  • Page 1 A DIRECT HEALTHCARE GROUP COMPANY EASY SoftBack Technical Manual G AT E R D . S E...
  • Page 2 EASY SO FTB ACK G ATE RD .SE...
  • Page 3: Table Of Contents

    TEC HN I CAL MANU AL EASY SoftBack EASY is a well-designed hygiene stool with a great many advanced functions. The hygiene chair is designed with telescoping pillars to create as much space and flexibility as possible for care personnel. The chair is suitable for use in shower and toilet environments in care institutions and at home.
  • Page 4: Parts List

    EASY SO FTB ACK 1. Detaljförteckning 57-283-EASY Headrest for SB incl. attachment 58-220-1 Backrest SB 57-288-2 Armrest lock 58-245-L/R Armrest SB (left/right), alloy detail only 58-209 Handrest 58-285-1 Seat frame SB 57-250-1 Plastic seat 56-233 Plastic seat/keyhole, green 58-280-L/R Pillars complete (Left / Right) 58-277 Holder (footrests) 58-283-1-L/R...
  • Page 5 TEC HN I CAL MANU AL G ATE RD .SE...
  • Page 6: Accessories

    EASY SO FTB ACK 3. Accessories Part no. Description 56-205 Shower seat around hole 56-206 Soft PU seat 56-212-EASY Barrier (52cm), Easy 56-213 Splashback 56-214 Armrest lock (M8) 56-216 Infill 56-217 Waist belt / Thigh belt, Hygiene chairs 56-218 Slides 56-220-EASY Heel strap kit (pair), Easy 56-221...
  • Page 7: Cleaning And Maintenance

    TEC HN I CAL MANU AL 4. Cleaning and maintenance The chair is made of stainless steel pipes (powder coated) and aluminium. Exposed details that have not been painted are made of aluminium or stainless steel. Be sure to check that the product feels stable / slip-free - no loose screw joints may be present.
  • Page 8 EASY SO FTB ACK Check thoroughly (at least once a year) 1. Armrests - so that the slip guard / wrist guard is intact and fixed. 2. Pillars - Calibrate the chair and then check its functionality with the remote control. Make sure the pillars (up / down) are synchronous and feel loose.
  • Page 9: Replacement Of Remote Control

    TEC HN I CAL MANU AL 5. Replacement of remote control Incorrect remote control is easily changed by releasing the contact / remote control on the left pillar - new remote control is mounted in the same way. NOTE: It is important that contact is locked with the clamp lock to ensure IP X5. 6.
  • Page 10: Troubleshooting When Chair Cannot Be Operated

    EASY SO FTB ACK 8. Troubleshooting when chair cannot be operated NOTE: Chair cannot be operated over seat height 65cm if chair is tilted forward. Seat can also not be tilted forward if seat height is higher than 65cm. Before starting troubleshooting - always restart the battery (see below - hold the battery OFF) button for about 5 seconds.
  • Page 11: Id Label

    The battery is given a 6 month warranty on manufacturing defects. For more information or questions please contact: Gate Rehab Development AB Industrigatan 2, S-333 75 Reftele tel 0371-318 00 info@gaterd.se www.gaterd.se A DIRECT HEALTHCARE GROUP COMPANY G ATE RD .SE...
  • Page 12: Technical Specification

    EASY SO FTB ACK 12. Technical specifications Material Aluminium Plastic (PP, PP/GS, PA, PA/GS, TPE, Silicone) Textile Dartex Foam (PUR) Steel (Stainless) Frame / stand Powder coating (polyester) Specification power system Actuator Raise/lower/pillars Tilt function Voltage Lift 100kg/pelare 150 kg Stroke 400 mm 75 mm...
  • Page 13 TEC HN I CAL MANU AL Wiring Diagrams / Control box The control box is reached by removing the protective cap - 4 screws. Control box with battery with removed cover. Actuators (2x up / down and 1x tilt), The actuators are connected directly to the control box as below. Remote control and battery are connected via spindle cable to control box as below.
  • Page 14: Information On Emc

    EASY SO FTB ACK Control box (A): Spindle cable (B): 1. Connection connector # 1 / Spindle cable 1. Connects to input # 1 on control box 2. Actuators up / down - left 5. Remote control 3. Actuators up / down - right 6.
  • Page 15 TEC HN I CAL MANU AL The product is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Electromagnetic Immunity test IEC 60601 test level Compliance level environment - guidance Floors should be wood,...
  • Page 16 EASY SO FTB ACK The product is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Immunity test IEC 60601 test Compliance level Electromagnetic environment - guidance level Portable and mobile RF communications...
  • Page 17: Dimensions

    TEC HN I CAL MANU AL 15. Dimensions All dimensions in millimeters and with 125 mm wheels. When using Double wheels / 100mm, width over wheels increases by + 30mm. G ATE RD .SE...
  • Page 18 EASY SO FTB ACK G ATE RD .SE...
  • Page 19 TEC HN I CAL MANU AL G ATE RD .SE...
  • Page 20 A DIRECT HEALTHCARE GROUP COMPANY Gate Rehab Development AB Industrigatan 2 Reftele, Sverige S-330 21 T: 0371-318 00 F: 0371-318 01 E: info@gaterd.se LIT-00116 Issue 1 Date: January 2020 G AT E R D . S E...
