BRK electronic PRC700VB Quick Start Manual

SMOKE & CO
COMBO
A L A R M
P H O T O E L E C T R I C
PRC700VB
CAT.
LOW PROFILE DESIGN
Sleek, contemporary design blends into
any décor.
VOICE WARNING
WITH LOCATION
Exclusive! A voice will tell you the
programmed location of the unit and
danger detected.
ELECTROCHEMICAL CO
SENSOR
Most accurate technology available for
detecting carbon monoxide as com-
pared to other sensing technologies.
PHOTOELECTRIC
Photoelectric technology is generally
more sensitive at detecting large par-
ticles, which tend to be produced in
greater amounts by smoldering fires.
10 YEAR END OF LIFE
10 Year CO Sensor and end of life. Pro-
vides audible notice when alarm needs
to be replaced. (Note: Batteries do not
last 10 years and are not tamper proof.
Use PRC710VB for these features.)
SILENCE FEATURE
Silences nuisance alarms.
3V (two 1.5V AA) Alkaline Battery Powered
Description:
BRK PRC700VB (model PC1200V) is a battery operated single station photoelectric
smoke and carbon monoxide combination alarm specifically designed for residen-
tial and institutional applications including sleeping rooms of hospitals, hotels, mo-
tels, dormitories, and other multifamily dwellings as defined in standard NFPA 101.
BRK PRC700VB has been fully tested and complies with, UL217, UL2034, CSFM,
NFPA 72, NFPA 720, NFPA 101 and other agencies that model their codes after
the above agencies. It meets building codes where battery operated photoelectric
smoke and carbon monoxide combination alarms with voice are required and with
model building codes published by the ICC.
BRK PRC700VB is a state of the art smoke and CO combination alarm designed to
provide early warning of a fire or carbon monoxide danger. It features a photoelec-
tric smoke sensing chamber, an electrochemical CO sensor and "Voice Warning
with Location". This exclusive feature incorporates a voice that will speak one of
11 pre-programmed locations and the danger detected. When the alarm sounds (if
programmed for "basement", for example) it will speak "Warning, evacuate, smoke
in basement". It features a Sweeping Horn Tone that has a lower and varying fre-
quency that makes it easier for the elderly with normal age related hearing loss to
hear the horn. Two AA alkaline batteries power supply, 10 Year CO sensor, 10 Year
End of Life feature and single button test/silence. This alarm has two silence fea-
tures. Low Battery Silence: Temporarily silence the low battery chirp for up to eight
hours. Alarm Silence: Silence alarm for several minutes. It also features a tam-
per resistant locking pin that locks the alarm to the mounting bracket to prevent
removal of batteries or alarm. De-
signed for wall or ceiling
mounting. Includes
mounting an-
chors and
screws.
