TROUBLESHOOTING

Symptom
No output or display
Inaccurate measured
temperature
Voltage output does
not match displayed
temperature
No alarm output
Cannot change
settings
Probable Cause
No power to the
sensor
Target too small for
sensor's field of view
Incorrect emissivity
setting
Target is a reflective
metal surface
Field of view
obstruction
Dust or condensation
on lens
Output temperature
scale mismatch
Incorrect wiring or
configuration
Sensor is locked
(padlock icon is
displayed)
Solution
Check the power supply and wiring
Ensure the sensor's view is completely filled
by the target. Position the sensor closer to
the target to measure a smaller area.
Choose the correct emissivity setting for the
target material. See "Configuration -
Emissivity" for more information.
Try using a low emissivity setting, or paint or
coat a measurable area of the target to
make it non-reflective
Remove obstruction; ensure sensor has a
clear view of target
Ensure lens is clean and dry. Clean gently
with a soft lens cloth and water. If problem
recurs, consider using an air purge collar.
Check the output range and scale in Voltage
Output settings; ensure the output scale
matches the input range of the
measurement instrument
Check electrical connections (see
Installation), Reset Alarm, and Alarm Output
settings
Go to Settings – Enter PIN to unlock the
sensor
