Overland Storage NEO Agility 48 10GbE Card Instructions

Add-on/Spare 10GbE Card Instructions
This document describes how to either add a new, or remove
and replace an existing, 10Gb Ethernet card in a NEO
Agility 48 appliance from Overland Storage.
WARNING:
To reduce the risk of electric shock or damage to
equipment, always remove any power cords while working with
the appliance.
WARNUNG: Um das Risiko eines elektrischen Schlags oder
Schäden am Gerät zu vermeiden, ziehen Sie stets den
Netzstecker, bevor Sie an der Einheit arbeiten.
AVERTISSEMENT:
Pour réduire le risque de choc électrique
ou endommagement de l'équipement, retirez toujours les
cordons électriques en travaillant avec l'appareil.
CAUTION:
While working with the appliance, observe
standard Electrostatic Discharge (ESD) precautions to prevent
damage to micro-circuitry or static-sensitive devices.

Prepare the Appliance

Power Appliance Off

CAUTION:
To prevent data corruption and loss, verify that all
processes are inactive and idle before shutting down the NEO
Agility appliance.
1. Using either console or remote desktop, log into the
appliance as an administrator.
2. Verify that all host processes are idle.
3. From the Agility Management Console, verify that all
queued tape write operations have completed.
Review the last entries in the Diagnostics > System log for
the Flush Cache > SUCCEEDED events for all tape
drives.
4. Right-click the Windows logo in the lower-left corner and
select Shutdown or sign out > Shutdown.
5. When all the LEDs are off, disconnect the power cords
from their sockets.
6. Disconnect the remaining cables from the unit ports,
noting their locations.

Remove the Bezel

1. If needed, use the supplied key to unlock the bezel.
2. Press in the latch on the right to release the bezel.
3. Carefully swing the bezel out, remove it from the
appliance, and set it aside.
10400839-001
Power Sockets
©2017 Overland Storage, Inc.
NEO Agility 48 Appliance
®
System Log
Cable Ports
Page 1 of 4
