SYNAPSIS ECDIS

OPERATOR MANUAL

Version: E02.00 or higher

4343.DOC012 Edition: November 2019

Raytheon Anschütz GmbH

Postfach 1166

D - - 24100 Kiel

Germany

Tel +49- -4 31- -30 19- -0

Fax +49- -4 31- -30 19- -501

Email Service@raykiel.com

www.raytheon- - anschuetz.de

Table of Contents

Summary of Contents for Raytheon Anschütz SYNAPSIS ECDIS

Page 1 Raytheon Anschütz GmbH Postfach 1166 D - - 24100 Kiel Germany Tel +49- -4 31- -30 19- -0 Fax +49- -4 31- -30 19- -501 Email Service@raykiel.com www.raytheon- - anschuetz.de SYNAPSIS ECDIS OPERATOR MANUAL Version: E02.00 or higher 4343.DOC012 Edition: November 2019...
Page 2 Stand 12/2013 Version 12/2013 Dieses Dokument sowie dessen Inhalt sind This document and its content are copyright urheberrechtlich geschützt. Die Weitergabe, protected. Distribution, reproduction and Vervielfältigung und Speicherung sowie die storage as well as translation and exploitation Übersetzung wie auch Verwendung dieses of this document and its content, in whole or Dokuments oder dessen Inhalts, als Ganzes in parts and regardless of what form, are...
Page 3 Stand 12/2013 Version 12/2013 Dieses Dokument sowie dessen Inhalt sind This document and its content are copyright urheberrechtlich geschützt. Die Weitergabe, protected. Distribution, reproduction and Vervielfältigung und Speicherung sowie die storage as well as translation and exploitation Übersetzung wie auch Verwendung dieses of this document and its content, in whole or Dokuments oder dessen Inhalts, als Ganzes in parts and regardless of what form, are...
Page 4: Table Of Contents
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Table of Contents Introduction ............. .
Page 5 Operator Manual Table of Contents Ship Symbols In the Chart Area ..........2--19 2.6.1 Circle...
Page 6 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Table of Contents 4.3.4 ENC + CM93/3 Chart Catalog ..........
Page 7 Operator Manual Table of Contents Options Menu ............5- -1 Options Menu ARCS .
Page 8 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Table of Contents Display Menu ............
Page 9 Operator Manual Table of Contents 7.1.8 Man Overboard ............7--9 7.1.9 Clear or Cancel Man Overboard -- Alarm...
Page 10 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Table of Contents 8.2.12 Route Monitoring ............
Page 11 Operator Manual Table of Contents 10.1.1 Plot Layer Description ........... . 10--2 10.1.1.1 Example .
Page 12 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Table of Contents 12.1.9 INS Test Alert ............
Page 13 Operator Manual Table of Contents 16.4 Options Dialog ............16--11 16.4.1 Info Dialog .
Page 14 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany List of Abbreviation NOTE Many of these definitions have been adapted from the “Glossary of ECDIS-Related Terms,” published by the International Hydrographic Bureau, 2nd Edition, September 1993. Term Description BACKSPACE THE BACKSPACE KEY; USED TO ERASE CHARACTERS TO THE LEFT OF THE VERTICAL BAR.
Page 15 Operator Manual Table of Contents Term Description CLICK AND DRAG A TRACKBALL TECHNIQUE IN WHICH YOU POINT TO AN ITEM OF CHOICE, PRESS THE [Left] TRACKBALL BUTTON, MOVE THE CURSOR TO THE DESIRED POSITION, THEN RELEASE THE BUTTON. CM93/3 JEPPESEN C- -MAP PROPRIETARY CHART DATABASE FORMAT COURSE OVER GROUND COMMAND A WORD OR PHRASE FOUND IN A MENU.
Page 16 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Term Description ELECTRONIC NAVIGATIONAL CHART - THE DATABASE, STANDARDIZED AS TO CONTENT, STRUCTURE AND FORMAT, ISSUED FOR USE WITH ECDIS ON THE AUTHORITY OF GOVERN- MENT AUTHORIZED HYDROGRAPHIC OFFICES. THE ENC CONTAINS ALL OF THE CHART...
Page 17 Operator Manual Table of Contents Term Description MMSI MARITIME MOLILE SEVICE IDENTITY MOUSE A REMOTE POINTING DEVICE. ALSO REFERRED TO AS A TRACKBALL. MESSAGE NAV panel NAVIGATION PANEL NAVIGATIONAL AID ANY INSTRUMENT, DEVICE, CHART, METHOD, ETC., USED ONBOARD, INTENDED TO ASSIST IN THE NAVIGATION OF A CRAFT.
Page 18 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Term Description SAFETY CONTOUR THE CONTOUR RELATED TO THE OWN SHIP AND USED BY THE ECDIS TO DISTINGUISH ON THE DISPLAY BETWEEN SAFE AND THE UNSAFE WATER, AND FOR GENERATING ANTI- GROUNDING ALARMS. THE SAFETY CONTOUR INFORMATION IS ENTERED IN THE SHIP INFO DIALOG BOX (INTEGRATION MENU).
Page 19 Operator Manual Table of Contents Term Description WEND WORLDWIDE ELECTRONIC NAVIGATIONAL CHART BASE THE ABBREVIATION FOR “WORLD GEODETIC SYSTEM”. THIS SYSTEM WAS DEVELOPED BY THE USA FOR SATELLITE POSITION FIXING AND RECOMMENDED BY IHO FOR HYDRO- GRAPHIC AND CARTOGRAPHIC USE. WGS84 IS THE CURRENT SYSTEM IN USE (84 REFERS TO THE YEAR).
Page 22: Introduction
SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Introduction ECDIS is an integrated software controlled navigation system with advanced electronic chart capabilities including: -- route planning -- route monitoring -- ground monitoring It enables a navigator to do all navigational routines which are done on paper charts.
Page 23 Operator Manual NOTE All charts are displayed in a ”North--up” orientation. Datum is always WGS 1984 (World Geodetic System). ECDIS chart capabilities are: o IHO--S57 o IHO--S63 (encrypted) o Jeppesen / C--MAP CM93/3 SENC distribution Raster Charts (RNC) o ARCS Unofficial charts o Jeppesen / C--MAP CM93/3 World or Professional + Database NOTE...
Page 24: Types Of Charts
SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Types Of Charts ECDIS displays the type and scale of the displayed chart in the information panel. As you change the scale of the display, or center the display on other areas, the type of the chart being displayed may change, indicating that ECDIS is displaying a more appropriate chart.
Page 25: Charting Capabilities For Enc
Operator Manual Following ECDIS functions are only available with the CM93/3 databases (except world database): Tidal Prediction (chapter 9.1.8) Automatic Route Planning and Port Information (chapter 8.2.2) 1.1.2 Charting Capabilities for ENC The provision of a timely, reliable worldwide uniform ENC data distribution ser- vice is a major organizational challenge.
Page 26 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany yet. A number of nations are still distributing their ENCs individually (e.g. Japan Hydrographic Office, Australian Hydrographic Office, USA -- NOAA) either through chart data suppliers or directly. Principally, WEND focuses on the supply and distribution of ENCs by facilitating the establishment of services intended to satisfy the SOLAS carriage require- ment for up--to--date charts.
Page 27: Charting Capabilities For Arcs Chart Types
Operator Manual 1.1.3 Charting Capabilities for ARCS Chart Types ARCS sea charts (Raster--data--format) ARCS means Admiralty Raster Chart Service. This institution scans sea charts of the British Admiralty (BA) in a raster--data--format. Such a manner scanned sea charts are available on CD--ROM as Raster Nautical Charts (RNCs) with a worldwide coverage.
Page 28: Display Organization
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Display Organization Cursor Information Panel MFC Switch chapter 2.5 chapter 2.7 Menu Bar Tool Bar chapter 2.10 chapter 2.2 chapter 2.4 Chart Area Status Bar chapter 2.9 chapter 2.8 NSC Remote Panel...
Page 29: First Steps In Operation
Operator Manual First Steps in Operation This chapter describes following basic functions: Starting the ECDIS (chapter 2.1.1) Terminating the ECDIS (chapter 2.1.2) How to use the Cursor (chapter 2.1.3) How to handle the Operator Panel (chapter 2.1.4) 2.1.1 Starting the ECDIS Positioned on front, lower right side.
Page 30: How To Use The Cursor
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany 2.1.3 How to Use the Cursor When using the trackball, the cursor is moved by rolling the ball in the appropriate direction. left middle right Figure: 2--2 Trackball The trackball is equipped with three buttons.
Page 31 Operator Manual commands indicating actions that can be performed on the object. MFC switch and context menu. Call up the MFC Switch, place the cursor over the “Raytheon Anschütz” field and press the Right button. 2.1.4 Operator Panel The operator panel is designed to execute the most commonly used functions. Signaling: Illumination of the keys and status indicators is switched on when the relevant action is activated.
Page 32 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Status indicators, press toggle switch (7). The function activated is indicated by ). Use the dial (16) to adjust the Gain. Use the dial (11) to adjust the Sea. The Gain control adjusts the sensitivity of the radar video.
Page 33 Operator Manual Press and hold the button. The Heading Line disappears during this time. Press button to change VECTOR LENGTH. Center to reset your own ship to the middle of the PPI or to activate OFF Center. Dial, see 1/6. 2--6 4343DOC020102 Edition: January 2016...
Page 34: Ascii Keyboard Techniques (Option)
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany 2.1.5 ASCII Keyboard Techniques (Option) If available, you have two options for activating a command from the keyboard: S Use shortcuts S Use the arrow keys 2.1.5.1 Shortcuts Shortcuts are referenced in the manual as <Alt+X> where Alt is the [Alt] key and X is a letter key.
Page 35: Menu Conventions
Operator Manual 2.2.1 Menu Conventions The ECDIS, like other Windows programs, follows certain conventions when listing command names: Ellipsis (...) -- Before it carries out the command, the ECDIS will prompt you for more information by displaying a dialog box. Check mark () -- The command is a ”toggle”...
Page 36: Using The Windows And Dialog Boxes
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Using the Windows and Dialog Boxes 2.3.1 Closing a Menu If you decide not to access a command, you can close a menu. Closing a menu with the trackball Point to any part of the screen outside the menu and click.
Page 37: Specify A Coordinate Using The Trackball
Operator Manual 2.3.4 Latitude / Longitude Boxes Latitude and Longitude boxes are two areas grouped together in a box: a Degrees/minutes text box, in which you enter degrees/minutes; Hemisphere Boxes Figure: 2--6 Latitude and Longitude Boxes 2.3.4.1 Specify a Coordinate Using the Trackball 1) Type the desired hemisphere.
Page 38 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Figure: 2--7 Right Trackball menu These menus will close automatically after some seconds or they may be closed by the Cancel command. The dots behind the Cancel command indicate the timeout for the automatic close.
Page 39 Operator Manual Figure: 2--8 Object info for S--57 chart format Select an Object and Send to Radar Objects with special info (e.g. coastline or restricted area) activates the Send to Radar button in the Object Info window (Figure: 2--9). To transfer e.g. the coastline to the Raytheon Radar push the Send to Radar button.
Page 40 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Figure: 2--9 Object info and Send to Radar function Information in .tif format. Information in .txt format. Figure: 2--10 Special object infos 2--13 Edition: January 2016 4343DOC020102...
Page 41: Tool Bar
Operator Manual Tool Bar The tool bar, Figure 2--22, provides quick access to many ECDIS commands. 9 10 12 13 14 15 16 17 Figure: 2--11 Tool Bar Previous View -- Retrieves the view which was displayed prior to the current view.
Page 42 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Fixed EBL -- Allows you to draw an electronic bearing line which displays the range and bearing from the ship to a set point, see “Electronic Bearing Line”, chapter 9.1.1. Mark At Ship -- Places a mark at the ship‘s current location, see “Placing Ship Marks”, chapter 7.1.4.
Page 43: Customization
Operator Manual 2.4.1 Customization Besides the preconfigured tool bar keys additional keys may be added by a configuration dialog. To start customization press the right trackball key inside the empty toolbar space and select Customize (see Figure: 2--12). To remove all buttons, select Reset to default. Figure: 2--12 Tool Bar Customization activation The customization dialog is shown (see Figure: 2--13) and buttons from the left list (available buttons) may be moved to the right list (active buttons), and...
Page 44 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Currently available buttons which are described in more detail further down in this manual: Figure: 2--14 Available customizable buttons 1) Route Manager -- Open Route Manager. Additional drop--down items (Edit/Create Primary Route, Edit/Create Secondary Route, Toggle Routes, Route Monitoring, Track Control).
Page 45: Cursor Symbols
Operator Manual Cursor Symbols The cursors, Figure: 2--15, located at the bottom left of your screen displays cursor information. You can move the cursor using the trackball. The cursor appears as a variety of shapes and enters a variety of modes. By default, it remains in Center on Cursor mode unless a command is being performed.
Page 46: Ship Symbols In The Chart Area
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Ship Symbols In the Chart Area The ship symbol can be displayed as one of two symbols, a circle or a rectangular ship symbol. 2min 4min 6min This symbol adjusts to the scale of the chart.
Page 47: Information Panel
Operator Manual Information Panel The ECDIS integrates information from the following shipboard sensors: GPS, ARPA radar, autopilot, gyro, echo sounder, speed log, engine RPM sensor, rudder position sensor, as well as optional secondary position sensors such as Loran C. The information is integrated into the information panel and graphical displays which allow the navigator to interpret the data in a single glance.
Page 48 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany NAV Information Panel TRACK Information Panel Manua Figure: 2--19 Information Panel, *) Route Description 2--21 Edition: January 2016 4343DOC020102...
Page 49 Operator Manual Table 2--1 Standard Information Panels Call Outs and Description Pos. No. Description Chart Name -- The name of the chart currently being displayed. View Scale -- The current vertical scale of the display (in nautical miles) and the ratio between the size at which an object is displayed to its actual size.
Page 50: Operational Steering Modes Of Ecdis
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Pos. No. Description Waypoint Next -- Next waypoint No. and waypoint position Track Crs. -- Displays the current Track Course in [deg] from the previous waypoint to the next waypoint. -- shows the Co--ordinated Universal Time.
Page 51 Operator Manual  Switching from steering to track to steering to course/heading -- The active waypoint is cleared and ECDIS switches to course control until a valid heading is entered.  Switching from steering to course/heading to steer to track -- The course line is removed and ECDIS switches to course control if a valid active waypoint is selected and the data transmission between ECDIS and Autopilot is established (see Autopilot Operator Manual for...
Page 52 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Steering Mode Heading Control Defined by an electronic heading or course over ground (course made good), rate of turn and turning radius. Steering may be done manually or by the autopilot. While steering to a course or heading, the information panel will or say ”Heading Control”...
Page 53: Central Alert Management (Cam)
Operator Manual 2.7.1.1 Central Alert Management (CAM) The central alert management is managed from the SYNAPSIS INS. The system is continually monitoring ECDIS, radar, conning and CCRS devices and Software. When it finds a problem, it notifies you through alarms--, warnings-- and caution -- messages.
Page 54: Status Bar Cursor/Chart Center
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Status Bar Cursor/Chart Center The boxes, Figure: 2--24 (below), located at the bottom of the display show a variety of cursor information. The left hand corner box always displays current cursor position while the middle corner box displays distance and bearing from the ship to the cursor location as well as the estimated time of arrival at that location assuming the ship’s current speed and a direct route to that location.
Page 55: Chart Area
Operator Manual Chart Area The chart area is where the ECDIS displays ships, electronic charts symbols, and past tracks. It is also where you will enter waypoints/routes, set markers, and draw lines. The display has optional latitude/longitude grid lines which cover the entire world and are measured in degrees and minutes, with minutes expressed to the hundredth decimal.
