ENDA ETC1311 Quick Start Manual

Read this document carefully before using this device. The guarantee will be expired by
damaging of the device if you don't attend to the directions in the user manual. Also we don't
accept any compensations for personal injury, material damage or capital disadvantages.
ENDA ETC1311 DIGITAL THERMOSTAT
Thank you for choosing ENDA ETC1311 temperature controller.
* 35 x 77mm sized.
* On-Off control.
* TC Typ "J" or "K" or Pt100 input.
* Temperature compensation.
* In the case of probe failure, heating can be
selected on, off or periodical running.
* Upper and lower limits of the setpoint can be
adjusted.
* Set value can be adjusted by using single key.
* Having CE mark according to European Norms.
Order Code : ETC1311- -
1 2
1 - Input 2 - Supply Voltage
FE.....Fe-Const (J) 230VAC...230V AC
RT.....Pt100
24VAC.....24V AC
K.......NiCr-Ni (K) 12VAC.....12V AC
SM...........9-30V DC / 7-24V AC
Attention !
ENDA ETC1311 is intended for installation in control panels. Make sure that the device is
used only for intended purpose. The electrical connections must be carried on by a
qualified staff and must be according to the relevant locally applicable regulations. During
an installation, all of the cables that are connected to the device must be free of energy.
The device must be protected against inadmissible humidity, vibrations, severe soiling
and make sure that the operation temperature is not exceeded. The cables should not be
close to the power cables or components.
ENDA ENDA
INDUSTRIAL ELECTRONICS INDUSTRIAL ELECTRONICS
ETC1311-K-230VAC ETC1311-FE-230VAC-P
DIGITAL THERMOSTAT DIGITAL THERMOSTAT
SN: XXXXXXXXX
K (NiCr-Ni)
-
+
1 2 3 4 5 6 7 8 9 10 11 12 1 2 3 4
Equipment is protected throughout
by DOUBLE INSULATION.
NOTE:
Fuse
F 100 mA
SUPPLY:
Switch
250V AC
4 Line
184-253V AC
50/60Hz 3VA
5
Neutral
Fuse should
Cable size: 1,5mm²
be connected
OUT
ENDA
-
3

3 - Output

P......... Relay-16A
None...Relay-8A
SSR....Logic output
ENDA
INDUSTRIAL ELECTRONICS
ETC1311-RT-12VAC
DIGITAL THERMOSTAT
SN: XXXXXXXXX
J (Fe-CuNi)
-
+
5 6 7 8 9 10 11 12 1 2 3 4 5 6 7 8
Holding screw 0.4-0.5Nm
Note:
1) Mains supply cords shall meet the requirements of
IEC 60227 or IEC 60245.
230V AC
2) In accordance with the safety regulations, the power
Supply
supply switch shall bring the identification of the
relevant instrument and it should be easily
accessible by the operator.
english

Technical Specifications

ENVIRONMENTAL CONDITIONS

Ambient/storage temperature
Max. relative humidity
Rated pollution degree
Height
Do not use the device in locations subject to corrosive and flammable gasses.

ELECTRICAL CHARACTERISTICS

Supply voltage /
Power consumption
Wiring
°C Scale
Sensitivity /Accuracy
PRG
SET
Indicator
EMC
ETC1311
Safety requirements
OUTPUT
HEAT OUT
Life expectancy for relay

CONTROL

Control type
Control algorithm
Hysteresis

HOUSING

Housing type
Dimensions
Weight
Enclosure material
While cleaning the device, solvents (thinner, benzine, acid etc.) or corrosive materials must not be used.
Dimensions
OUT
SN: XXXXXXXXX
ENDA
Pt100
9 10 11 12
SURAN Industrieelektronik
Dettinger Str. 9
D-72160 Horb a.N.
0 ... +50°C/-25 ... 70°C (with no icing)
80 , up to % 31°C decreasing linearly 50% at
According to EN 60529 Front panel : IP65
Rear panel : IP20
Max. 2000m
230VAC +10%/-20%, 50/60Hz, 24VAC±10%,50/60Hz or 24Vac/dc (9-30Vdc or 7-24Vac)
Max. 4VA
2.5mm² screw-terminal connections.
TE Typ "J" or "K": 0 ... +600°C / Pt100: -100...600°C
± 0.5% (of full scale) / ± 1 digit
3 digits, 14mm, 7 parts red LED
EN 61326-1: 1997, A1: 1998, A2: 2001 (Performance criterion B is satisfied for EMC tests.
The device is designed to operate in controlled electromagnetic environment)
EN 61010-1: 2001 (Pollution degree 2, overvoltage category II)
For ETC1311-XX ; Relay: 250V AC, 8A( for resistive load
For ETC1311-XXP ; Relay: 250V AC, 16A(for resistive load), NO.
For ETC1311-XX ; Mechanical 30.000.000; Electrical 100.000 operation.
For ETC1311-XXP ; Mechanical 30.000.000; Electrical 30.000 operation.
Single-setpoint control
On-Off control
Adjustable between 1 ... 20°C.
Suitable for flush-panel mounting.
W77xH35xD71mm
Approx. 250g ( after packing the device and a probe
Self extinguishing plastics
77mm
For removing mounting clamps:
Push out the flush-mounting
°C
clamp in direction 1 as shown
PRG
SET
in the figure below. Then, pull
out the clamp in direction
ETC1311
Flush mounting
clamp

Panel cut-out

71mm
1
Tel.: +49 (0)7451 / 625 617
Fax: +49 (0)7451 / 625 0650
40 °C
), NO+NC.
)
Depth
71mm 5mm
2.
Flush mounting 2
Panel
Rubber
clamp
packing
Note : 1) Panel thickness
should be maximum
7 mm.
2) If there is no 60mm
free space at the back
side of the device, it
would be difficult to
remove it from the
Panel
1./2 ETC1311-E
E-mail : info@suran-elektronik.de
Internet : www.suran-elektronik.de
