  • Page 1 Model Document MyVallox Control D5311 Valid from 04.02.2020 Updated 31.03.2020 Manual Control panel...
  • Page 2: Table Of Contents

    Settings ........... 20 Compatibility of the MyVallox Control panel ....4 Filter settings .
  • Page 3: Safety

    Children must be supervised and not be allowed to play with the All Vallox ventilation units have been designed to provide device. appropriate and continuous ventilation so as to present no threat to health and to maintain structures in good condition.
  • Page 4: Disposal Of The Ventilation Unit

    Vallox 110 MV, ValloPlus 350 MV, ValloPlus 350 MV-E 3702, A3702 Vallox 145 MV, ValloPlus 510 MV, ValloPlus 510 MV-E 3712, A3712 Vallox 245 MV, ValloPlus 850 MV, ValloPlus 850 MV-E 3732, A3732 Vallox 245 MV VKL, ValloPlus 850 MV WNH, ValloPlus 850 MV-E WNH 3732, A3732...
  • Page 5: System Description

    Modbus MyVallox Home MyVallox Control VENTILATION UNIT CONTROL Ventilation unit control options. Operation of the Vallox ventilation unit can be controlled by the following means: • Through the control panel installed in the building • Through the MyVallox Home local area network connection and the MyVallox Home/Cloud user interface.
  • Page 6: Connecting The Ventilation Unit To The Cloud Service

    To register your Vallox ventilation unit with the MyVallox Cloud service: Connect one end of the network cable to the grey connector of the Vallox ventilation unit and the other end to the router. 2. Open the network settings on the computer by selecting Start → My Computer →...
  • Page 7: Control Panel Buttons

    The Statistics button opens the temperature, relative humidity of air, carbon dioxide or VOC level graphs (1 day or 1 week). This icon indicates when the feature is turned off at your user level. © Vallox Oy - All rights reserved...
  • Page 8: Starting Up And Shutting Down The Unit

    THE UNIT Unit software We recommend that the latest software version be always used. Check and download the latest version at http://www.cloud.vallox. com either before or immediately after setup. The current software version of the ventilation unit is shown on the control panel display when the unit is connected to the mains or factory settings are restored.
  • Page 9: Setup

    Select Down arrow. The Daylight saving time setting value is changed to Off. 2. The manual daylight saving time setting is now on. 3. Proceed to the next phase by selecting Right arrow. © Vallox Oy - All rights reserved...
  • Page 10: Set The Date

    Set the date Use the Plus and Minus buttons to set the date. 2. Select Right arrow. 3. Use the Plus and Minus buttons to set the month. 4. Select Right arrow. 5. Use the Plus and Minus buttons to set the year. 6.
  • Page 11: Parental Controls

    The fan speed (rpm) will change accordingly. 2. Measure and adjust the supply air flows from the valves. 3. Press the Right arrow button. © Vallox Oy - All rights reserved...
  • Page 12: Ventilation Modes

    4. Use the Plus and Minus buttons to set the extract air fan ratio as a percentage of the maximum output ratio. The fan speed (rpm) will change accordingly. Measure and adjust the extract air flows from the valves. 5. Select OK. Supply and extract air flow settings are now complete.
  • Page 13: Symbols For Ventilation Modes

    CO2 and three shaded bars — The carbon dioxide or VOC level is significantly higher than normal. The fan speed will be automatically increased if automatic adjustment is allowed. Table 2. Ventilation mode symbols © Vallox Oy - All rights reserved...
  • Page 14: Ventilation Mode Settings

    VENTILATION MODE SETTINGS NOTE By default, the fan speed used in the At home mode is the higher of the percentage values set for basic ventilation airflows. We recommend that this basic ventilation setting be used with the At home mode. Once you have set the fan speed for the At home mode, the fan speed for the Away mode will by default be set to -30% of the At home mode fan speed.
  • Page 15: Fireplace Mode