Page 56: Enc (C--Map93/3)
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany 2.9.1.1 ENC (C- -MAP93/3) The CM93/3 Database is a seamless product. It consists of different scale layers, corresponding to as many navigational purposes of S57/3; each layer includes electronic charts with similar compilation scale, organized into a continuous coverage.
Page 57: Track Plotter
Operator Manual 2.9.1.2 Track Plotter The ECDIS positions the ship on the electronic chart using information from the GPS or other positioning sensors. The ship symbol is directional and is oriented according to your gyro heading. An optional heading vector (an arrow) and search light (the cone shape) are displayed projecting from the bow of the ship symbol.
Page 58: Mfc Switch (Option)
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany 2.10 MFC Switch (Option) 2.10.1 Using the MFC Switch If a Multifunction Console (MFC) is used for radar, ECDIS and conning the MFC Switch allows the selection from these applications. The MFC Switch is placed on the top right corner of the display.
Page 59 Operator Manual Control Information Service Calling up the Synapsis Service Tool Close All All applications will be closed. The EggShell Utility Selec- tion window appears after some seconds. context menu right trackball key ECDIS application ECDIS task Route Planning ECDIS task Route Monitoring Conning application Conning page Nav Conning page Stat...
Page 60: Changing Display Colors
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany 2.10.1.1 Changing Display Colors Changing display colors in a single ECDIS System, see chapter 6.1.8. Changing display colors in a Multifunction System (MFC) with ECDIS, radar and conning applications used as single system (Console, Black Box Version).
Page 61 Operator Manual Intentionally left blank 2--34 4343DOC020102 Edition: January 2016...
Page 62: Main Menu
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Main Menu Main Menu Commands If your ECDIS system is connected to a printer, you can print the display image. You should note that although the system keeps tracking the ship and processing all other sensor inputs, you cannot interact with ECDIS while printing takes place.
Page 63: Print Setup
Operator Manual 3.1.1 Print Setup The Print Setup command enables you to select and configure your printer. NOTE When printing, ECDIS automatically reverses a black background to white. Procedure: Step 1 Select a printer from the drop--down list. Step 2 Select either a portrait or landscape paper orientation. Step 3 Click on OK.
Page 64: Screenshot
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Display Menu Step 1 Step 2 Step 3 Figure: 3--3 Print Options Dialog Box 3.1.3 Screenshot NOTE This function is only available on systems with USB support, because due to the size of the files the screenshots may only be exported to a USB storage.
Page 65 Operator Manual Procedure: Step 1 Click on Create new Screenshot. Step 2 Click on Capture. The screenshot window will automatically be hidden while the screenshot is generated. Any other windows which are on top of the chart will be captured in the screenshot. Step 1 Step 2 Figure: 3--4 Create new Screenshot...
Page 66: Exit
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Step 1 Step 2 Step 3 Figure: 3--5 Manage Screenshot 3.1.4 Exit NOTE Do not exit from ECDIS by turning off the computer. This may cause to loose plot data or may damage your system! Procedure: Step 1 Select Exit.
Page 67 Operator Manual Intentionally left blank 3--6 4343DOC020102 Edition: January 2016...
Page 68: Chart Menu
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Chart Menu Chart Menu Commands This menu is used for the chart management. Step 1 Goto ARSC Chart Info / Select... ENC + CM93/3 Chart Catalog License " Installation " Updates "...
Page 69 Operator Manual Charts Commands Function 4.10 ENC and Updates CM93/3 4.11 ARCS 4.12 4.13 Chart Server (Option) Rights Allows you to take over the “Chart Server Rights”. Chart Server Rights... (this command indicates the ECDIS status client) 4--2 4343DOC020102 Edition: January 2016...
Page 70: Goto Arcs Or Goto Enc
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Goto ARCS Or Goto ENC This function is available, if the two chart types are stored on the ECDIS. Procedure: Step 1 Select Goto ARSC Chart or Goto ENC Chart. Result: The ECDIS switches over to ARCS chart and inversely to ENC chart.
Page 71: Info / Select
Operator Manual Info / Select Select and view the different charts you have available for the world or the currently displayed region. 4.3.1 Info / Select - - ENC + CM93/3 - - Chart Type Info about ENC and CM93/3 Chart Type The C--MAP 93/3 Database is a seamless product.
Page 72 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Procedure: (Figure: 4--2) Step 1 Select Charts (menu bar). Step 2 Select Info / Select... The dialog box appears. Step 3 Select ENC + CM93/3. Step 4 Point and click on the different chart types (i.e., Harbor, Coastal, etc.).
Page 73 Operator Manual Step 1 Goto ARCS Chart Info / Select... ENC + CM93/3 Chart Catalog Step 2 License " Installation " Updates " Step 3 Step 6 Step 4 Step 5 Figure: 4--2 Select Chart Dialog Box -- ENC + CM93/3-- Command Buttons: Click on View to view the chart and leave the dialog box View...
Page 74: Info / Select -- Dnc -- Chart Type
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany 4.3.2 Info / Select - - DNC - - Chart Type Info about DNC Chart Type The DNC database is a seamless product. It consists of different scale layers, corresponding to as many navigational purposes of DNC; each layer includes electronic charts with similar compilation scale, organized into a continuous coverage.
Page 75 Operator Manual Step 1 Goto ARCS Chart Info / Select... Step 2 ENC + CM93/3 Chart Catalog License " Installation " Updates " Step 3 Step 4 Step 5 Figure: 4--3 Select Chart Dialog Box --DNC-- Command Buttons: Click on View to view the chart and leave the dialog box View open.
Page 76: Info / Select -- Arcs -- Chart Type
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany 4.3.3 Info / Select - - ARCS - - Chart Type Info about ARCS Chart Type ARCS means Admiralty Raster Chart Service. This institution scans sea charts of the British Admiralty (BA) in a raster--data--format. Such a manner scanned sea charts are available on CD--ROM as Raster Nautical Charts (RNCs) with a worldwide coverage.
Page 77: Enc + Cm93/3 Chart Catalog
Operator Manual Procedure: Step 1 Select Charts (menu bar). Step 2 Select Info / Select... The dialog box appears. Step 3 Select ARCS. Step 1 Goto ARCS Chart Info / Select... Step 2 ENC + CM93/3 Chart Catalog License " Installation "...
Page 78 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany ARCS Selection: All installed charts S Show all installed charts in the list box. Select by chart name S Select chart by name. Example: Type in the name of selected sea area, for example “oslo”.
Page 79 Operator Manual Command Buttons: Click on View to view the chart and leave the dialog box View open. Click on View and Close to view the chart and close the View and Close dialog box. 4--12 4343DOC020102 Edition: January 2016...
Page 80 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany 4.3.4 ENC + CM93/3 Chart Catalog This menu function allows you to view and verify the ENC and CM93/3 charts. Procedure: (Figure: 4--5 ) Step 1 Select the Database, e.g. DE. The left list box displays the cell names of of the Database DE.
Page 81 Operator Manual Command Buttons: Click on Verify Update Status for verifying the cells. Verify Update Status Step 1 Select Verify Update Status. Step 2 The Report Options dialog box appears (Fig. 4--6). Step 3 Choose the kind of report (Summary Report or Full Report). Step 4 Choose the filter options (Complete or Filtered by Routes).
Page 82 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Click on Export List to save the content of the left list box Export List as a text file. Summary Click on Summary to create a summary of the status report and an export function into HTML. Detailed cell information is not included in the status report.
Page 83: License Administration For Cm93/3 Licenses
Operator Manual License Administration For CM93/3 Licenses CM93/3 Description 93/3 licences for 93/3 charts are obtained from C--MAP Norway AS and are available for worldwide coverage, one or more zones, one or more areas, or single charts. Licenses can only be used on the system for which they were generated and cannot be transferred to other software or hardware systems.
Page 84: Add License Manually
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany 4.4.1 Add License manually Add License manually allows a license to be entered manually. Procedure: (Figure: 4--8) Step 1 Select Charts (menu bar). Step 2 Select CM93/3 License..The dialog box appears.
Page 85: Expired Licenses
Operator Manual 4.4.2 Expired Licenses All C--MAP licenses that will expire by a certain date in the future are listed. Procedure: (Figure: 4--9) Step 1 and Step 2 (Figure: 4--8) Step 3 Select Expired licenses. Step 4 Enter the desired date with the format Month.Year via OSK. Step 5 Select Create, all known zones and areas are displayed.
Page 86: Licenses List
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany 4.4.3 Licenses List All licenses that are still valid are listed and displayed with the following information: -- valid to (e.g. 10--2002) -- Zone/Area -- 16 character license code Procedure: (Figure: 4--10) Step 1 and Step 2 (Figure: 4--8 ) Step 3 Select Licenses list.
Page 87: License Order Per Position
Operator Manual 4.4.4 License Order per Position This function enables sea areas to be chosen by cursor action across areas. Procedure: (Figure: 4--11) Step 1 and Step 2 (Figure: 4--8 ) Step 3 Select Order per position. To select the desired area, at least three coordinates must be set. The position data of the coordinates are entered in the list box Coordinates per mouse click in order.
Page 88 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Command buttons in the Coordinates per mouse click area allows a cursor position to be deleted Delete list item deletes all entries from the list Clear list specifies the licensing extent for the chart type in which the...
Page 89 Operator Manual ECDIS Save to file a:\RaytheonAnschütz 0009.usr? Step 1 This window displays the imminent data transfer to the target directory a: and the name of the license file (e.g. RaytheonAnschütz). Step 1 The action is executed by pressing the Yes button. Send this CD to the chart manufacturer C--MAP.
Page 90: License Order Per Route
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany 4.4.5 License Order per Route In this connection, the license selection is made via a route that has already been planned. For example, the route was planned on an ARCS chart and should be run over a CM93/3 chart.
Page 91 Operator Manual Command buttons in Select route from list: area All known routes are displayed in this list box. The first route is automatically proposed as the default route. The route selection is made via the cursor or via the scroll bar. specifies the licensing extent for the chart type through which the Zone Area...
Page 92 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Step 1 The action is executed by pressing the Yes button. Send this CD to the chart manufacturer C--MAP. If you click on No, the License Administration box appears again. 4--25 Edition: January 2016...
Page 93: Add License From File
Operator Manual 4.4.6 Add License from File This function reads the C--MAP license key for the requested area into the ECDIS System. The license files are distributed via C--MAP. The license files are automatically included in the C--MAP data structure and release the desired areas for a limited period.
Page 94 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Command button Within the list box License file list: all licenses are overlaid when Add licenses the button is pressed. At the same time, the licenses are processed within the program. The desired areas are released.
Page 95: Select License Order Manually
Operator Manual 4.4.7 Select License Order Manually Within this function a chart list, comprising different zones and areas can be merged together and transferred to C--MAP as a license order. Selected areas of a zone (e.g. 3) are removed from the License order list: when the entire zone (3) is selected.
Page 96 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Command button inserts the selected zone/areas from the list box. Add to list deletes the selected names from the list box Remove from list deletes all entries from the list box in sequence.
Page 97: License Administration For Iho S63 License
Operator Manual License Administration for IHO S63 License 4.5.1 User Permit Procedure: (Figure: 4--15) Step 1 Select Chart (menu bar). Step 2 Select IHO S63 License..Step 3 Select User Permit. The registration No. is indicated in the field. Step 1 Goto ARCS Chart Info / Select...
Page 98: Licenses List
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany 4.5.2 Licenses List Procedure: (Figure: 4--16) Step 1 and Step 2 (Figure: 4--15) Step 3 Select Licenses list. Licenses can be renewed and the status of the current license list reviewed. Status information...
Page 99: Add Licenses From File
Operator Manual 4.5.3 Add Licenses from File Procedure: (Figure: 4--17) Step 1 and Step 2 (Figure: 4--15) Step 3 Select Add Licenses from file. Licenses can be added automatically by choosing Add licenses from file and pointing to the ENC.PMT file received from IHO S63.
Page 100: Product List
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany 4.5.4 Product List Procedure: (Figure: 4--18) Step 1 and Step 2 (Figure: 4--15) Step 3 Select Product list. The product list shows all available IHO S63 charts. If you want to order a new license, note the cell code and contact IHO S63 Service.
Page 101: Import Product List
Operator Manual 4.5.5 Import Product List The product list is automatically updated during installation or update of S-63 chart. So there is usually no need to load the product list manually. Procedure: (Figure: 4--19) Step 1 and Step 2 (Figure: 4--15) Step 3 Select Import Product list.
Page 102: Certificate -- Sa Public Key
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany 4.5.6 Certificate - - SA Public Key To load the new IHO.CRT file, insert the removable media into the ECDIS, open the menu Charts – License – IHO S63. Step 1 and Step 2 (see Figure: 4--15) Step 3 Select Certificate SA Public Key.
Page 103: License Administration For Arcs License
Operator Manual License Administration For ARCS License Procedure: (Figure: 4--22) Step 1 Select Chart (menu bar). Step 2 Select ARCS License..Step 3 If no security key (software dongle) is loaded, the License Administrator dialog box appears. Follow the instructions in the dialog box.
Page 104 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Command Buttons: Shows the license information. License Info In this case the user permit (data file) can be copied automatically. Figure: 4--23 ARCS License Information Select this button when a new license or a license Load Permit file update is available.
Page 105 Operator Manual Select this button when you get a new License or a Add Permit license update per phone or fax. Figure: 4--25 Add Chart Permit 4--38 4343DOC020102 Edition: January 2016...
Page 106 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Select the relevant chart and click on the Remove Remove Permit Permit button. Practice: If you got a license update, sometime a chart permit is cancelled and replaced by another chart number.
Page 107: Cm93/3 Or Enc Installation
Operator Manual CM93/3 or ENC Installation The electronic charts belonging to the two most general “navigational purposes” (i.e. the so--called background charts) are stored on the C--MAP 93/3 Database CD--ROM in non- -encrypted format, meaning that can be freely accessed and displayed on the ECDIS, before the user actually buys licenses for the charts.
Page 108 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Step 1 Goto ARCS Chart Info / Select... ENC + CM93/3 Chart Catalog License " ENC and CM93/3 Installation.. ARCS Installation.. Step 3 Installation " DNC Installation.. Step 2 Updates " Step 4...
