Front View - SCHEU Biostar Operation Manual

The basic components of the Biostar Scan With LCD Display include:
B
On/Off Switch:
Infrared Heater:
Control Panel:
Locking Handle:
Barcode Scanner:
Pellet Cup:
Platform*:
Pellet Drawer:
Pressure Chamber:
Locking Ring Clamp:
Magnetic Brush**:
I
H
C
Supplies electricity to operate the machine.
Found on left side of unit, swings from back of machine (rest position),
forward over thermal plastic held on the chamber.
Contains operating controls including keypad operation input buttons,
air pressure evacuation button, and digital operating viewing panel.
Locks chamber onto pellet cup/platform and switches air pressure on.
Automatically enters the correct processing information for the thermal
plastic.
Used in every pressure-forming process and can be removed from the
Biostar table for cleaning. The pellet cup holds the dental model, pellets,
and platform.
Circular plate that is placed on the inner lip of the master
pellet cup, to be used in place of pellets.
Removable front compartment that holds unused pellets.
Thermal plastic is held and air pressure incorporated for molding.
Circular metal clamp that secures material to the pressure chamber.
Used to control pellet placement and remove the platform
from the pellet cup.
F
E
G

Front View

D
A
On/Off Switch
B
Infrared Heater
C
Control Panel
D
Locking Handle
E
Barcode Scanner
F
Pellet Cup
G
Pellet Drawer
H
Pressure Chamber
I
Locking Ring Clamp
A
J
Platform*
K
Magnetic Brush**
J
K
