DEFAULT SETTINGS

The sensor is fully configurable via the display and controls. No configuration is necessary in
many applications: the sensor will work straight out of the box with the below default settings.
All settings are adjustable except those marked (fixed).
Setting
Output Voltage
Temperature Low
Temperature High
Alarm Trigger
Temperature Reference
(Alarm)
Alarm Set Point
Alarm Hysteresis
Output Mode (Alarm)
Alarm Reset
Emissivity Setting
Reflected Energy
Compensation
Reflected Temperature
Averaging Period
Hold Mode
Hold Period
Displayed Temperature
Temperature Units
PIN
GUARANTEE
Calex guarantees each instrument it manufactures to be free from defect in material
and workmanship under normal use and service for the period of two years from the date
of purchase. This guarantee extends only to the original buyer according to Calex's standard
Terms and Conditions of Sale.
Calex Electronics Limited
PO Box 2, Leighton Buzzard, Bedfordshire, England LU7 4AZ
Tel: +44 (0)1525 373178 | mail@calex.co.uk | www.calex.co.uk
12
Range of Values
0-5 V / 1-5 V / 0-10 V
0°C to 900°C
100°C to 1000°C
HI / LO / Off
Measured / Internal
0°C to 1000°C
0°C to 30°C
Active HI / Active LO
Auto / Manual
0.2 to 1.0
On/Off
0°C to 1000°C
0 s to 60 s
Peak/Valley/Off
0 s to 1200 s
RAW / FIL / AVG
°C / °F
Default Value
0-10 V
0°C
1000°C
HI
Measured
100°C
1°C
Active HI
Auto
0.95
Off
25°C (note: this value is
automatically overridden
when Reflected Energy
Compensation is Off)
0 s
Off
0 s
RAW
°C
1234 (fixed)