Page 109 Operator Manual The process by which the user chooses which Install CM93/3 Database chart he wants to access (i.e. which licenses he needs to buy) is called Install Database. To install a database, place CD into the CD drive and press the Install Database button.
Page 110 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Dialog Box Area: Import and Convert ENC data Apply executes an action Exit the dialog box is faded out Cancel a current procedure is aborted Import and convert unencrypted S57 data files.
Page 111 Operator Manual  There are two options to select cells from CD Automatic selection or manual selection. Automatic selection In this case the program recognizes and selects all cells in a selected directory (sub directories included). These cells will be imported. Procedure: (Figure: 4--29) Step 1, Step 2, Step 3 (Figure: 4--27).
Page 112 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Manual selection In this case only the manually selected cells will be imported (without sub directories). Procedure: (Figure: 4--30) Step 1, Step 2, Step 3 (Figure: 4--27). Step 4 Select the folder S57 (e.g. US).
Page 113 Operator Manual  Starting the conversion process Procedure: (Figure: 4--31) Step 1 Select the Execute button The dialog box File conversion in progress appears and shows the processing. Step 1 Figure: 4--31 Conversion display 4--46 4343DOC020102 Edition: January 2016...
Page 114 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany The conversion process ends with following dialog box (Figure: 4--32). Step 1 Select OK. Step 2 Step 1 Figure: 4--32 Import of data completed If you want to see the complete installation information, then select View Log (Step 2).
Page 115 Operator Manual Import and Convert S63 data Import IHO S63 .. Insert the data CD and select Import IHO S- -63. The following dialog will be displayed. Select the CD drive and the directory where the S63 data is stored. country codes e.g.
Page 116 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany  There are two options to select cells from CD Automatic selection or manual selection Automatic selection In this case the program recognizes and selects all cells in a selected directory and sub directories.
Page 117 Operator Manual Manual selection In this case only the manually selected cells will be imported (without sub directories). Procedure: (Figure: 4--36) Step 1, Step 2, Step 3 (Figure: 4--27). Step 4 Select the cell folder containing the data file to be converted. Normally, the sub directory number is 0.
Page 118 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany  Starting the conversion process Procedure: (Figure: 4--37) Step 1 Select the Execute button. The dialog box File conversion in progress appears and shows the processing. Step 1 Figure: 4--37 Conversion Display...
Page 119 Operator Manual The conversion process ends with following dialog box (Figure: 4--38). Step 1 Select OK. Step 1 Step 2 Figure: 4--38 Import of data completed If you want to see the complete installation information, then select View Log (Step 2). The following dialog window appears. Note If the following message appears: Following cells were not installed:...
Page 120: Arcs Installation
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany ARCS Installation Procedure: (Figure: 4--40) Step 1 Select Charts (menu bar). Step 2 Select Installation. Step 3 Select ARCS Installation. The volume list shows already installed zones. Insert an ARCS chart CD.
Page 121 Operator Manual Click on the button, the installation process starts Install Volume Figure: 4--41 ARCS Installation Process Recommendation If available, the provided update should be installed now. The update process is also initiated by clicking on the Install Volume button (chapter 4.11). Click on this button if you want to remove the selected Remove Volume volume.
Page 122: Dnc Installation
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany DNC Installation Procedure: (Figure: 4--43) Step 1 Select Charts (menu bar). Step 2 Select Installation. Step 3 Select DNC Installation. The volume list shows already installed zones. Step 1 Goto ARCS Chart Info / Select...
Page 123 Operator Manual The process by which the user chooses which chart he Install Database wants to access is called Install Database. To install a database, insert CD and click on the Install Database button and follow instructions, see following dialog. The installation takes approximately one hour.
Page 124 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany After correct selection of DNC path, the following dialog will be displayed automatically. The dialog shows the progress of verification. This process takes time. Figure: 4--45 Progress of Verification is running If the verification is done, a summary will be displayed in the window. In case of errors or warnings the corresponding messages will be shown in the report window.
Page 125 Operator Manual Procedure: Step 1 Press the button. The copying process starts automatically. Step 2 After copying process is over, the database will be registered. Press OK and the Installation of the DNC database is finished. Close Step 1 Step 1 Figure: 4--47 Database registered Procedure: (Figure: 4--48) Step 1, Step 2, Step 3 (Figure: 4--43 ).
Page 126 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Priority If you want to modify the priority, select the database Down you will have displayed first or last and click Priority “Up” or “Down”. To remove a selected database, click on “Remove Remove Database Database”.
Page 127: Enc And Cm93/3 Updates
Operator Manual 4.10 ENC and CM93/3 Updates Procedure: (Figure: 4--49) Step 1 Select Charts (menu bar). Step 2 Select Updates. Step 3 Select ENC and CM93/3 Updates. The dialog box appears. Step 4 Select the chart type. Step 1 Goto ARCS Chart Info / Select...
Page 128 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Command Buttons: Auto Update CM93/3 Auto Update CM93/3 is only supported for C--MAP databases Auto Updating presents three download procedures. Load All Will load and install all available updates for the licensed areas from the C--MAP server directly.
Page 129 Operator Manual The user can check the updates and then expand the update on the various objects in the chart. The chart will automatically pan and highlight the location of the object as shown below. Update S--57 and S--63 Used for S57 and S63 charts. Click on the Update S- -57 and S- -63, the following dialog box appears.
Page 130 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany Update Review Clicking on the “Update Review”, the following dialog box appears. Now you can review the updates applied listed by Auto Update CM93/3 or by Update S- -57 and S- -63.
Page 131 Operator Manual Figure: 4--51 Updating Log Update Review 4--64 4343DOC020102 Edition: January 2016...
Page 132: Arcs Update
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany 4.11 ARCS Update Procedure: (Figure: 4--52) Step 1 Select Charts (menu bar). Step 2 Select Updates. Step 3 Select ARCS Update. The volume list shows already installed zones. Insert an ARCS chart CD.
Page 133 Operator Manual Click on the button, the installation process starts Install Volume (Figure: 4--53). The ECDIS system checks the update edition. If the edition is older than the actual ECDIS edition the following window appears. update in progress Figure: 4--53 ARCS update Click on this button to stop the process.
Page 134: Arcs Updates Indication
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany 4.11.1 ARCS Updates Indication ARCS updates can be displayed directly via the chart concerned or via the Info/Select function. ARCS Updates within a chart Within an ARCS chart all updates are entered and selected automatically.
Page 135 Operator Manual ARCS Updates within the Info/Select Dialog Procedure: (Figure: 4--56) Step 1 Select Info / Select..Step 2 Select ARCS. Main Charts ENC Options Goto ARCS Chart Info / Select... Step 1 ENC + CM93/3 Chart Catalog License "...
Page 136: Dnc Update
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany 4.12 DNC Update Procedure: (Figure: 4--57) Step 1 Select Charts (menu bar). Step 2 Select Updates. Step 3 Select DNC Update. The volume list shows already installed zones. Insert an ARCS chart CD.
Page 137 Operator Manual Select the Update you want to install from this window and select the corre- sponding database from DNC DATABASE window. Then click on the Apply Up- date button. If you want to install all available updates, select corresponding DNC database and click on the Apply All Updates button.
Page 138 SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany The result of the update installation process is shown in the Processing Update window. Figure: 4--60 Execute DNC Update Show review update Procedure: (Figure: 4--61) Step 1 Select Show Review Update. Step 2 Select a name in the Updates Logbook.
Page 139 Operator Manual Show highlights Procedure: (Figure: 4--61) Step 1 Select e.g. Relocate Buoy NT from 34.345- -77.63 to 34.3333. Step 2 Select Highlight. The chart will be centered automatically (to the object) and a circle appears around the object. Step 2 Step 1 Figure: 4--62 Highlight...
Page 140: Chart Server Rights (Option)
SYNAPSIS ECDIS Raytheon Anschütz GmbH Operator Manual Germany 4.13 Chart Server Rights (Option) This function is only possible in connection with a navigation system containing at least two ECDIS units. Depending on the system configuration, one ECDIS can be given server or client status.
Page 141 Operator Manual Main Charts ENC Options Goto ARCS Chart Info / Select... ENC + CM93/3 Chart Catalog License " Installation " Updates switching to switching to " Chart Server Chart Server Chart Server Rights the ECDIS with Chart Server Rights is in progress.
Page 142: Options Menu
SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Options Menu This menu is used to select special chart display adjustments for the selected chart type (chart type selection chapter 4.3). These adjustments are regulated by the chart type. Options Menu ARCS...
Page 143: Chart Information
Operator Manual 5.1.1 Chart Information ARCS Chart information shows all chart specific information generated by the ARCS chart manufacturer at digitalization of the chart. Procedure: (Figure: 5--2) Step 1 Select ARCS Option (Figure: 5--1). Step 2 Select Chart Information... The dialog box appears. Figure: 5--2 Chart Information 5.1.2...
Page 144: Show Updates And Arcs Indicate Updates
SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Chart/ panel information group display Figure: 5--3 View Chart Notes 5.1.3 Notices to Mariners… and Warnings Within these menu entries special marine or warning messages can be called up which can be read in the dialog box.
Page 145: Options Menu For Enc
Operator Manual Options Menu for ENC The option menu contains the following commands: Figure: 5--4 ENC Options Menu Table 5--2 Overview ENC Options ENC and 93/3 Function Options Commands 5.2.1 Presentation Select from Presentation Libraries for S52 and C--Map or Chart 1 Library including color differentiation diagram.
Page 146 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany ENC and 93/3 Function Options Commands 2.5.6 Chart Scale Set the chart scale mechanism: -- automatic size (--Normal,--Medium,--High), switching to appropriate navigation purpose while zooming -- A--G, Z zooming on one defined navigation purpose (e.g.
Page 147: Presentation Library
Operator Manual 5.2.1 Presentation Library With this menu item, the user can select from different presentations for the currently loaded chart. In accordance with IHO--S52 “Specifications of Chart Content and Display Aspects of ECDIS” colors and symbol, this menu is comprising Test Presentation Library and Chart_1 besides the Standard Symbol Library.
Page 148 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Procedure: (Figure: 5--6) Step 1 Select Presentation Library. The dialog box appears. Step 2 Select Chart1. The information window appears. Select OK and the Presentation Library List appears. Step 3 Select the Zoom In function from the Display Menu.
Page 149 Operator Manual Cancel Step 2 Step 3 Step 4 Step 5 Figure: 5--6 Information window Problem solution If you cannot recognize any line adjust more Contrast / Brightness. If this does not solve the problem, contact the Service department to change the ECDIS Display.
Page 150: Mariners Objects
SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 5.2.2 Mariners Objects This function enables the user to manually add marine objects like buoys ), wrecks etc. into the currently loaded chart. The entries are saved and can later be worked on (deleted, moved etc.).
Page 151 Operator Manual select object Attributes select the Object Step 5 Step 3 Step 6 Step 4 Step 5.1 define type select attribute specify the for this object descriptions object for this object Attributes Figure: 5--7 Mariner Objects In this case it is possible to specify a buoy with more details (Buoys with special purpose “Light”...
Page 152 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Step 7 Figure: 5--8 Edit Manual Objects dialog box By pressing the Close key, the cursor is released for positioning the buoy . Figure: 5--9 Add a special object info 5--11 Edition: January 2016...
Page 153 Operator Manual Command Buttons: Undo Edit This function is selected in relation to its attributes. If the Undo Edit button is pressed during or after an attribute specification, the previous attribute specification in the list and the placed object in the chart is deleted.
Page 154 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Step 1 Step 2 Step 3 Figure: 5--10 Del Mariner Object Review Mariner Objects Procedure: (Figure 5--11) Step 1 Select ENC Options. Step 2 Select Mariners Object. Step 3 Select Review Mariner Obj. The dialog box appears.
Page 155: Manual Updates
Operator Manual Click on Export, to create a file with the contents of the Log Export List. For this procedure a formatted 3,5” disk must first of all be inserted in the drive. 5.2.3 Manual Updates This menu item is designed for the official manual chart correction (equivalent to Notes to Mariners for paper charts).
Page 156 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Step 6 Select Place Objects. The object can now be placed on the chart via the cursor or, in case of manual input, by entering the Specify Location value (Latitude and Longitude).
Page 157 Operator Manual Review Manual Update Procedure: (Figure 5--13) Step 1 Select ENC Options. Step 2 Select Mariners Object. Step 3 Select Review Mariner Obj. The dialog box appears. Step 7 Figure: 5--13 Edit Manual Objects dialog box By pressing the Close key, the cursor is released for positioning the buoy. 5--16 4343DOC020102 Edition: January 2016...
Page 158 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Figure: 5--14 Add a special object info Command Buttons: Reset Edit This function is selected in relation to its attributes. If the Reset Edit button is pressed during or after an attribute...
Page 159 Operator Manual Step 1 Step 2 Step 3 Figure: 5--15 Object info Official chart objects cannot be visibly deleted from their place, they get an */* symbol as an overlay marker. This symbol will mark objects as manually deleted on the current chart layer. Move Objects On actuating this button, you can select the object (using the appropriate symbols like “...
Page 160 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Step 1 Step 2 Step 3 new position old position “ / “ Figure: 5--16 Move Objects Chart Viewer: ENC charts are made up of several scale ranges. The information extent of the scale ranges varies and is determined via the penetration depth (zoom in/out).
Page 161 Operator Manual Select View all chart, it will display the updated object at the first navigation purpose where this object is available centred on the chart. The displayed data set will be automatically be presented at the smallest scale available. At the same time tree list box and the Delete Object button will be enabled.
Page 162: Legend
SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 5.2.4 Legend... This menu feature opens an info window for the currently loaded chart. The info window shows all characteristic data for ENC charts. Procedure: (Figure: 5--17) Step 1 Select ENC Options (Figure: 5--1).
Page 163: Display Options
Operator Manual 5.2.5 Display Options This menu allows the user to select the SENC information (System Electronic Navigational Chart) to be displayed on the current chart. Procedure: (Figure: 5--18) Step 1 Select ENC Options (Figure: 5--1). The dialog box appears. Figure: 5--18 Chart Options 5.2.5.1...
