- Page 1 Operation and User Manual FPC-5V2 Panel Fire Protection Controller Issue April 2019 Version 2 P a g e FPC-...
- Page 2 7. Testing and Commissioning ..................7 8. FPC5-V2 Module Assembly ..................9 9. Adaptor plate/junction box coupling required ............9 10. FPC5-V2 Module Connection to Condensed Aerosol Generators ....10 11. Kiwa Declarations ....................11 P a g e FPC-5V2 April 2019...
- Page 3 This Operation & User Manual provides information on the FPC-5V2 fire protection module and how it is connected to the various FirePro Condensed Aerosol Generators. Autonomous fire suppression unit Primary power source: 3Vdc battery. Battery monitoring feature with LED - indication.
- Page 4 The fire protection module FPC-5V2 is powered by an internal 3V battery capable of providing the necessary amperage to activate a condensed aerosol fire suppression generator. The FPC-5V2 module is equipped with a battery monitoring feature. The battery status is indicated by the three LEDs located on the front of the unit.
-
Page 5: Front Section
It is important to pass the Condensed Aerosol Generator wires from the same opening of the adaptor plate/junction box coupling. Figure 6 Step 3: Install the FPC-5V2 main body to the Condensed Aerosol Generator by turning Figure 7 Step 4: the electronic PCB. - Page 6 PCB from the front section of the FPC-5V2 module. Press Switch Figure 12 Step 9: Place the front section of the FPC-5V2 module into the main body of the FPC- 5V2. Insert and tighten safety Knob "A" to assemble the unit. P a g e FPC-5V2...
- Page 7 . Figure 14 Typical installation The FPC-5V2 module equipped with a bimetallic sensor must be installed in such a way so that the bimetallic sensor is as close to the ceiling inside the electrical panel enclosure.
- Page 8 Table1: Specifications For Testing, Commissioning and Simulation purposes, the Condensed Aerosol Generator is disconnected from the fire protection module FPC-5V2 and replaced by an indication circuit as per below diagram. The indication circuit includes a resistor and an LED (the indication circuit must be installed as illustrated below since the LEDs feature polarity).
- Page 9 Step 9: By using an ohm-meter ensure that the ohmic resistance of the condensed aerosol generators is b Step 10: Replace the simulation LED circuit with the condensed aerosol generators. Figure 17: Measuring the Condensed Aerosol Generator resistance P a g e FPC-5V2 April 2019...
- Page 10 Aerosol Generator series: FP-20 Adaptor plate applicable to Condensed Aerosol Generator series: FP-40, FP-80 Junction box coupling applicable to Condensed Aerosol Generator series: FP- 100, FP-200, FP-500, FP-1200, FP-2000, FP-3000, FP-4200, FP-5700, Table 1: P a g e FPC-5V2 April 2019...
- Page 11 Figure 19: For Box type Condensed Aerosol Generators FP-1200, 2000, 3000, 4200, 5700 FP-20 FP-40,80 FP-100,200,500 Figure 19: For Cylindrical type Condensed Aerosol Generators FP-20,40, 80, 100, 200, 500 10 | P a g e FPC-5V2 April 2019...
- Page 12 Declarations 11 | P a g e FPC-5V2 April 2019...
-
Page 13: Declaration Of Conformity
Extension cable for bi-metal switch and heat cable STATEMENT BY KIWA With this declaration, Kiwa declares that legitimate confidence exists that the products supplied by FirePro Systems Ltd. comply with the technical specifications as laid down in this product declaration. Ronald Karel Kiwa This declaration consists of 6 pages. - Page 14 K94463/05 ® Page 2 of 6 FirePro Ignition device for Non-Pressurized Condensed Aerosol Generators Declaration This product declaration is based on the functional requirement § 4.4.2, § 4.4.3 and test requirements § 7.15 of CEN/TR 15276-1. Ignition device(s) other than the standard electrical ignition device have not been tested as a part of the Non-Pressurized Condensed Aerosol Generators or separate component according §...
- Page 15 K94463/05 ® Page 3 of 6 FirePro Ignition device for Non-Pressurized Condensed Aerosol Generators Application and use Total flooding fire-extinguishing systems are used primarily for protection against hazards that are in enclosures or equipment that, in itself, includes an enclosure to contain the extinguishant. Condensed aerosol generators can be used as a part of fire fighting systems in buildings, plants or other structures.
- Page 16 Kiwa declaration K94463/05 ® Page 4 of 6 FirePro Ignition device for Non-Pressurized Condensed Aerosol Generators Marking ® The products should be marked with the Kiwa -mark. Place of the mark Required specifications Method of marking • • • On the generator Name of the product and supplier Non-erasable and non-detachable;...
- Page 17 K94463/05 ® Page 5 of 6 FirePro Ignition device for Non-Pressurized Condensed Aerosol Generators Cross reference CEN/TR 15276-1, Fixed fire fighting systems - Condensed aerosol extinguishing systems - Part 1: Requirements and test methods for components, February 2009 Chapter...
- Page 18 Kiwa declaration K94463/05 ® Page 6 of 6 FirePro Ignition device for Non-Pressurized Condensed Aerosol Generators Chapter Description Demand Result Remarks Test methods 7.15 Ignition performance test Pass 25 samples of the complete ignition devices: • Bi-metal switch, • Heat cable and •...
-
Page 19: Limitation Of Liability
(including negligence), strict liability or otherwise, even if advised of the possibility of such damages. NOTE FirePro is constantly updating its products and systems to the state of the art and therefore reserves the right to make changes in design, equipment and technology. You cannot... - Page 20 FirePro Systems 8 Faleas Street, Agios Athanasios Industrial Area, CY-4101 Limassol, Cyprus - EU P a g e FPC- Tel.: +357 25 379999 | Fax: +357 25 354432 | Email: mail@firepro.com www.firepro.com...
