 5in (12.7cm) diameter
Size and Weight
· Weight: 320g
· Width: 5.12 in (130 mm)
· Height: 3.46 in (88 mm)
· Depth: 1.29 in (32.75mm)
Battery (internal)
· Panasonic Rechargeable Lithium Ion
3400 mAh, 3.7V
· Running time without mains present: 48
hours minimum
129mm
Wireless and Security
· Self-contained ultra-low power Wi-Fi
module
· IEEE Wi-Fi 802.11 b/g/n Wi-Fi transceiver
· 802.11g: up to 54 Mbps
· Frequency Band 2.484 GHz (WLAN
Channels 1-13)
· Wi-Fi security modes including Open,
WEP, WPA, and WPA2-PSK
· Data encryption: TLS1.2 (SSL)
Sensor
· Temperature sensor range and accuracy:
0°- 65° ± 0.3°C
88mm
32mm
c o n t r o l s