Page 164: Other Display
SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 6 prohibited and restricted areas; 7 chart scale boundaries; 8 indication of cautionary notes; 9 ship’s routing systems and ferry routes; 10 archipelagic sea lanes. 5.2.5.3 Other Display Other Display all other information which is not part of the Standard Display, for example: 1 spot soundings;...
Page 165 Operator Manual The Safety depth is used to distinguish safe and dangerous spot soundings. The value of the safety depth can be linked to the safety contour by using the corresponding check box. Command Button: Save settings as “ User defined Display” The button is used to store all currently made settings in this dialog for the user defined display, which can be recalled by using the menu as described above.
Page 166: Chart Scale
SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 5.2.6 Chart Scale This menu function allows the user to display charts in following modes: -- Automatic -- Normal -- Automatic -- Medium -- Automatic -- High -- or at fixed navigational purpose (e.g. harbour, approach) Procedure: (Figure: 5--20) Step 1 Select ENC Options (Figure: 5--1).
Page 167: Display Date (Auto)
Operator Manual 5.2.7 Display Date (Auto) This menu function allows the user to find out date--dependent objects in the chart, such as seasonal buoys, are only to be displayed over a certain period. Other objects, such as a traffic separation schema, may have a date on which they are intro ducted or discontinued.
Page 168: Chart Indications
SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 5.2.8 Chart Indications This function provides means to turn the chart indication for different categories of objects on or off. The indication can be set for Route Planning and Look-Ahead Searchlight (Route Monitoring) independently.
Page 169 Operator Manual Figure: 5--23 Chart Indications, Look--Ahead Searchlight Example of Look-Ahead Searchlight with highlight indication of safety contour (red outline and fill), Hazard and Special Condition Area (yellow outline). Figure: 5--24 Look--Ahead Searchlight, Example Example of Route with highlighted indications of safety contour (red outline and fill) and Hazards (yellow outline).
Page 170 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Figure: 5--25 Route with highlighted indications of safety contour NOTE Categories which are not to be highlighted in Route Planning are marked with an asterisk (*) in the review route check results (see chapter 8.2.8).
Page 171: Options Menu For Dnc
Operator Manual Options Menu for DNC The option menu contains the following commands: Figure: 5--26 DNC Options Table 5--3 Overview DNC Options DNC Options Function Commands 5.3.1 Mariners Add or delete chart symbols, points, lines and text. Objects... 5.3.2 Manual Add or delete chart data to or from a chart according to DNC, Collars Updates...
Page 172: Mariners Objects
SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 5.3.1 Mariners Objects This function enables the user to manually add marine objects like buoys ), wrecks etc. into the currently loaded chart. The entries are saved and can be worked on (deleted, moved etc.) later.
Page 173 Operator Manual select object Attributes select the Object Step 3 Step 5 Step 6 Step 4 Step 5.1 select attribute define type specify the descriptions for this object object for this object Attributes Figure: 5--27 Mariner Objects In this case it is possible to specify a buoy with more details (Buoys with special purpose “Light”...
Page 174 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Step 7 Figure: 5--28 Edit Manual Objects dialog box By pressing the Close key, the cursor is released to position the buoy . The positioned buoy is displayed within the light cone code within the chart.
Page 175 Operator Manual Command Buttons: Reset Edit This function is selected in relation to is attributes. If the Reset Edit button is pressed during or after an attribute specification, the previously attribute specification in the list and the placed object in the chart is deleted.
Page 176: Manual Updates
SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 5.3.2 Manual Updates This menu item is designed for the official manual chart correction (equivalent to Notes to Mariners for paper charts). Chart corrections are announced either from the chart manufacturer or regularly issued notices to mariners.
Page 177 Operator Manual displayed (e.g. scale maximum 1000 and scale minimum 500000). Step 6 Select Place Objects. The object can now be placed on the chart via the cursor or, in case of manual input, by entering the Specify Location value (latitude and longitude). select object Attributes select the...
Page 178 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Step 7 Figure: 5--32 Edit Manual Objects dialog box By pressing the Close key, the cursor is released for positioning the buoy . The positioned buoy is displayed within the light cone code within the chart.
Page 179 Operator Manual Command Buttons: Reset Edit This function is selected in relation to its attributes. If the Reset Edit button is pressed during or after an attribute specification, the previous attribute specification in the list and the placed object in the chart is deleted.
Page 180 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Official chart objects cannot be visibly deleted from their place, they get a */* symbol as an overlay marker. This symbol will mark objects as manually deleted on the current chart layer.
Page 181 Operator Manual Chart Viewer: DNC charts are made up of several scale ranges. The information extent of the scale ranges varies and is determined via the penetration depth (zoom in/out). If an object is deleted or inserted in a scale range, this action is restricted only to this scale range.
Page 182: Legend
SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 5.3.3 Legend... This menu feature opens an information window for the currently loaded chart. The Info Window shows all characteristic data specific for DNC charts. Procedure: (Figure: 5--36) Step 1 Select DNC Options (Figure: 5--1).
Page 183 Operator Manual This Warning will be displayed if the coefficients for the World Magnetic Model are out of date (chapter 9.1.9). Figure: 5--37 Magnetic Verification 5--42 4343DOC020102 Edition: January 2016...
Page 184: Overlays
SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 5.3.4 Overlays This menu item allows the user to select the SENC information (System Electronic Navigational Chart) to be displayed on the current chart. Procedure: (Figure: 5--38 and Figure: 5--39) Step 1 Select DNC Options (Figure: 5--1).
Page 185 Operator Manual 7 indication of cautionary notes Full Display all other information which is not part of the Standard Display, for example: 1 spot soundings 2 submarine cables and pipelines 3 ferry routes 4 contents of cautionary notes 5 graticule 6 place names Chart Options...
Page 186 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Figure: 5--39 Option Menu 5--45 Edition: January 2016 4343DOC020102...
Page 187: Symbol Types
Operator Manual 5.3.5 Symbol Types Using this menu function, buoys and beacons can be displayed as Simplified Symbols according to IHO--paper S52. Procedure: (Figure: 5--40) Step 1 Select DNC Options (Figure: 5--1). Step 2 Select Symbol Type. The dialog box appears. Simplified Symbols selected Traditional Symbols selected Figure: 5--40...
Page 188 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Display Menu The ECDIS display is defined by the two values for scale and center. Scale is the distance from the top to the bottom of the display and can be any value from 1 NM to 3999 NM.
Page 189 Operator Manual Table 6--1 Overview Display Menu Display Commands Function 6.1.1.1 Zoom In Allows you to select an area of the display on which to zoom--in. En- larging the selected area so that it fills the display. 6.1.1.2 Zoom Out Allows the user to specify the degree to zoom out the display.
Page 190 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 6.1.1 The Zoom Feature The Zoom feature enables you to quickly change the scale of the display. The zoom activities are displaying as second information in the Information Panel (Figure: 6--2). Figure: 6--2 Information Panel...
Page 191 Operator Manual NOTE Make sure to hold down the [Left] button until the box is drawn to the size you desire. If you have drawn the box to the desired size, but want to reposition it, before you release the [Left] button, hold down [Shift] and move the cursor until the box is in the desired position.
Page 192 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 6.1.1.2 Zooming Out Use the Zoom Out command from the toolbox to quickly change the display scale from its current value to one that is one--and--one--half times (150 %) larger. You can use the command repeatedly until the scale reaches 6,550 NM.
Page 193 Operator Manual 6.1.2 Default Scale Display the current chart at the default scale. 6.1.3 Largest Scale Load and display the chart with the largest available scale at the current display position. 6.1.4 Scale and Center Command When you want to center the display on a specific location or change the scale to a particular value, use the Scale and Center command.
Page 194 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Step 3 Step 3 Step 3 Step 3 Step 4 Figure: 6--5 Scale and Center Dialog Box 6.1.5 View Area Command One of the fastest ways to reposition the display is to use ECDIS’s view area feature.
Page 195 Operator Manual Procedure: Step 1 Select the display menu (Figure: 6--1). Step 2 Select View Area. The dialog box appears. The names of all the areas you have saved appear in the list box. When you select an area name, its scale and center are displayed at the bottom of the dialog box.
Page 196 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 6.1.5.2 Open an Area Procedure: Step 1 Select the display menu (Figure: 6--1). Step 2 Select View Area. The dialog box appears. Step 3 Click on the name of the area you want to open. The area name appears in the text box and its scale and center appear below the list box.
Page 197 Operator Manual 6.1.6 Keeping Your Ship in the Display Area (Ship Auto Center) When you turn on the Auto Center feature, ECDIS automatically moves the displayed chart area so that your ship is always in view. When your ship reaches a point near the edge of the display (that you determine), ECDIS automatically recalculates the center of the display, then re--centers it so that your ship is at its center.
Page 198 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany ECDIS chart Off center range e.g. 50% Ship motion range e.g. 5% Figure: 6--7 AutoCenter Enabled 6.1.7 True Scale Icon The rectangular ship symbol is not a fixed size symbol but adjusts to the scale of the chart.
Page 199 Operator Manual 6.1.9 Information Panel ECDIS allows you to control the display of e.g. 4 different types of the information panel. You can also select to remove them from the display area so that you may have a wider viewing area. Procedure: Step 1 Select the display menu (Figure: 6--1).
Page 200 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Ship Menu Ship Menu Commands ARCS Options Display Ship Routes Step 1 Figure: 7--1 Ship Menu Table 7--1 Overview Ship Menu Ship Command Function 7.1.1 Ship Info... Specifies the ship’s dimensions; specifies the location of navigation device antennas relative to bow and port side.
Page 201 Operator Manual 7.1.1 Ship Info The ship info dialog box provides information about the ship. Procedure: (Figure: 7--2) Step 1 Select the ship menu (Figure: 7--1). Step 2 Select Ship Info... The dialog box appears. Figure: 7--2 Ship Info 7--2 4343DOC020102 Edition: January 2016...
Page 202 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 7.1.2 Position Offset When displaying a signal from a navigational aid using the ARPA Radar Tracking command, the target may not appear exactly over the navigational aid. When this occurs, make sure your electronic charts have the most recent update. If this is the case, the error may be due to incorrect position information from your nav- igational positioning device.
Page 203 Operator Manual 7.1.2.1 Changing Ship’s Position Procedure: (Figure: 7--3 and Figure: 7--4) Step 1 Select the ship menu (Figure: 7--1). Step 2 The cursor changes to target shape and the Ship Offset dialog box appears. (Figure: 7--4). Step 3 Enter the offset using the display a) Click on ARPA target.
Page 204 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 7.1.3 Own Ship Vector and Look- -Ahead WARNING FOR ANTI- - GROUNDING INFORMATION TO BE ACCU- RATE, ALL CHART DATABASES MUST BE UP- - TO- - DATE AND VALID. ECDIS provides options to display course vectors and heading line as well as a search light.
Page 205 Operator Manual Procedure: (Figure: 7--5 and Figure: 7--6) Step 1 Select the ship menu (Figure: 7--1). Step 2 Select Own Ship Vector. The dialog box appears (Figure: 7--5). Step 3 Figure: 7--5 Own Ship Vector Step 3 Select your favored Ships Vector presentation in the chart (Figure: 7--6).
Page 206 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 7.1.4 Placing Ship Marks The Mark at Ship command is used to annotate tracks with your own ship marks. The Auto Label command will place a ship mark at your boat’s location at specified time intervals, nautical mile intervals, or at specific headings.
Page 207 Operator Manual 7.1.5 Anchor Watch ECDIS can monitor the drift of the ship while anchored. When Own ship (DR Point) travels outside the range, ECDIS gives an audible alert and displays a warning message. Procedure: (Figure: 7--8) Step 1 Select the ship menu (Figure: 7--1). Step 2 Select Anchor Watch….
Page 208 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 7.1.6 Guard Zones The Guard Zones are defined on the Synapsis Radar and can be displayed on the ECDIS. Procedure: Step 1 Select the Ship menu. Step 2 Select Guard Zone. 7.1.7...
Page 209 Operator Manual Procedure: (Figure: 7--10) Step 1 Select the ship menu (Figure: 7--1). Step 2 Select the MOB button or select Man Overboard... command. ECDIS places special MOB marker with time entry on the chart, set an Alarm (acoustic and visual in the message display area). Following MOB information displays in the status bar: Position of the MOB, distance and bearing to the MOB 7--10...
Page 210 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Step 2 special MOB marker with time entry Position of the MOB, distance and bearing to the MOB Figure: 7--9 Man Overboard event (see log menu) Figure: 7--10 Current Log MOB information...
Page 211 Operator Manual 7.1.9 Clear or Cancel Man Overboard - - Alarm Procedure: Step 1 Select the ship menu (Figure: 7--1). Step 2 Select Overboard All- -Clear. ECDIS turns off the alarm and posts an entry to the ship. 7--12 4343DOC020102 Edition: January 2016...
Page 212 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Routes Menu Route Planning ECDIS has sophisticated route planning capabilities. During route planning, each route section is automatically checked against the safety contour dangers / hazards and special condition areas. The check results can be reviewed (see chapter 8.2.9).
Page 213 Operator Manual circle, you will need to change either your ship’s speed or the planned rate of turn (see Autopilot dialog box, chapter 12.1.4). 8--2 4343DOC020102 Edition: November 2019...
Page 214 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 8.1.1 Route Description field Figure: 8--1 Route Description ECDIS does not select an active waypoint until the Steer to Track dialog box has been opened and the active waypoint has been selected.
Page 215 Operator Manual The following information is displayed: 1) Waypoints appear as a circle and an additional circle appearing around the active waypoint. 2) Planned track (course line) between the waypoints (is red in color and appears as a thick dashed line between waypoints and a thick dashed line for the approach manoeuvre).
Page 216 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 8.1.1.1 Handling Primary Route and Secondary Route It is possible to plan and edit two routes at the same time. Route priorities are indicated by the entries Primary and Secondary in the menu guide (chapter 8.2.5 Toggle Routes).
Page 217 Operator Manual 8.1.1.2 Primary and Secondary Route used in a Single ECDIS system Using the context sensitive pop--up window you will find following restrictions between the Primary and Secondary Route window. Place the Target Cursor on a waypoint from a Primary or Secondary Route and click the right button from trackball.
