Opus OFFICERINO User Manual

User's guide OFFICERINO
User's guide
OFFICERINO

Safety precautions

•
Before operating the machine please read the user's guide carefully.
Operate machine according to the user's guide. Pay special attention to
the max punching and binding capacity.
•
The machine should be kept out of children's reach.
•
Do not use the machine to punch hard materials, such as metal → it may
cause the damage.
•
Pay special attention while stretching the plastic comb. Do not reach or put
fingers into the open comb → danger of injury!
•
The machine should be protected against dust and moisture. Do not allow
any liquid to get inside the unit.

Recommendation

•
Use only recommended supplies or acessories from OPUS company
•
The machine is designed to bind documents with the plastic combs only
•
Unpack and install all the elements of the device and put it on a sturdy and
level surface
•
Before punching important documents, test the settings of the machine on
a sheet of paper.
•
The machine punches 15 sheets of paper. The plastic cover should be
punched separately! Do not exceed max punching capacity!.
•
In OPUS Officerino blades were oiled to protect them from the corrosion
and to ensure comfortable operation. Before operating machine for the first
time punch some piece of paper few times to clean up the blades.

Choosing the comb size

Choose proper comb size using the table below. Adjust comb size to the
quantity of binding paper sheets, e.g. use 16mm comb to bind 145 sheets of
paper.
Max binding sheets 10 25
Comb size 4,5 6
Max binding sheets 180 210
Comb size 20 22
User's guide OFFICERINO
45 65 105 125 145
8 10 12 14 16
240 270 300 350 440
25 28 32 38 45
165
18
