5.

maintenance

5.1. The maintenance and repair of this crane may only be carried out by qualified and
authorized personnel, who as a result of their training and experience are familiar with the
hydraulic systems used in these devices.
5.2. clean and lubricate the axes of the moving parts of the crane at regular intervals. the crane
should be kept clean and protected from aggressive condi tions at all times.
5.3. only original spare parts should be used.
5.4. Withdraw the crane from service if it is suspected that it has been subjected to abnormal
loads or has suffered any type of knock until the unit has been inspected and any problem
has been resolved.
5.5. If the oil level needs to be checked or refilled, dismantle the hydraulic unit and with piston fully
retracted, remove the filler plug and drain its contents into a container. With the hydraulic unit
in a horizontal position, proceed to introduce the necessary volume for each model as indicated.
avoid dirt entering the system with the new oil.
an excess of oil over the volume required may affect the operation of the crane.
5.6. only use hydraulic oil, Hl or Hm type, with an iso grade of cinematic viscosity of 30cst at 40º,
or of an Engler viscosity of 3 at 50ºC. Never use brake fluid.
5.7. When the crane is not in use, it should be fully retracted in the lowest position so as to
minimize piston corrosion. it is recommended to apply an anti-corrosion product to the main
piston and to the pump.
5.8. store the crane in a dry and clean place, out of the reach of children.
parts support is available for this product. to obtain a parts listing and/or diagram,
please log on to www.sealey.co.uk, email sales@sealey.co.uk or telephone 01284 757500.

environmental protection

recycle unwanted materials instead of disposing of them as waste. all tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment.
When the product becomes completely unserviceable and requires disposal, drain off any fluids (if applicable)
into approved containers and dispose of the product and the fluids according to local regulations.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
important: no liability is accepted for incorrect use of this product.
WarrantY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