Page 218 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Primary Route (Server) Primary Route (Client) Secondary Route Figure: 8--4 Pop--up windows for Primary and Secondary Route (Server and Client Rights) 8--7 Edition: November 2019 4343DOC020102...
Page 219 Operator Manual Routes Menu Commands Display Ship Routes Nav Tools Step 1 Figure: 8--5 Routes Menu 8--8 4343DOC020102 Edition: November 2019...
Page 220 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Table 8--1 Overview Route Menu Routes Commands Function 8.2.1 Create Create or edit a primary or secondary route. Route... 8.2.2 Automatic Allows you to plan a route automatically. The automatic route plannin- Route...
Page 221 Operator Manual Routes Commands Function 8.2.18 Check Route.. Checks a Route (Primary or Secondary) passing a restricted area (e.g. military zone). 8.2.19 Route Server Option Rights Allows you to take the “Route Server Rights”. 8.2.1 Edit Route Command When you choose the Edit Route command, ECDIS displays the Edit Route dialog box with the name of the open route (Primary or Secondary) in the title bar.
Page 222 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 8.2.1.1 Creating a Route NOTE The larger the scale of the display, the more accurately you can locate specific coordinates. If you want to place a waypoint at a location that is...
Page 223 Operator Manual Step 3 Step 2 Step 4 / 6 Step 7 Figure: 8--6 Creating a new Route 8--12 4343DOC020102 Edition: November 2019...
Page 224 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany ENC Chart Objects which are detected and may be indicated (see chapter 5.2.8) during route planning and route monitoring. Safety Contour Shallow water (shallow depth areas or dredged area) Land areas Shoreline constructions...
Page 225 Operator Manual Seaplane landing areas Submarine transit lanes Anchorage areas Marine farms/aquacultures PSSA (Particularly Sensitive Sea Areas) 8.2.1.2 Route Edit Operations Procedure: (using the menu structure) Step 1 Select the route menu (Figure: 8--5). Step 2 If no route loaded select Route Manager, select a route from the list box, click Open as Primary or Open as Secondary button.
Page 226 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany In place editing of waypoint properties is activated by double--clicking into a list property field (see Figure: 8--8). Figure: 8--8 In place editing Edited values only become operative after deselecting the respective field.
Page 227 Operator Manual symbol appears at each location you specify and the route is extended with fair lanes and a planned track (dashed). Step 1.8 Click on Ok. The Save Route dialog box appears. Step 1.9 To save the route, type a name of up to 25 characters in the text box, then click on OK.
Page 228 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany fields. Click outside the editable fields ------ i.e. click on the number column. The waypoint is repositioned in the display and the route is redrawn. NOTE Datum is always WGS 1984. Step 3.2 Select the OK button, if the a route changing is finished.
Page 229 Operator Manual Step 3.1 Step 3.2 Figure: 8--9 Change Route Option button Route: Insert Before selected To insert a waypoint before an existing waypoint, first select the existing waypoint, then enter the new waypoint. ECDIS redraws the route to include the inserted waypoint.
Page 230 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Option button Route: Delete selected Use the Delete feature of the Edit Route command to remove waypoints from a route. Step 5.1 Using the target cursor Position the cursor over the waypoint you want to delete and click on [Left] button.
Page 231 Operator Manual XTD limit Cross- - Track error (Figure: 8--10) Step 7.1 To enter a cross--track error, click in the XTD limit text box and enter the cross--track in [m]. Click on Set to make the change. The fair lanes on the display will be adjusted according to the cross--track limit settings.
Page 232 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Step 8.1 Click on Compact. The dialog layout is switched to Compact layout. Step 8.2 Click on Expand. The dialog layout is switched back to Expand layout. NOTE Compact layout is not supported during Track Control or Route Monitoring.
Page 233 Operator Manual Figure: 8--12 Conflicting Times Warning Voyage mode is activated and deactivated by pressing the Voyage button. The waypoint list layout is then changed accordingly. In Standard mode the following waypoint list columns are shown with the route--position disabled and all other columns enabled: position on the route Label label...
Page 234 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Figure: 8--13 Voyage Mode Layout To set and fix a speed or ETA value, double--click the field in the waypoint list and enter the desired value, other dependent speed and ETA values will be recalculated.
Page 235 Operator Manual Figure: 8--14 Voyage Full Listing When finished with voyage changes, press the Voyage button again to leave voyage mode. (10) Undo / Redo The Editor keeps track of all route changing operations. The Undo option will revert to the last saved route state and the Redo option will re--do the last route changing operation.
Page 236 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany NOTE The datum conversion is only a display. It will not change the waypoint’s coordinates. The stored waypoints remain unchanged in WSG 1984 coordinates. Procedure: (e.g. using the pop--up window per cursor) Step 11.1 Place the cursor on a waypoint and click on right button.
Page 237 Operator Manual Figure: 8--15 Enter different Datum (12) Great Circle Navigation ECDIS provides a feature that allows you to navigate great circle routes. Whenever you change the route that two neighboring waypoints exceed 200 NM distance from each other. ECDIS prompts you with the following dialog. Figure: 8--16 Intermediate Waypoints dialog box 8--26...
Page 238 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Two sequential dialog activations are possible for a single route change operation. Select Great Circle or Rhumb line, select the requested count and click Yes to continue, click No to bypass this single dialog or click Cancel to abort all dialogs (i.e.
Page 239 Operator Manual Simulate a Great Circle Route If you want to build a great circle route, you will need to enter the number of intermediate points to create the route (Figure: 8--18) . These points create a curved great circle route. larger distance.
Page 240 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Figure: 8--19 Standard Mode Context Actions In Standard Mode the waypoint properties (radius, XTD, speed) can be set simultaneously, selected waypoints can be deleted, all waypoints can be selected, a route check operation can be triggered, intermediate waypoints may be added and consecutive selected waypoints can be saved as a new route.
Page 241 Operator Manual In Voyage Mode the waypoint properties (speed, speed--is--fixed, ETA--is--fixed) can be set simultaneously, all waypoints can be selected, a route check operation can be triggered, the ETA display mode can be set (all ETA’s, fixed ETA’s only), the Time column display mode can be set (TTG, Total Time, Time on Leg) and the voyage can be deleted.
Page 242 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 8.2.2 Automatic Route Planning and Port Information (Option) The ECDIS offers a function for automatic route planning. The Automatic route planning is only available if the Jeppesen (C--MAP) database ”Professional+” or Jeppesen PRIMAR is installed and has a valid license.
Page 243 Operator Manual Procedure: (Figure: 8--22) Step 1 Select Automatic Route Planning/Port Information from the Nav Tools menu. The dialog box appears. Step 2 Select the desired start port in the list /alternative press Click Cursor. Position the cursor on the port name /alternative on the chart position. Then press the Add Port button /alternative press left trackball key.
Page 244 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany dialog Box Step 6 Step 2, 3 Step 4 Step 5 Shows all existing Ports. Use the scroll bar for Step 7 selecting the desired port. Shows only the existing Ports for the current chart area.
Page 245 Operator Manual NOTE It might happen, that some turns (e.g. in canals or port entries) need a smaller turning radius than the given default turning radius, in this case the turning radius will be reduced adequately on the relevant turns and an information is provided in the status area of the window.
Page 246 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Step 1 Step 2 Figure: 8--23 List of all available passages 8--35 Edition: November 2019 4343DOC020102...
Page 247 Operator Manual 8.2.3 Create SAR Pattern Route With this function, ECDIS provides means to create a route from a Search and Rescue (SAR) pattern in a safe, fast and simple way. Four different types of SAR patterns are provided: -- Expanding Square -- Sector -- Parallel Track -- Expanding Track...
Page 248 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany The following parameters can be adjusted for SAR patterns: -- Start Position -- Own Ship’s Position (follow own ship) -- MOB Position (only available if MOB is set) -- Cursor (set Start Position with the cursor, initially at own ship)
Page 249 Operator Manual NOTE If track control is active and the SAR pattern shall be saved as primary route, the user is prompted to confirm the termination of track control. Route monitoring will be terminated without confirmation. Examples for SAR patterns Expanding Square and Sector SAR pattern are covering an area centered on the start position.
Page 250 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Figure: 8--26 SAR Pattern, Sector with One Cycle 8--39 Edition: November 2019 4343DOC020102...
Page 251 Operator Manual Figure: 8--27 SAR Pattern, Sector with Two Cycles 8--40 4343DOC020102 Edition: November 2019...
Page 252 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Figure: 8--28 SAR Pattern, Parallel Track 8--41 Edition: November 2019 4343DOC020102...
Page 253 Operator Manual Figure: 8--29 SAR Pattern, Expanding Track 8--42 4343DOC020102 Edition: November 2019...
Page 254 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 8.2.4 Route Manager Figure: 8--30 Route Manager dialog box When you activate the Route Manager, a list of all known routes is shown in alphabetical order. A short status information is shown dependent on currently selected routes (i.e.
Page 255 Operator Manual NOTE When you open a route, ECDIS draws fair lanes and a planned track (dashed) between the waypoints. Use the Track Control command to begin navigating to waypoint (see Activating Track Control (chapter 8.2.13)) Procedure: Step 1 Select Route Manager from the Routes menu. Step 2 Click on the name of the route you want to open.
Page 256 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 8.2.4.3 Export The Export Route command allows you to save routes on USB--Stick. Procedure: Step 1 Select Route Manager from the Routes menu. Step 2 Select the drive on which to export the routes.
Page 257 Operator Manual 8.2.4.4 Import The Import Route command allows you to import routes from USB--Stick. RTZ, RTZP and ROUTE (Proprietary Raytheon Anschuetz Route) are supported as import formats. You can only import routes which have been exported with a compatible software version.
Page 258 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 8.2.4.5 Protect / Unprotect The Protect Route command allows you to protect routes against accidental deletion and content changes. The Unprotect Route command allows you to deprotect previously protected file(s). Procedure: Step 1 Select Route Manager from the Routes menu.
Page 259 Operator Manual Step 2 Figure: 8--33 Toggle Routes Step 2 For further Secondary Route information place the Cursor on a waypoint and click the right button. Select List Secondary Route... The following dialog appears NOTE The List Route dialog box appears confirming average ship’s speed. ECDIS automatically calculates it, but you may enter a different speed if you wish to.
Page 260 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Figure: 8--35 Route List Step 5 Select Close when you have finished viewing the route list. 8--49 Edition: November 2019 4343DOC020102...
Page 261 Operator Manual 8.2.6 Saving Routes (Primary or Secondary) The Save Route command allows you to store a route in the route list iterating usage. When you choose the Save Route command, the system will check the route for obstacles or depths shallower than the depth defined by the ship’s loading conditions (Ship Info command/ Integration menu).
Page 262 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 8.2.7 Show Route (Primary or Secondary) The Show Route command centers the display on either the active waypoint of the open route, or if there is no active waypoint, the first waypoint on the route.
Page 263 Operator Manual Table 8--2 Waypoint List Column Definitions Column Contains Waypoint Num The waypoints numerical position on the route. Waypoint Label Waypoints label. Latitude Waypoints latitude. Brg Next Bearing from that waypoint to the next waypoint. Dist. Next Distance between that waypoint and the next waypoint. Dist.
Page 264 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 8.2.9 Reviewing Route Check results Routes are automatically checked when they are opened or edited. Routes may also be checked explicitly using the Routes -- Check Route... menu command (chapter 8.2.18). The results of the latest route check can be reviewed with this menu command.
Page 265 Operator Manual Figure: 8--39 Route Check Results (ordered by object types) On the right hand side of the window the detailed information about the selected object will be displayed. The selected object will also be highlighted on the chart. By double clicking on an object the chart will be centered on the object. For highlighting of route check result, see also chapter 5.2.8 „Chart Indications“.
Page 266 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 8.2.11 Sending and Displaying ECDIS objects and Route on the Radar ECDIS allows you to send and display objects on selected radars. ECDIS is compatible with any device whose I/O ports are according to designed NMEA 0183.
Page 267 Operator Manual Figure: 8--40 Send to Radar 8.2.11.2 Send Route to Radar The Send Route to Radar function is used for the Primary Route. Route Monitoring can be activated if you want to transfer a Primary Route to the connected radar display. This is an automatic function without any pop--up window information.
Page 268 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 8.2.12 Route Monitoring Route Monitoring can be activated if you want to follow a route in manual or leading control, but also want to have the information provided in track control mode, i.e. exceeding cross track limits, approaching a waypoint.
Page 269 Operator Manual Procedure: (Figure: 8--41) Step 1 Select Open Route from the Routes menu. Select Route Monitoring. (Alternative selection, place the Target Cursor on a waypoint from a Route and click the right button. Select Route Monitoring from the menu box which appears) Step 2 Select the desired waypoint per left or right arrow button or per target cursor.
Page 270 Operator Manual Raytheon Anschütz GmbH Germany 8.2.13 Track Control Synapsis ECDIS supports track control for the following editions:  IEC62065:2002  IEC62065:2013 NOTE Track Control is not an ECDIS function. To activate this function an AUTOPILOT System has to be connected. For detailed information ask Raytheon Anschütz.
Page 271 Operator Manual Wheel Over Line presentation on the ECDIS Two different Wheel Over Line presentations are provided on the ECDIS:  WOL crossing the WOP and vertical to actual track line  WOL crossing the WOP and parallel to next track line If the ECDIS is connected with the autopilot NP5500, the WOL runs vertical to the actual track line.
Page 272 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany If the ECDIS is connected with other autopilots, the WOL runs parallel to the next track line. Figure: 8--43 ECDIS connected with other autopilots 8.2.13.1 Information Panel NAV - -Route Description- - The NAV panel of ECDIS uses the TO WPT box to display information about the active waypoint you are approaching.