    Fireplace mode as a percentage of the maximum output ratio. 8. The supply air fan speed of the Fireplace mode is now set. 9. Proceed to the next phase by selecting Right arrow. © Vallox Oy - All rights reserved...
  • Page 16: Finishing The Setup

    10. Use the Plus and Minus buttons to set the extract air fan speed of the Fireplace mode as a percentage of the maximum output ratio. 11. The extract air fan speed of the Fireplace mode is now set. 12. Select OK. IMPORTANT The timer function of the fireplace mode can be turned off only when the external fireplace switch has...
  • Page 17: Browsing The Fireplace Mode Information

    Editing the ventilation mode settings Open the main display of the desired ventilation mode. 2. Select Mode information. 3. Select Edit. 4. Make the desired changes as instructed in the section Setup wizard-> Ventilation mode settings. © Vallox Oy - All rights reserved...
  • Page 18: Timer Functions Of The Fireplace And Boost Modes

    Timer functions of the Fireplace and Boost modes In addition, the timer function can be modified in the Fireplace and Boost modes. See Setup wizard-> Ventilation mode settings. TEMPERATURES AND SENSORS Viewing temperature data Select Settings > Temperatures and sensors. 2.
  • Page 19: Viewing The Relative Humidity Of Air And The Carbon Dioxide And Voc Levels Measured By The Sensors

    Carbon dioxide or VOC level statistics for the past You can view the graph for a week or for a single day. week. You can view the graph for a week or for a single day. © Vallox Oy - All rights reserved...
  • Page 20: Settings

    SETTINGS Filter settings Select Settings > Filters. 2. Select OK. 3. The summary display of filter replacement shows the following information: • Filters replaced — Indicates the date when the filters were last replaced. • Reminder interval — Indicates the filter replacement interval in months.
  • Page 21: Filter Maintenance Reminder

    4. Select OK. The MyVallox Control panel automatically switches to the sleep mode when the pre-set Sleep time has elapsed. To reactivate the MyVallox Control panel, press any button. Adjusting the display brightness Select Settings > Display settings. 2. Select OK.
  • Page 22: Time And Date

    TIME AND DATE Setting the time and date The available time settings are: • Time • 24- or 12-hour clock • Automatic daylight saving time • Date NOTE The ventilation unit time will withstand a power cut of a few hours. Setting the time Select Settings >...
  • Page 23: Setting The Date

    6. Use the Down arrow button to select the desired time. Use the Select button to browse and select the ventilation mode that will be turned on at the chosen time. The icons are: At home mode. Away mode. Boost mode. © Vallox Oy - All rights reserved...
  • Page 24: Turning The Week Clock On

    8. Once you have selected the modes for the week clock, select Settings. 9. Select OK, if you want to save the changes made to the week clock. Select Cancel, if you do not want to save the changes. Select Back, if you want to go back to editing the week clock.
  • Page 25: Turning The Unit Off

    This keeps the indoor air fresh and prevents humidity from condensing in the ventilation ducts and structures. It also reduces the risk of moisture damage. To re-start the ventilation unit, press any key. © Vallox Oy - All rights reserved...
  • Page 26: Troubleshooting

    TROUBLESHOOTING NOTE Error messages are displayed on the control panel and in the MyVallox Home and MyVallox Cloud services. FAULT CAUSE MEASURES Error message: The extract air fan has stopped. Make sure that the fan is not running. The fan cabling and Extract air fan operation must be checked, and if necessary the fan must be replaced.
  • Page 27: User Level Diagrams

    Bypass settings of the HR cell External sensor settings Display settings Heating settings Panel address Professional settings Modbus settings Basic fan settings Turn unit off I/O and bus settings Lock code and access rights Defrost settings © Vallox Oy - All rights reserved...
  • Page 28 Vallox Oy | Myllykyläntie 9-11 | 32200 LOIMAA | FINLAND Customer service +358 10 7732 200 | Aftersales +358 10 7732 270 © Vallox Oy - All rights reserved...
