BRK electronic PRC710VB Quick Start Manual

SMOKE & CO
COMBO
A L A R M
1 0 - Y E A R S E A L E D
PRC710VB
CAT.
LOW PROFILE DESIGN
Sleek, contemporary design blends into
any décor.
10-YEAR
LITHIUM POWER
10 years of continuous protection.
No battery change required. Provides
audible notice when alarm has reached
its end of life.
TAMPERPROOF
SEALED ALARM
Powercell cannot be removed.
VOICE WARNING
WITH LOCATION
Exclusive! A voice will tell you the
programmed location of the unit and
danger detected.
ELECTROCHEMICAL CO
SENSOR
Most accurate technology available for
detecting carbon monoxide as com-
pared to other sensing technologies.
PHOTOELECTRIC
Photoelectric technology is generally
more sensitive at detecting large par-
ticles, which tend to be produced in
greater amounts by smoldering fires.
SILENCE FEATURE
Silences nuisance alarms.
Sealed 3V Lithium Power Cell
Description:
BRK PRC710VB (model PC1210V) is a 3V lithium power cell operated single sta-
tion photoelectric smoke and carbon monoxide combination alarm specifically
designed for residential and institutional applications including sleeping rooms of
hospitals, hotels, motels, dormitories, and other multifamily dwellings as defined
in standard NFPA 101. BRK PRC710VB has been fully tested and complies with,
UL217, UL2034, CSFM, NFPA 72, NFPA 720, NFPA 101 and other agencies that
model their codes after the above agencies. It meets building codes where tam-
perproof 10-year sealed lithium battery operated photoelectric smoke and carbon
monoxide combination alarms with voice are required and with model building
codes published by the ICC.
BRK PRC710VB is a state of the art smoke and CO combination alarm designed to
provide early warning of a fire or carbon monoxide danger. It features a photoelec-
tric smoke sensing chamber, an electrochemical CO sensor and "Voice Warning
with Location". This exclusive feature incorporates a voice that will speak one of
11 pre-programmed locations and the danger detected. When the alarm sounds (if
programmed for "basement", for example) it will speak "Warning, evacuate, smoke
in basement". It features a sealed 10-year lithium power cell power supply that is
permanently installed. The tamperproof design will not allow the powercell to be
removed. The low power warning indicator will cause the alarm to "chirp" when it
reaches the end of its service life and needs to be replaced. Upon end of life, the
unit meets UL requirements for disabling the alarm and non-reinstallation of unit
to mounting bracket. It also features a tamper resistant locking pin that locks the
alarm to the mounting bracket to prevent removal of the alarm. Designed for wall or
ceiling mounting. Includes
mounting anchors
and screws.