Page 273 Operator Manual 8.2.13.2 Information TRACK - - Route Description - - The TRACK panel contains the following information. To Waypoint: The label (name) of the active waypoint. The active waypoint’s location. The active waypoint’s distance and track course and the time to go at the ship’s current speed.
Page 274 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany the arrow keys. When you select the new waypoint, ECDIS verifies if it is a valid course line, then it circles the waypoint, redraws the course line, and updates the Information Panel. If it is not a valid course line, then ECDIS grays the dialog box, except the Select Active Waypoint arrow buttons, until a valid waypoint is selected.
Page 275 Operator Manual Step 2 indicated only if NP208x or NP5500 is installed Step 3 Figure: 8--46 Activating Track Control 8--64 4343DOC020102 Edition: November 2019...
Page 276 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 8.2.13.4 Stopping Track Control If you want to depart from the track or interrupt track control in case of emergency: Procedure: (Figure: 8--47) Step 1 Select Track Control from the Routes menu.
Page 277 Operator Manual 8.2.13.5 Reactivating Track Control When you -- after an interruption -- are ready to reactivate track control, you can open the Steer to Track dialog box and select a waypoint on the route as the active waypoint you want to navigate to. Procedure: (Figure: 8--48) Step 1 Select Track Control from the Routes menu.
Page 278 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 8.2.14 ETA Calculation With this function the parameters for the ETA calculation can be set. Figure: 8--49 ETA Calculation There are two ways to calculate the ETA: -- Based on the current speed for the whole route from current ship’s position via the TO Waypoint to the end of the route.
Page 279 Operator Manual 8.2.15 Distance- - To- - Run / Planned Position Distance- - To- - Run From this menu function a Distance--To--Run interval can be defined. It is appropriate to zoom out the chart such that the complete route is visible. Procedure: (Figure: 8--51) Step 1 Select Distance- -To- -Run..
Page 280 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Planned Position This tool can be directly related to the Distance--To--Run function. Planned Position will reasonably only be performed for the Track Control or Route Monitoring. It is appropriate to zoom out the chart such that the complete route is visible.
Page 281 Operator Manual Info field Figure: 8--52 Distance--To--Go and Planned Position 8--70 4343DOC020102 Edition: November 2019...
Page 282 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 8.2.16 Pre- -Departure Checklist The Pre--Departure Checklist allows you to write an individual checklist for e.g. important procedures like what is to do before leaving the harbour? This checklist can be stored under a typical name so you can call it up every time.
Page 283 Operator Manual 8.2.17 Alarms Using the Navigational Alarms In connection to Route planning ECDIS provides two alarms to assist you during navigation: The Waypoint Approach Alarm and the Cross--Track Error Alarm. Both alarms can be adjusted by the Alarms command, opening the dialog box shown below.
Page 284 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Cross Track Deviation Limit violation ECDIS generates an alarm to indicate violation of cross--track limits (the Cross Track Deviation Limit is defined in the Alarms dialog box shown in Figure: 8--55 and can also be set in the Create/Change Route dialog (chapter 8.2.1.2 (7)).
Page 285 Operator Manual 8.2.17.1 Setting the Navigational Alarms Procedure: (Figure: 8--56) Step 1 Select Alarm from the Routes menu, the dialog box appears. (Alterative selection, place the Target Cursor on a waypoint and click the right button. Select Alarm from the menu box which appears. The dialog box appears).
Page 286 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 8.2.18 Check Route Check Route considers the validity of objects limited in time in the sea chart formats CM93/3 and S57. Objects limited in time are: S Prohibited Areas S Own Ships Contours S Buoys and Beacons.
Page 287 Operator Manual 8.2.19 ECDIS used as Route Server or Route Client (Option) This functionality is only possible in connection with a navigation system containing at least two ECDIS units. Depending on the system configuration, one ECDIS can be the Route Server or the Route Client.
Page 288 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Client Route Menu Server Route Menu Edit Primary Route... Edit Primary Route... Edit Secondary Route... Edit Secondary Route... Automatic Route Planning/Port Information Automatic Route Planning/Port Information Route Manager... Route Manager... Toggle Routes Toggle Routes Save Route...
Page 289 Operator Manual Intentionally left blank 8--78 4343DOC020102 Edition: November 2019...
Page 290 Operator Manual Intentionally left blank 8--78 4343DOC020102 Edition: January 2016...
Page 291 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany NAV Tools Menu NAV Tools Menu Commands Display Ship Routes Nav Tools Step 1 Figure: 9--1 Nav Tool Menu Table 9--1 Overview Nav Tool Menu Nav Tools Function Commands 9.1.1 Free/Fixed Allows you to draw electronic bearing line and variable range marker EBL/VRM which display the range and bearing from own ship to another point.
Page 292 Operator Manual Nav Tools Function Commands 9.1.7 Line of The line of position feature is provided as an aid to the navigator. Position To determine ship’s location when forced to operate in Dead Reckon- ing mode (DR) or as a visual check of the ship’s electronic positioning systems.
Page 293 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 9.1.1 Electronic Bearing Line (EBL) You can use the Free EBL and Fixed EBL commands to draw electronic bearing lines either centered on own ship or at any location on the display. The Fixed EBL command draws an electronic bearing line which centers on own ship’s...
Page 294 Operator Manual Step 3 Step 2 EBL/VRM position inhumation field Figure: 9--2 Range and Bearing from One Point to Another 9--4 4343DOC020102 Edition: January 2016...
Page 295 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 9.1.1.2 Range and Bearing from the Ship to a Displayed Location Procedure: (Figure: 9--3) Step 1 Select Fixed EBL/VRM from the Nav Tools menu or click on the Fixed EBL button on the tool bar The anchor point of the EBL is located at the ship’s center.
Page 296 Operator Manual 9.1.2 Show EBL/VRM Labels This function enables/disables the display of labels on fixed and free EBL/VRMs. The label is displayed outside the VRM near the intersection of EBL and VRM. Figure: 9--4 EBL/VRM Labels 9--6 4343DOC020102 Edition: January 2016...
Page 297 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 9.1.3 Rhumb/Great Circle Line Within this NavTool it is possible to calculate distances of two positions on a rhumb line or a great circle line. Procedure: (Figure: 9--5) Step 1 Select Rhumb/Great Circle Line from the Nav Tools menu.
Page 298 Operator Manual 9.1.4 Datum Transformation With this NavTool it is possible to calculate position values (coordinates) for different datums. Procedure: (Figure: 9--6) Step 1 Select Datum Transformation from the Nav Tools menu. The dialog box appears. Step 2 f you want to change the Source Datum, press the Change button, a library list window appears.
Page 299 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 9.1.5 Cursor Information The Cursor Information menu provides configurable tooltip information. Configurable items are: -- Position: as shown in the status bar or with selectable datum -- Range / Bearing: as shown in the status bar...
Page 300 Operator Manual Procedure: Step 1 Select Cursor Information... from the Nav Tools menu. The dialog box appears. Figure: 9--8 Cursor Information Dialog Box NOTE Depth Areas, Vertical Clearance and Point Objects refer to chart objects and are only shown if chart database data is available. NOTE The cursor field in the status bar is still giving cursor position for datum WGS 84.
Page 301 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Select Datum Procedure: Step 1 Select Cursor Information... from the Nav Tools menu. The Cursor Information dialog box appears (Figure 9--8). Step 2 To change the datum of the cursor position, select the currently activated datum.
Page 302 Operator Manual 9.1.6 Position Fix With this NavTool any position within the chart can be declared to be a fixed point. The selection can be made with the cursor or manually with the keyboard via the position window Latitude and Longitude. Every fixed point is given a code via the Option buttons that verifies the information source.
Page 303 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Line Of Position 9.1.7 The Lines Of Position (LOP) feature is provided as an aid to the navigator (terrestrial navigation): S To determine ship’s location when forced to operate in the Dead Reckoning (DR) mode.
Page 304 Operator Manual Select the Time Of Validity (TOV). Default time reference is UTC. After pressing the Now button the TOV will be set to the current ships time. Modify / Add Is used to confirm a modification of existing Line Of Position or to add a new LOP.
Page 305 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Save Fix The LOP entries will be saved and can be recalled within four hours. Close Closes the Position Fix dialog box without saving. 10. List of LOP Individual LOP may be enabled or disabled using the check box in the list.
Page 306 Operator Manual Figure: 9--13 Line of Position It might happen that the intersection points are located in two equivalent groups (e.g. as a result of two overlapping range arcs). In this case the user may either select one of these two groups as the most likely position of the ship or add an additional LOP in order to achieve a unique accumulation of intersections for the fix.
Page 307 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 9.1.8 Tidal Prediction The Tidal Prediction is only available, if the Jeppesen/C--Map or JeppesenPRIMAR “Professional+” database is installed and has a valid license. With this NavTool it is possible to calculate tidal prediction for more than 7000 tide stations.
Page 308 Operator Manual Check box (4) for showing the tidal information marks on charts (up to 1 : 500 000 only). Symbol for the information mark Figure: 9--14 Tidal Prediction 9--18 4343DOC020102 Edition: January 2016...
Page 309 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 9.1.9 Magnetic Variation If the coefficient of magnetic variation calculation are out of data the following message appears. The warning message contains an address to get in contact for a new version.
Page 310 Operator Manual Step 1 Step 2 Step 3 Figure: 9--16 Magnetic Variation 9--20 4343DOC020102 Edition: January 2016...
Page 311 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Plot Layer Plot Layer is a drawing tool allowing manual chart entries to be indicated into an area chosen by the user. The chart entries can be composed of different objects. Each of these objects can be individually designed using the offered attributes color and style.
Page 312 Operator Manual 10.1.1 Plot Layer Description Figure: 10--2 Draw Objects Active Group of Objects for selecting a named group of chart entries designating a newly named group of chart entries deleting a desired group of chart entries Edit Edit is subdivided into following groups: Object -- for selecting the display mode Action -- for editing objects Color -- for the object attribute Color...
Page 313 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Info shows context--related information or shows the known data of an object group (name, last modified, contents). How it works S Info for Object Point selection Each point can be marked with a label (font size Small, Middle, Large), Color and Style.
Page 314 Operator Manual Info for Color selection From the variety of colors offered, RED is suggested as color indicating alarm. 10.1.1.1 Example Procedure: Step 1 Select Draw Objects from the Plot Layer menu. The dialog box appears. Step 2 Click on the New Group button. Write down the name e.g. “ANCHOR PLACE”.
Page 315 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 10.1.2 Merge Object Groups Within this Plot Layer function it is possible to merge at least two existing groups to one new group. The maximum size of the new group is 200 points, 1000 line points, 1000 area points and 100 arrows.
Page 316 Operator Manual 10.1.3 Export Object Groups The Export Object Groups command allows you to save groups. Procedure: (Figure: 10--4) Step 1 Select Export Object Group from the Plot Layer menu. The dialog box appears displaying the names of all the object groups saved in the list.
Page 317 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 10.1.4 Import Object Groups The Import Object Groups command allows you to import objects. You can only import objects which have been exported by the ECDIS software from Raytheon Anschütz. Procedure: (Figure: 10--5) Step 1 Select Import Object Group from the Plot Layer menu.
Page 318 Operator Manual Intentionally left blank 10--8 4343DOC020102 Edition: January 2016...
Page 319 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Logs Menu If the ECDIS is in operation the Log function is active. In this case the most rele- vant ship data or events will be recorded in a Current 24 Hour Log file.
Page 320 Operator Manual 11.1.1 Current 24 Hour Log The following events are recorded in the 24 Hour Log.  Alarm  Warning  Info (different information events)  Acknowledge (of alarm or warning)  OwnShip (periodic recording)  NavDevice (position device changed) ...
Page 321 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Command Buttons: Click on Close to exit the box. Close Click on Print to print out the 24 Hour Log contents on Print a separate printer. Click on Export to create a file (TXT format) with the contents Export of the Current 24 Hour List in the view.
Page 322 Operator Manual Click on Filter. The filter dialog box appears (Figure: 11--4). Filter Select the column and event types in the checkbox you want to see in the 24 Hour Log list box (default settings: all columns and events are selected). You may optionally specify a time range for filtering the 24 Hour Log.
Page 323 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 11.1.2 Manage 24 Hour Logs Manage 24 Hour Logs is used to view, export or delete the previously recorded 24 Hour Logs. The system stores the 24 Hour Logs per month. The maximum storage period can be configured by a service technician.
Page 324 Operator Manual Click on Export to create a file (TXT format) with the selected Export previous 24 Hour Log. The export will be done on the selected media drive or USB drive attached to the system. Follow the dialog box (Figure: 11--6). NOTE After exporting, the user may choose to delete the exported logs.
Page 325 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 11.1.3 Manual Log Entries The dialog allows to enter three types of logs: -- Text (free text or user defined template text) -- Environment -- Voyage (start or end of a voyage) All manual 24 Hour Log entries will be formatted as text in a separate row of the Current 24 Hour Log.
Page 326 Operator Manual S Defining text templates for recurring situations. Procedure: (Figure: 11--8) Step 1 Select the button Edit to define user text templates. Step 2 Click the button New to enter user text. Enter user text (e.g. Hello World!). Step 3 Click the button Apply. Step 4 Click the button Close to store the user text.
Page 327 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany S Environment Entry Procedure: (Figure: 11--9) Step 1 Select event type Environment. Step 2 Enter the values for Air Temperature, Air Pressure, Water Temperat- - ure, Wave Height, Wave Direction, Visibility, Coverage. The ’C’ button will clear the corresponding field.
Page 328 Operator Manual S Voyage (Start / End) A Start Voyage entry will reset the voyage distance value and start measuring the voyage distance. Procedure: (Figure: 11--10) Step 1 Select event type Voyage. Step 2 Select Start Voyage or Select End Voyage. An End Voyage entry will stop measuring the voyage distance.
Page 329 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 11.1.4 Voyage Recording The Voyage Recorder automatically retains the ship‘s past track of the last 14 days. This record is registered in the recorded track area of the voyage recording box using the UTC data of the record as reference name.
Page 330 Operator Manual Position Receiver: This list box contains the integrated position receivers. Selection is performed either via the scroll bar or directly via the cursor. While plotting the trail type of position receiver is indicated at each interval mark. Max. Visible length: This entry determines the maximum displayed length of the position trail.
Page 331 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Integration Menu 12.1 Integration Menu Commands Logs Integration Help Nav Device Selection... Target Options… Radar Overlay Settings... Autopilot... Echosounder... Wind Sensor... NavTex... Ship Info INS Test Alert Tender Configuration... Tender Information... Monitor Settings Profile Administration…...
Page 332 Operator Manual Integration Function Commands 12.1.7 NavTex... Option Allows the user to display the NavTex information. 12.1.8 Ship Info... Specifies the ship’s dimensions; specifies location of navigation de- vice antennas relative to bow and port side. 12.1.9 INS Test Alert Allows the user to set a test alert in the INS system to check the alert management.
Page 333 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 12.1.1 Navigation Devices Selection Use the Nav Device Selection command to select from the type(s) of navigation positioning device(s), speed device(s) and depth device(s) you have integrated into the ECDIS or Multifunction Console used as single system (Console, Black Box Version) or used in the Integrated Navigation System (INS).
Page 334 Operator Manual CCRS SELECTION MODE Within this selection possibility, the type of sensor selection is selected. AUTO for the automatic sensor selection. The designation of the sensor soft buttons is displayed in GRAY. GRAY declares the soft buttons to be already active.
Page 335 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany system calculation considered the actual heading and speed and this posi- tion information. Older position information will not be accepted from the system. Within this field, position corrections can be made via an on--screen key- board.
Page 336 Operator Manual SPEED THROUGH WATER All sensors which can be used within a single system or INS are displayed within the SPEED THROUGH WATER display. The SELECT soft buttons are available only in MAN mode. ENABLE selection is available in AUTO mode and MAN mode. ENABLE means that the sensor information has been included in the CCRS rating.
Page 337 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany within the SPEED OVER GROUND display. The SELECT soft buttons are available only in MAN mode. ENABLE selection is available in AUTO mode and MAN mode. ENABLE means that the sensor information has been included in the CCRS rating.
Page 338 Operator Manual The following text describes the meaning of the colored quality indicator. In the Synapsis Service Tool under menu point Ship Parameter, the General Presentation Standard shows the predefined edition of the IEC 62288 for the used system. Sensor Performance if corresponding to IEC 62288 edition 1; The sensor performance is categorized in three rating levels: GPS1 as result from CCRS rating this sensor has...
Page 339 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Sensor Performance if corresponding to IEC 62288 edition 2; The sensor performance is categorized in three rating levels: as result from CCRS rating this sensor has GPS1 good integrity (GREEN). as result from CCRS rating this sensor has GPS2 doubtful integrity.
Page 340 Operator Manual 12.1.2 Target Options (AIS / ARPA) The Automatic Identification System (AIS) is designed for automatic and autono- mous data communication between ships. The communication data consists of information such as identification, position, speed, course over ground (detailed information see AIS Manual). The ECDIS is able to exchange text messages with other ships via AIS.
Page 341 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany -- Sleeping AIS targets may be activated manually via a context menu by right clicking either on the target symbol on the chart or on the AIS target in the target information windows.
Page 342 Operator Manual AIS target filtering comprises of the two settings for Show AIS AtoN and Base Stations and the Visual Range. Figure: 12--5 Target Options Menu If the Own Ship AIS Transponder Data is available at the ECDIS, an extended AIS Options dialog is displayed.
Page 343 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Figure: 12--6 Association Groups 12--13 Edition: January 2016 4343DOC020102...
Page 344 Operator Manual Figure: 12--7 Own Ship Voyage Settings The extended AIS Options dialog provides the possibility to change the own ship voyage settings and write them to the AIS Transponder. The none voyage related own ship AIS Transponder data may be displayed. 12--14 4343DOC020102 Edition: January 2016...
Page 345 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Figure: 12--8 Own Ship AIS Transponder Procedure: (Figure: 12--9) Step 1 Select Target Options… from the Integration menu or alternative via tool bar key. The dialog box appears. Select and change the Options... and Limits for Dangerous Targets.
Page 346 Operator Manual (alternative selection via the Tool Bar) Step 3 Step 2 Figure: 12--9 Selecting an AIS Target 12--16 4343DOC020102 Edition: January 2016...
Page 347 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 12.1.2.2 AIS Messages The ECDIS is able to exchange text messages with other ships via AIS. Procedure: (Figure: 12--10) Step 1 Select AIS Options… from the Integration menu. The dialog box appears.
Page 348 Operator Manual Step 3 Step 2 Step 4, 5, 6, 7 Figure: 12--10 AIS Messages 12--18 4343DOC020102 Edition: January 2016...
Page 349 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 12.1.2.3 AIS Symbols Figure: 12--11 shows a possible ECDIS display with AIS targets and AIS informa- tion window. Figure: 12--11 ECDIS Display with AIS Targets The AIS symbols are assigned in five different pieces of target information. De- pending on the situation, each symbol has a different meaning (see AIS sym- bols).
Page 350 Operator Manual Target symbols: Target Symbol Description of symbol Sleeping AIS Sleeping AIS targets shall be presented as acute isosceles triangles oriented to the tar- targets gets’ reported heading (or COG if heading is not reported) and centered at the targets’ re- ported position.
Page 351 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Target Symbol Description of symbol Activated AIS Alternatively, when own ship is presented as a targets -- true true scaled outline, the user may select to add scaled outlines true scaled outlines to activated AIS target symbols.
Page 352 Operator Manual Target Symbol Description of symbol Heading lines Heading lines shall be selected for display for activated AIS targets and associated targets, represented by AIS target symbols. Heading lines shall originate at the apex of the AIS triangle and shall extend not less than 4 mm and at least 4 mm beyond the bow of the true scaled outline when it is used.
Page 353 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Target Symbol Description of symbol Target past posi- Selected target past Optionally, target past positions may be tions shown. position: Past positions shall be presented as a series of small circular symbols of 1 mm diameter.
Page 354 Operator Manual Target Symbol Description of symbol AIS aids to navi- Physical AIS aids to navigation (ATON) shall gation -- Physi- be presented as an open diamond. The sides of the diamond shall be not more than 6 mm in length.
Page 355 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Target Symbol Description of symbol AIS aids to navi- Virtual AIS aids to navigation (AtoN) shall be gation -- Virtual presented as an open diamond with crosshair centred at reported position. The sides of the diamond shall be not more than 6 mm in length.
Page 356 Operator Manual Target Symbol Description of symbol AIS search and An AIS search and rescue transmitter (AIS-- rescue transmit- SART) shall be as a 6mm diameter circle with ter and other de- a cross inside drawn with a solid line. A test vices using AIS version of the AIS--SART shall use the same burst transmis-...
Page 357 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Target Symbol Description of symbol Selected targets Selected target symbols shall be presented as Selected radar targets: broken squares indicated by their corners, cen- tered on the selected target symbol by the user and clearly extending beyond it.
Page 358 Operator Manual Target Symbol Description of symbol Lost targets Lost radar targets: Lost target symbols shall be presented as crossed lines centered on the target symbol and extending at least 2 mm but not more than 3 mm beyond the symbol. The lines shall be drawn using a solid line style and shall flash with the required color red until acknowledged by the user.
Page 359 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Target Symbol Description of symbol Tracked tender Default target color. target Tracked tender Dangerous target Color red, flash until acknowledged. Associated tar- From activated tender target and tracked tar- gets gets from one or more radars.
Page 360 Operator Manual The Target Information dialog window separator Figure: 12--12 AIS Information Dialog Box In the upper part of the dialog a list of all AIS and ARPA targets is displayed. This is subdivided into columns for the User ID (AIS MMSI), Call Sign, Ship’s Name, CPA in NM, TCPA in minutes, Distance from own ship in NM, Bearing from Own Ship in degree, Target Speed in knots and Target Course over ground in degree.
Page 361 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany The image in the first column indicates the AIS target status (Table 12--2). Image Status of the AIS Targets Tracked Dangerous Lost Dangerous & Lost Table 12--2 AIS Target Status The list in the lower part shows detailed information about the selected targets from the upper list.
Page 362 Operator Manual Figure: 12--14 Example for an ARPA Target Information If the selected target is dangerous, this is also indicated in the CPA/TCPA row (DANGEROUS TARGET). If the selected target is lost, this is also indicated in the position row (LOST TAR- GET).
Page 363 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 12.1.3 Radar Overlay Settings (Option) The Radar Overlay Settings dialog box allows different optical settings for the radar overlay. Is the dialog box activated without radar signal, the elements Range, Sea Clutter, Rain Clutter, Gain and Correlation are deactivated first (chapter 12.1.3.1).
Page 364 Operator Manual Step 1 After the initialization the radar overlay appears on the ECDIS. Figure: 12--16 Radar Overlay Settings -- Enable Radar Overlay -- 12--34 4343DOC020102 Edition: January 2016...
Page 365 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 12.1.3.2 Using the Radar Overlay Settings Procedure: (Figure: 12--17) Step 1 Select Radar Overlay Settings from the Integration menu. The Radar Overlay Settings dialog box appears. Figure: 12--17 Radar Overlay Settings 12--35...
Page 366 Operator Manual Slider Range The Range area on the ECDIS depends on the Pulse Width/Range selection on the RADAR (Figure: 12--18). ECDIS Range Selection RADAR Pulse Width Selection 0,12 SHORT 0,25 MED1 0,75 MED2 12,0 24,0 LONG 48,0 Figure: 12--18 Pulse Width / Range Selection If the Pulse Width/Range is changed on the RADAR, the range of the radar overlay is automatically adjusted to the new range (Figure: 12--19).
Page 367 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Step 2 Use the check box Auto adjust the Range to the view scale to centre the radar overlay in ECDIS. Slider Sea Clutter Keep adjusting slider, as possible, until sea clutter is no longer disturbing the radar overlay.
Page 368 Operator Manual Figure: 12--20 Correlation Scan To Scan Press the Apply button, after the initialization the radar overlay appears on the ECDIS. Sweep To Sweep In the Sweep To Sweep Correlation mode, the targets, coast line etc. are dis- played in a permanent GREEN shade. Figure: 12--21 Correlation Sweep To Sweep Press the Apply button, after the initialization the radar overlay appears on the...
Page 369 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 12.1.4 Autopilot NOTE This chapter applies to all autopilots except for the autopilot NP5500. NOTE Track Control is not an ECDIS function. To activate this function an AUTOPILOT System has to be connected. For detailed information ask Raytheon Anschütz.
Page 370 Operator Manual 12.1.5 Integrating a Depth Sounder / Setting the Depth Alert Use the echosounder command to set an alert depth. If you want to change the unit of measure for the depth display and alert. If the Conning Display Monitor (Option) is connected to the ECDIS the scaling of the depth display will be changed at the same time.
Page 371 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Figure: 12--22 Echosounder Dialog Box 12--41 Edition: January 2016 4343DOC020102...
Page 372 Operator Manual 12.1.6 Changing the Wind Display ECDIS allows you to specify whether you want to display wind data, in the infor- mation panel, relative to your own ship, or as true wind. Depending on the option selected in the dialog box, the information panel will display one of three types of wind.
Page 373 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 12.1.7 Navigational Text Messages NavTex The NavTex messages are automatically stored and can be displayed in the NavTex window. Enable Filter NavTex functions NavTex messages Figure: 12--24 NavTex Dialog 12--43 Edition: January 2016...
Page 374 Operator Manual 12.1.7.1 NavTex Messages Each line consists of the following information (see Figure: 12--25): -- An icon representing the type of message -- Time stamp of the (last) receipt of the NavTex message -- Message type -- NavTex message code -- UTC time from NavTex NMEA message (if provided) -- Frequency the message was received on -- Error rate in %...
Page 375 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 12.1.7.2 NavTex messages with Position Coordinate Information A position coordinate information may be extracted automatically from the con- tents of a NavTex message. If valid latitude / longitude coordinates are recog- nized in a line of a NavTex message, the ECDIS will automatically move the chart to this position after double clicking on the message line.
Page 376 Operator Manual 12.1.7.3 NavTex functions On the right hand side is a set of buttons for the following functions (see Figure: 12--24): -- Collapse All: To restore the list view with all messages collapsed -- Expand All: To show the message contents of all messages -- Print: To print the selected message -- Export:...
Page 377 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany marked as protected. Up to 50 messages may be protected from automatic dele- tion. 12.1.7.4 Enable Filter If the Enable Filter check box is marked, the list of NavTex message may be...
Page 378 Operator Manual 12.1.8 Entering Information about Your Vessel (Ship Info Command) Procedure: (Figure: 12--30) Step 1 Select Ship Info… from the Integration menu. The dialog box appears. Figure: 12--30 Ship Info Dialog Box 12--48 4343DOC020102 Edition: January 2016...
Page 379 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 12.1.9 INS Test Alert The test alert is used to check the alert management in an INS system. This test alert must be displayed in the display for alerts in all MFC consoles.
Page 380 Operator Manual 12.1.10 Tender Tracking (Option) Tender Tracking implies a Seetrac Tender Tracking System. The ECDIS on the main ship allows the tender observation and recording. The tenders are displayed as small violet circles with a course vector. Furthermore, tender information can be displayed via the Tender Information window (Figure: 12--32).
Page 381 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 12.1.10.1 Tender Configuration Note: Dependent on the type of the tender tracking system there are minor differences: -- Some tender systems do not provide SOG and COG data for the tenders. In this case the tender symbols are displayed without a vector and SOG / COG is not displayed in tender information.
Page 382 Operator Manual The Time On Channel is used if there are tenders configured on different channels (see service mode). Managed mode means: The Time On Channel has to be preselected in the service mode. Autonomous mode means: In this case the Time on Channel function is not used. The tender channel selection is managed by Seetrac Basic Unit.
Page 383 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Configure Tender is used to add new tender, edit the values for TTC (Tender Transmission Code), Name, Channel and Recording status. Procedure: Configuration (Figure: 12--34) Step 1 Select Tender Configuration… from the Integration menu or as an alternatively via the tool bar key.
Page 384 Operator Manual (alternative selection via the Tool Bar Key) Step 1 Step 2 Step 3 Step 4 Record Status Disable Tender Recording. Enable or disable the record status. double klick Figure: 12--34 Tender Configuration 12--54 4343DOC020102 Edition: January 2016...
Page 385 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Manage Recordings allows the selection of individual Tender trails. The trails are displayed in a orange or red line. A dotted orange line indicates a depth lower than the Highlighted Depth value. A solid red line indicates a shallow water conture.
Page 386 Operator Manual (alternative selection via the tool bar key) Step 7 Step 1 Step 3 Step 2 Step 4 Step 5 Step 6 Figure: 12--35 Manage Recording 12--56 4343DOC020102 Edition: January 2016...
Page 387 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 12.1.10.2 Tender Information The active channel will be shown on the caption bar of the tender information dialog. Procedure: Tender Information (Figure: 12--36) Step 1 Select Tender Configuration... from the Integration menu or as an alternatively via the tool bar key or by clicking on a Tender symbol in the sea chart.
Page 388 Operator Manual 12.1.11 Monitor Settings This Backlight Brightness allows the operator to switch over between the func- tion CENTRAL and LOCAL backlight dimming. The SYNAPSIS INS mostly con- sists of several MFCs they are combined in groups. In this case the selected CENTRAL function is used for one group.
Page 389 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 12.1.12 Profile Administration The Profile Administration allows the operator to load and modify different kind of ECDIS profiles. Profiles includes e.g. monitor settings, zoom areas in the chart or target options. The different kinds of profiles are: (see Figure: 12--38).
Page 390 Operator Manual Predefined Settings Predefined Settings are fixed settings which cannot be deleted or modified in the Profile Administration List. After loading a selected profile the ECDIS profile will be changed on this MFC console (local). User Settings The User Settings reflects the current ECDIS profile. This profile can be saved under a name.
Page 391 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Step 2 Click into the Edit window and edit the name per online keyboard. Step 3 Finish the procedure Step 4 Press the Save current profile soft button. The new profile displays under the User Settings.
Page 392 Operator Manual Step 4 Step 5 Step 3 Step 2 Step 7 Step 6 Step 8 Step 9 Figure: 12--40 Bridge Profile 12--62 4343DOC020102 Edition: January 2016...
Page 393 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 12.1.12.1 Delete a Profile A predefined setting cannot be deleted. User settings and bridge profiles can be deleted. A user setting cannot be deleted if this setting is combined with another system profile.
Page 394 Operator Manual Step 3 Step 4 Figure: 12--41 Release USB Storage Device 12--64 4343DOC020102 Edition: January 2016...
Page 395 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Help Menu 13.1 Help Menu Commands The Help menu contains the following commands. Integration Help Help Index... System Information... About... Figure: 13--1 Help Menu Table 13--1 Help Menu Commands/Functions Help Commands Function Help Index...
Page 396 Operator Manual Figure: 13--2 About ECDIS 13--2 4343DOC020102 Edition: January 2016...
Page 397 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Error Messages For Bridge Alert Management (BAM) and categories of alarms and warnings, see annex Bridge Alert Management. The following is a list of alert messages which can be generated when working with ECDIS and Chart Station.
Page 398 Operator Manual 14.1 Warning and Notification Messages Table 14--1 Alarms Alarm Message Category Cause AUTOPILOT CONTROL MODE MIS- Control mode mismatch between Autopi- MATCH lot and ECDIS BACKUP NAVIGATOR ALARM Track Control: Backup navigator error acc. to IEC62065 CHANGING TRACK COURSE xxx Track Control: AP is performing course change CONNECTION LOST...
Page 399 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Table 14--2 Warnings Warning Message Categorie Cause ANCHOR WATCH VIOLATION Ship moves out of user defined anchor circle APPROACH OF CRITICAL POINT xxx ECDIS found a critical object on the course of the ship. Potential danger of grounding or collision.
Page 400 Operator Manual Alert Escalation Warnings have to possible escalation behaviours: -- Repeat as warning Warning (audible signal) is repeated. -- Escalate to alarm Warning escalates to prority alarm. Warning escalation is performed after configured warning escalation time. The following list shows all warnings that will be repeated as warning and all alarms that will not be escalated to BNWAS.
Page 401 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany An alert escalation situation can only be considered if a Bridge Navigation Watch Alarm System (BNWAS) is connected to the INS. The user is hereby forced to acknowledge an alarm within a given time window (e.g.
Page 402 Operator Manual 14.2 Permanent Indications Permanent indications are displayed continuously on the chart and can only be removed by eliminating the cause of the indication. The following table provides a list of all possible indications and the cause: Indication Cause Manual position adjustment Position is adjusted manually (see 7.1.2 Posi- tion Offset)
Page 403 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Non-ECDIS presentation - Refer to Paper The chart display is not in accordance with Chart IHO S-52 (see 5.2.1 Presentation Library) Information less than Standard Display The chart display contains less information than in the standard display (see 5.2.6 Over-...
Page 404 Operator Manual Intentionally left blank 14--8 4343DOC020102 Edition: January 2016...
Page 405 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Back- -up Arrangement 15.1 Introduction (Source of excerpts (BSH S33/N24) 1/01) Following requirements must be met to allow the official paper chart on board of seagoing vessels under the German Flag to be completely replaced by an...
Page 406 Operator Manual a) a duplication of the ECDIS b) carrying of a complete set of official and up--to--date paper charts The carriage requirements under Item 2 for a reduced set of official and up--to-- date charts when using the official raster data in RCDS mode remain unaffected by this.
Page 407 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Planned routes are transferred to the ECDIS where they are managed by their designation. 15.1.2 Planning Station Version The Planning Station Version consists of 1 ECDIS unit (Console or Table Top Version), a Personal Computer (PC) or Table Top Version.
Page 408 Operator Manual Intentionally left blank 15--4 4343DOC020102 Edition: January 2016...
Page 409 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Weather Overlay (Option) 16.1 Introduction The Weather Overlay (WO) transparently shows actual, historic or future weather information. Gridded binary data available in WMO -- GRIB (FM 92--IX Ext.) coded files are read, decoded and shown with symbols and numeric values.
Page 410 Operator Manual Figure: 16--1 Example showing Isobars, Wind symbols and numeric values for wind--speed and wind--direction The user may customize the grid location spacing, select the products to show and how to layout a single grid location as a combination of weather product symbols and numeric values (see Options Dialog for details).
Page 411 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 16.2 Tool Bar The weather tool bar contains shortcut items for the following actions:  Global Weather Enable Switch  Open Weather Installation Dialog  Open Weather Options Dialog  Open Weather Info Dialog ...
Page 412 Operator Manual 16.3 Installation Dialog The installation dialog shows a list of currently loaded GRIB data files. File op- erations are defined to modify the priority, switch the enable attribute, delete or purge files, select a file for inspection and auto follow the ECDIS view to display the geographic area of the current selected file.
Page 413 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany NOTE When multiple GRIB files are enabled with overlapping geographic regions, the resulting grid region may not be synchronized to each other. This effect may be reduced by decreasing the view area.
Page 414 Operator Manual To load additional GRIB files press the Load--Files button: Figure: 16--4 Example load--files list with 2 configured file loaders, namely LocalDrives and WetterWelt Depending on the ECDIS configuration a list of file loaders is shown, or a single configured file loader is directly executed.
Page 415 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 16.3.1 Local Drives The LocalDrives file loader may load any GRIB files located on local drives. Figure: 16--6 Example with selected USB folder J:/Weather_Download, showing 4 selected files with varying sizes The Load button will copy and load the selected files with an optional overwrite warning message when trying to overwrite an already existing file.
Page 416 Operator Manual 16.3.2 WetterWelt - - Catalog The Catalog WetterWelt file loader may load GRIB files remotely from a Wetter- Welt server. Figure: 16--7 Example with a list of files within the Cargo group, 1 selected file Cargo_NorthSea_BalticSea_04_120h.zip The Refresh button will reload the catalog. This may be useful when waiting for a delayed GRIB file production (see OnDemand mode below).
Page 417 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 16.3.3 WetterWelt - - OnDemand The OnDemand WetterWelt file loader may load GRIB files remotely from a Wet- terWelt server depending on a user request form. Figure: 16--8 Example with Package Selection named Weather Worldwide Highres, some selected products, geographic region, 3 days forecast, 6 hours stepping, 0.4 degrees resolution and an...
Page 418 Operator Manual The user selectable ranges are:  Forecast Days 1 to 10 days  Forecast Step 1, 3, 6 and 12 hours  Grid Resolution 0.100, 0.125, 0.400, 1.000 and 2.000 degrees All listed products may be selected or de--deselected. But always inspect the re- turned GRIB file for any warning messages like ”products not available”.
Page 419 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 16.4 Options Dialog The options dialog shows the current configuration of attributes which directly con- trol the visual appearance of weather overlay symbols and numeric values. Figure: 16--10 Example with selected full layout (wind, wind--num,waves, waves--num), all 3 selected iso--lines, selected show--units switch, wind--speed (kn, 70 kn limit), current--speed (kn, 3.0 kn...
Page 420 Operator Manual Single display example: Figure: 16--11 wind symbol with numeric gust(28 kn) Double display example: Figure: 16--12 Left: wind symbol with numeric gust(28 kn) Right: numeric wave--height (2.5 m), wave--direction (288 º), wave--period (9 s). Full display example: Figure: 16--13 Top- -Left: wind symbol with numeric gust(28 kn) Top- -Right: wind--speed (22 kn), wind--direction(164 º), gust (28 kn) Bottom- -Left: wave symbol with numeric period(9 s) Bottom- -Right: numeric wave--height (2.5 m), wave--direction...
Page 421 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Figure: 16--14 Example with a full product list for the top/left position of the full layout The list of selectable symbols and numeric values:  Wind wind symbol (vane coded to speed, opt. numeric gust) ...
Page 422 Operator Manual Symbols / Numeric Values Name (type) Drawings Values Wind (Symbol) Wind (Symbol) gust Wind (Numeric) speed direction Wind (Numeric) speed direction gust Current (Symbol) Current (Numeric) speed direction Pressure (Numeric) sea level pressure Air Temperature (Numeric) Degrees Celsius Cloud (Symbol) octans Cloud (Numeric)
Page 423 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany WeatherWelt (Example Sym- cloudy weather bol) (see below for detailed table) Alarm Colour Example wind symbol with gust Additionally the Options Dialog controls the following display options:  Air Pressure (Iso) shows consecutive iso--lines for mean--sea--level-- pressure -- in steps of 5 hPa ...
Page 424 Operator Manual WetterWelt Symbol Symbol Decription Symbol Decription sky clear cloudy 30% cloudy 50% cloudy 100% haze rain with some clouds rain with clouds rain with blue sky snow with bue sky snow with some clouds havy rain with clouds snow with rain snow with clouds storm with rain...
Page 425 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany 16.4.1 Info Dialog The info dialog shows all available values depending on the current mouse--over location. Figure: 16--15 Example with shown values for wind (direction, speed, gust), air pressure, waves height direction and period, current used...
Page 426 Operator Manual Pressing the Live/Animate button will switch to animation mode, and will select the forecast time near to the current live time when possible. Figure: 16--16 Example with activated animation mode, selected forecast date/time 2011--12--06 22:00, activated loop and play buttons, actual value read outs corresponding to mouse--over location NOTE The read outs will always be available within the geographic area of the...
Page 427 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany NOTE The Live/Animate button may be deactivated due to characteristics of the currently enabled GRIB files. Non overlapping geographic regions or non overlapping time ranges will deactivate the Live/Animate button. In this situation some files must be disabled to have the animation mode available -- i.e.
Page 428 Operator Manual 16.5 Context Menu A context menu is shown, when right clicking inside an active weather geo- graphic area. Figure: 16--17 Example showing a context menu with shortcuts for Weather--Report, Weather--Info, Weather--Legend and Char--Information The following actions are available: ...
Page 429 SYNAPSIS ECDIS Operator Manual Raytheon Anschütz GmbH Germany Figure: 16--18 Example showing a weather report starting on 2012--01--17 14:00 NOTE Values which do not exist for the specific forecast time are interpolated over time and marked with an asterisk (*) after the product name.
Page 430 Operator Manual 16.6 Legend The legend shows example symbols with attached limits and isoline examples. Symbols and numeric values will be shown in orange colour when exceeding the respective limit. Figure: 16--19 Example legend with wind symbols, wave symbols, current symbols, isoline symbols (mean--sea--level--pressure, air temperature, and wave height), cloud cover symbol and WetterWelt example symbols.
Page 431  Category C Alarms and warnings of this category cannot be acknowledged on the bridge, e.g., certain alerts from the engine. The audible annunciation of these alerts is duplicated at the CAM-HMI. The Synapsis ECDIS does not generate own category C alerts.
Page 432 Highest priority of an alert. Alarms which indicate immediate danger to human life or to the ship and its machinery exists and that immediate action must be taken. The Synapsis ECDIS does not generate own emergency alarms.  ALARM The latest active alarm is always displayed at the top line of the list in RED.
Page 433 Bridge Alert Management Annex Table 1-1 Emergency Alert Symbol Icon/Symbol Description Active Table 1-2 Alarm Symbols Icon/Symbol Description Active – unacknowledged alarm (flashing) Active – silenced alarm (flashing) Active – acknowledged alarm Rectified – unacknowledged alarm (flashing) Active – responsibility transferred alarm Table 1-3 Warning Symbols Icon/Symbol...
Page 434 Bridge Alert Management Annex Table 1-5 Acknowledge Not Allowed Symbols Icon/Symbol Description Emergency alarm – acknowledge not allowed Alarm – acknowledge not allowed Warning – acknowledge not allowed If these symbols appear on the display next to alert symbol, the alert cannot be acknowledged on this device.

Raytheon Anschütz SYNAPSIS ECDIS Operator's Manual

1 Introduction

2 Display Organization

3 Main Menu

4 Chart Menu

5 Options Menu

Quick Links

Related Manuals for Raytheon Anschütz SYNAPSIS ECDIS

Summary of Contents for Raytheon Anschütz SYNAPSIS ECDIS

Table of Contents
